The ASA5515-FPWR-K9 is the Cisco ASA 5500 Edition Bundle ASA5515-K9 ASA 5515-X with SW, 6GE Data, 1GE Mgmt, AC, 3DES/AES.
Quick Spec
Figure 1 shows the appearance of ASA5515-FPWR-K9.
Table 1 shows the quick spec.
|
Product Number |
ASA5515-FPWR-K9 |
|
Product Description |
Cisco ASA 5500 Edition Bundle ASA5515-K9 ASA 5515-X with SW, 6GE Data, 1GE Mgmt, AC, 3DES/AES |
|
Throughput: Application Control (AVC) |
500 Mbps |
|
Throughput: Application Control (AVC) and IPS |
250 Mbps |
|
Stateful inspection throughput (maximum) |
1.2 Gbps |
|
Stateful inspection throughput (multiprotocol) |
600 Mbps |
|
Triple Data Encryption Standard/ |
250 Mbps |
|
Users/nodes |
Unlimited |
|
Dimensions(H x W x D) |
1.67 x 16.7 x 15.6 in. (4.24 x 42.9 x 39.5 cm) |
|
Weight (with AC power supply) |
13.39 lb (6.07 kg) |
Product Details
Figure 2 shows the front panel of ASA5515-FPWR-K9.
Notes:
|
① |
Power button |
|
② |
Front Panel LED |
|
③ |
Hard-disk release button |
Table 2 shows the Front Panel LEDs’ descriptions.
|
LED |
Color |
Description |
|
BOOT |
Flashing green |
Power-up diagnostics are running, or system is booting. |
|
Solid green |
System has passed power-up diagnostics. |
|
|
Off |
Power-up diagnostics are not operational. |
|
|
ACTIVE |
Solid green |
Failover pair is operating normally. |
|
Off |
Failover is not operational. |
|
|
PS |
- |
Power supply status |
|
ALARM |
Off |
Normal operating system function. |
|
Solid amber |
Critical Alarm indicating one or more of the following: –a major failure of a hardware or software component. –an over-temperature condition. –power voltage is outside of the tolerance range. |
|
|
VPN |
Solid green |
VPN tunnel is established. |
|
Off |
No VPN tunnel established. |
|
|
HD |
Flashing green |
Proportioned to read/write activity. |
|
Solid amber |
Hard-disk drive failure. |
|
|
Off |
No hard-disk drive present. |
Figure 3 shows the back panel of ASA5515-K9.
Note：
|
① |
Back Panel LED: Power, Alarm, Boot, Active, VPN, HD0, HD1 |
④ |
Power supply |
|
② |
Console port |
⑤ |
GigabitEthernet data interfaces (0/0 through 0/5) |
|
③ |
USB Ports |
⑥ |
Management 0/0 interface |
·The GigabitEthernet interface connects with an RJ-45 cable and must be restricted to management use only
Compare to Similar Items
Table 4 shows the comparison of ASA5515-FPWR-K9 and ASA5512-FPWR-K9.
|
Models |
ASA5515-FPWR-K9 |
|
|
Product Description |
ASA 5515-X with FirePOWER Services, 6GE data, AC, 3DES/AES, SSD |
ASA 5512-X with FirePOWER Services, 6GE data, AC, 3DES/AES, SSD |
|
Throughput: Application Control (AVC) |
500 Mbps |
300 Mbps |
|
Throughput: Application Control (AVC) and IPS |
250 Mbps |
150 Mbps |
|
Stateful inspection throughput (maximum) |
1.2 Gbps |
1 Gbps |
|
Stateful inspection throughput (multiprotocol) |
600 Mbps |
500 Mbps |
|
Triple Data Encryption Standard/ |
250 Mbps |
200 Mbps |
Datasheet Download
[PDF] Cisco ASA 5500 with FirePOWER Services Datasheet
Get more information
Do you have any question about the ASA5515-FPWR-K9?
Contact us now via Live Chat or [email protected].
ASA5515-FPWR-K9 Specification
ASA5515-FPWR-K9 Specification |
|
|
Product Number |
ASA5515-FPWR-K9 |
|
Product Description |
Cisco ASA 5500 Edition Bundle ASA5515-K9 ASA 5515-X with SW, 6GE Data, 1GE Mgmt, AC, 3DES/AES |
|
Throughput: Application Control (AVC) |
500 Mbps |
|
Throughput: Application Control (AVC) and IPS |
250 Mbps |
|
Maximum concurrent sessions |
250,000 |
|
Maximum New Connections per second |
15,000 |
|
Supported applications |
More than 3,000 |
|
URL categories |
80+ |
|
Number of URLs categorized |
More than 280 million |
|
Centralized configuration, logging, monitoring, and reporting |
Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
|
On-Device Management |
ASDM |
|
Feature |
Cisco ASA 5515-X w/ FirePOWER Services |
|
Stateful inspection throughput (maximum) |
1.2 Gbps |
|
Stateful inspection throughput (multiprotocol) |
600 Mbps |
|
Triple Data Encryption Standard/ |
250 Mbps |
|
Users/nodes |
Unlimited |
|
IPsec site-to-site VPN peers |
250 |
|
Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections |
250 |
|
Virtual interfaces (VLANs) |
100 |
|
Security contexts(included; maximum) |
2.5 |
|
High availability |
Active/ |
|
Integrated Wireless Access Point (See Cisco AP 702 datasheet for WiFi technical details) |
N/A |
|
Expansion slot |
1 interface card |
|
User-accessible Flash slot |
No |
|
USB 2.0 ports |
2 |
|
Integrated I/O |
6 GE copper |
|
Expansion I/O |
6 GE copper or 6 GE SFP |
|
Dedicated management port |
Yes |
|
Serial ports |
1 RJ-45 console |
|
Solid-state drive |
1 slot, 120 GB MLC SED |
|
Memory |
8 GB |
|
System flash |
8 GB |
|
System bus |
Multibus architecture |
|
Temperature |
23 to 104°F (-5 to 40°C) |
|
Relative humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4572 m) |
|
Acoustic noise |
64.2 dBA max |
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4570 m) |
|
AC range line voltage |
100 to 240 VAC |
|
AC normal line voltage |
100 to 240 VAC |
|
AC current |
4.85A |
|
AC frequency |
50/60 Hz |
|
Dual-power supplies |
None |
|
DC domestic line voltage |
-40.5 to 56 VDC |
|
DC international line voltage |
-55 to -72 VDC (-60 VDC nominal) |
|
DC current |
15A (maximum input) |
|
Steady state |
65W |
|
Maximum peak |
70W |
|
Maximum |
239 Btu/hr |
|
Form factor |
1RU, 19-in. rack-mountable |
|
Dimensions (H x W x D) |
1.67 x 16.7 x 15.6 in. (4.24 x 42.9 x 39.5 cm) |
|
Weight (with AC power supply) |
13.39 lb (6.07 kg) |
