Cisco catalyst 2960XR-24PS-L IP Lite Base layer 2 - 3 stackable switch is comprised of 24 * 10/100/1000 Ethernet ports with POE+ and 4 SPF uplink interfaces.  IP Lite Image enables basic access layer 3 routing features, such as RIPV1, V2, OSPF stub, EIGRP stub, HSRP, VRRP, PIM stub, etc.

Quick Specs

Table 1 shows the Quick Specs.

Product Details

Figure 1 shows the front panel of WS-C2960XR-24PS-I.

Note:

·There are twenty-four 10/100/1000 Ethernet Gigabit Ports and four 1G SFP+ uplinks on the front panel.

·Two USB Type A ports and one USB mini-Type B (console) port are on the left.

·This switch offers one RJ-45 console port and one Ethernet management port on the left of the front panel.

·Power over Ethernet Plus (PoE+) supportS up to 370W of PoE budget for 12 ports with 30W per port or 24 ports with 15.4W per port

Figure 2 shows the back panel of WS-C2960XR-24PS-I.

Note:

① FlexStack-Plus module slot and cover  ② Power supply slot (with blank module)  ③ AC OK LED  ④ PS OK LED

⑤ AC power connector on the power supply module

The WS-C2960XR-24PS-I supports stacking with the optional stack kit. It has the FlexStack-Plus module (hot-swappable) that inserts in the slot located in the switch rear panel, and a 0.5-meter FlexStack cable to connect the FlexStack-Plus module ports. The stack module should purchase separately.

The Accessories

Table 2 shows some accessories of WS-C2960XR-24PS-I.
