Cisco AIR-AP1562D-A-K9 Outdoor Access Point offers the latest 802.11ac Wave 2 functions in a rugged, low-profile housing that service providers and enterprises can deploy easily. Ideal for applications requiring rugged outdoor Wi-Fi coverage, the Cisco Aironet 1560 Series Access Points offer the latest IEEE 802.11ac Wave 2 radio standard in a compact, aesthetically pleasing, easy-to-deploy package.
Quick Specs
Table 1 shows the Quick Specs.
|
SKU |
AIR-AP1562D-A-K9 |
|
Type |
Wireless access point |
|
Form Factor |
External |
|
Data Transfer Rate |
1.3 Gbps |
|
Compliant Standards |
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at |
|
Wireless Protocol |
802.11a/b/g/n/ac Wave 2 |
|
Power Over Ethernet (PoE) |
PoE+ |
|
Wi-Fi Bands |
2.4 GHz, 5 GHz |
Product Details
Cisco AIR-AP1562D-A-K9 has these benefits:
①802.11ac Wave 2 radio
Provides up to 1.3-Gbps data rates with 3 x 3 Multiple Input, Multiple Output (MIMO) and up to three spatial streams.
②Multiuser MIMO (MU-MIMO)
Allows transmission of data to multiple 802.11ac Wave 2-capable clients simultaneously to improve client experience; prior to 802.11ac Wave 2, access points could transmit data to only one client at a time, typically referred to as single-user MIMO.
③Flexible deployment modes
Allows for deployment of the 1560 in a variety of ways including point -to-point and mesh networks; it can also be deployed with the Cisco Mobility Express Solution, which is ideal f or small to medium -sized deployments that supports multiple access points without a physical controller; all deployment modes are easy to set up and configure.
④Small Form-Factor Pluggable (SFP) port
Supports optical fiber-based network connectivity for remote locations.
Compare to Similar Items
Table 2 shows the comparison.
|
Product Name |
AIR-AP1562D-A-K9 |
|
|
Antenna |
Internal |
External |
|
Data Transfer Rate |
1.3 Gbps |
1.3 Gbps |
|
Wireless Protocol |
802.11a/b/g/n/ac Wave 2 |
802.11a/b/g/n/ac Wave 2 |
|
Wi-Fi Bands |
2.4 GHz, 5 GHz |
2.4 GHz, 5 GHz |
|
Power Over Ethernet (PoE) |
PoE+ |
PoE+ |
Get More Information
Do you have any question about the AIR-AP1562D-A-K9?
Contact us now via Live Chat or [email protected].
AIR-AP1562D-A-K9 Specification
AIR-AP1562D-A-K9 Specification |
|
|
General |
|
|
Device Type |
Wireless access point |
|
Ruggedized Design |
Outdoor |
|
Width |
6.7 in |
|
Depth |
4.3 in |
|
Height |
9 in |
|
Networking |
|
|
Form Factor |
External |
|
Connectivity Technology |
Wireless |
|
Data Transfer Rate |
1.3 Gbps |
|
Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ac Wave 2 |
|
Network / Transport Protocol |
L2TP, IPSec |
|
Frequency Band |
2.4 GHz, 5 GHz |
|
Features |
Auto-sensing per device, MAC address filtering, DFS support, VPN passthrough, CleanAir technology, reset button, 2T2R MIMO technology, ClientLink technology, Maximum Ratio Combining (MRC), radio resource management (RRM), cyclic shift diversity (CSD), MU-MIMO technology, Cisco Flexible Antenna Port technology, beamforming technology, packet aggregation A-MPDU, packet aggregation A-MSDU, High Density Experience (HDX) |
|
Encryption Algorithm |
LEAP, AES, TLS, PEAP, TTLS, WPA, WPA2 |
|
Authentication Method |
X.509 certificates, Extensible Authentication Protocol (EAP) |
|
Compliant Standards |
IEEE 802.11, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
|
Antenna |
|
|
Antenna |
Internal |
|
Expansion / Connectivity |
|
|
Interfaces |
1 x 1000Base-T (PoE) - RJ-45 (WAN) ¦ 1 x - SFP (mini-GBIC) (WAN) ¦ 1 x console - RJ-45 |
|
Miscellaneous |
|
|
Compliant Standards |
EN 60950, ICES-003, IEC 60529 IP67, FCC Part 15.247, RSS-210, RSS-102, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, NEMA Type 4X, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, X.509, MIL-STD-810, EN 300 328, FCC OET Bulletin 65c, EN 301489-17, EN 301 489-1, AS/NZS 4268.2003, ANSI / IEEE 587 C62.41, NEMA 250-2008, EN 60068-2-5, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, IEC 60950 Second Edition, EN 60950 Second Edition, EN 301 893 |
|
Power |
|
|
Power Over Ethernet (PoE) Supported |
PoE+ |
|
Environmental Parameters |
|
|
Min Operating Temperature |
-40 °F |
|
Max Operating Temperature |
149 °F |
