AIR-CT5508-12-K9 includes 12 access point licenses and delivers superior 802.11n/ac performance that optimized up to nine times wireless performance of 802.11a/g networks. It supports up to 500 access points and 7000 clients with necessary licenses.
Quick Specs
Figure 1 shows the appearance of AIR-CT5508-12-K9.
Table 1 shows the Quick Specs.
|
Product Code |
AIR-CT5508-12-K9 |
|
Access points |
12 licenses include (500 licenses max) |
|
Device Type |
Wireless controller |
|
Ports |
8 x SFP uplinks |
|
Console ports |
10/100/1000 RJ-45 |
|
Wireless standards |
802.11a/b/g/d/e/h/k/n/r/u/w/ac |
|
Dimensions (W x D x H) |
44 x 53.9 x 4.45 cm |
|
Package Weight |
15.87 Kg |
Product Details
Figure 2 shows the front panel of AIR-CT5508-12-K9.
Note：
|
① |
Service port (RJ-45) |
⑤ |
Console port (Mini USB Type B) |
|
② |
Console port (RJ-45) |
⑥ |
SFP distribution ports |
|
③ |
Redundant port (RP) for future use (RJ-45) |
⑦ |
Management port LEDs |
|
④ |
USB ports 0 and 1 (Type A) |
⑧ |
Expansion module (EM) slot |
· You can use only one console port (either RJ-45 or mini-USB). When you connect to one console port, the other is disabled.
Figure 3 shows the back panel of AIR-CT5508-12-K9.
Note:
|
① |
Power supply PS1 |
④ |
Power supply PS2 slot with blank cover |
|
② |
Power supply PS1 on/off switch |
⑤ |
Fan tray |
|
③ |
Power supply PS1 AC cable connection |
|
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
AIR-CT5508-12-K9 |
||
|
Access Points |
12 access points licenses |
25 access points licenses |
50 access points licenses |
|
Max Access Points |
500 |
500 |
500 |
|
Max Client Support |
7000 |
7000 |
7000 |
|
Ports |
8 x SFP uplinks |
8 x SFP uplinks |
8 x SFP uplinks |
Get more information
Do you have any question about the AIR-CT5508-12-K9?
Contact us now via Live Chat or [email protected].
AIR-CT5508-12-K9 Specification
AIR-CT5508-12-K9 Specifications |
|
|
Access points |
12 licenses include (500 licenses max) |
|
Device Type |
Wireless controller |
|
Ports |
8 * SFP uplinks |
|
Console ports |
10/100/1000 RJ-45 |
|
Wireless standards |
802.11a/b/g/d/e/h/k/n/r/u/w/ac |
|
License |
● 5 AP licese: L-LIC-CT5508-5A ● 25 AP licese: L-LIC-CT5508-25A ● 50 AP licese: L-LIC-CT5508-50A ● 100 AP licese: L-LIC-CT5508-100A ● 250 AP licese: L-LIC-CT5508-250A ● DTLS License: L-LIC-CT55-LPE-K9 |
|
Security standards |
● Wi-Fi Protected Access (WPA) ● IEEE 802.11i (WPA2, RSN) ● RFC 1321 MD5 Message-Digest Algorithm ● RFC 1851 The ESP Triple DES Transform ● RFC 2104 HMAC: Keyed Hashing for Message Authentication ● RFC 2246 TLS Protocol Version 1.0 ● RFC 2401 Security Architecture for the Internet Protocol ● RFC 2403 HMAC-MD5-96 within ESP and AH ● RFC 2404 HMAC-SHA-1-96 within ESP and AH ● RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV ● RFC 2406 IP Encapsulating Security Payload (ESP) ● RFC 2407 Interpretation for ISAKMP ● RFC 2408 ISAKMP ● RFC 2409 IKE ● RFC 2451 ESP CBC-Mode Cipher Algorithms ● RFC 3280 Internet X.509 PKI Certificate and CRL Profile ● RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec ● RFC 3686 Using AES Counter Mode with IPsec ESP ● RFC 4347 Datagram Transport Layer Security ● RFC 4346 TLS Protocol Version 1.1 |
|
Encryption |
● WEP and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys) ● Advanced Encryption Standard (AES): CBC, CCM, Counter Mode with Cipher Block Chaining Message Authentication Code Protocol (CCMP) ● DES: DES-CBC, 3DES ● Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit ● DTLS: AES-CBC ● IPSec: DES-CBC, 3DES, AES-CBC |
|
Authentication, Authorization, and Accounting (AAA) |
● IEEE 802.1X ● RFC 2548 Microsoft Vendor-Specific RADIUS Attributes ● RFC 2716 PPP EAP-TLS ● RFC 2865 RADIUS Authentication ● RFC 2866 RADIUS Accounting ● RFC 2867 RADIUS Tunnel Accounting ● RFC 3576 Dynamic Authorization Extensions to RADIUS ● RFC 3579 RADIUS Support for EAP ● RFC 3580 IEEE 802.1X RADIUS Guidelines ● RFC 3748 Extensible Authentication Protocol ● Web-based authentication ● TACACS support for management users |
