The Cisco 3945 router, modular Services Performance Engine (SPE) 150, which can be upgraded for even higher performance as next-generation WAN environments evolve. CISCO3945-SEC/K9 bundle Security function, supporting Security Cisco IOS Firewall, IPS, IPsec (3DES and AES), SSL VPN, and IP BaseEntry-Level Cisco IOS Softeare Functions
Quick Specs
Table 1 shows the Quick Specs of the CISCO3945-SEC/K9.
|
Product Code |
CISCO3945-SEC/K9 |
|
Bundle |
Security Function |
|
Services Performance Engine module |
w/SPE 150 |
|
Rack Units |
3U |
|
Interfaces |
3 integrated 10/100/1000 Ethernet ports with 2 ports capable of RJ-45 or SFP connectivity |
|
Expansion Slot(s) |
4 service module slots 1 Internal Services Module slot 4 onboard digital signal processor (DSP) slots 4 Enhanced High-Speed WAN Interface Card (EHWIC) slots |
|
RAM |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
47.6 cm x 43.8 cm x 13.3 cm |
Product Details
Figure 1 shows the front panel of the CISCO3945-SEC/K9.
Note:
① On/Off switch ② Power connector ③ LEDs area
Table 2 shows the LEDs area description.
|
LED |
Description |
|
|
SYS status LED |
Solid green |
Solid green indicates normal operation. |
|
Blinking green |
System is booting or is in ROM monitor mode. |
|
|
Amber |
System error. |
|
|
Off |
Power is off or system board is faulty. |
|
|
ACT status LED |
Solid or blinking green |
Solid or blinking indicates packet activity between the forwarding and routing engine and any I/O port. |
|
Off |
No packet transfers are occurring. |
|
|
POE |
Green |
IP phone power is on. |
|
Amber |
IP phone power is not on. |
|
|
PS1 / PS2 |
Green |
System is running. |
|
Amber |
System is not running. |
|
Figure 2 shows the back panel of the CISCO3945-SEC/K9 with slots and ports.
Note:
① Compact flash 0 and 1 (0, right) ② EHWIC 0,1,2 and 3 (0, far right) ③ USB serial port ④ RJ-45 serial console port ⑤ AUX port
⑥ SFP 1 and SFP 2 (2, top) ⑦ 10/100/1000 Ethernet port GE 0/1 and GE 0/2 (GE 0/1, down) ⑧ 10/100/1000 Ethernet port GE 0/0 ⑨ USB 0 and USB 1 (1,top)
⑩ Ground ⑪ Service module slots
Figure 3 shows security bundle.
Modularity Features
Table 3 shows recommended modules for this router.
|
Models |
Description |
|
Cisco Services Performance Engine 150 for Cisco 3945 ISR (It's a configured item in the CISCO3945-SEC/K9.) |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
16-channel high-density voice DSP module |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
1GB USB Flash Token |
Compare to Similar Routers
Table 5 shows the comparison of CISCO3945-SEC/K9 and CISCO3945/K9.
|
Model |
CISCO3945-SEC/K9 |
|
|
Bundle |
Security Bundle |
None |
|
SPE |
w/SPE 100 |
w/SPE 150 |
|
Interface |
3GE |
3GE |
|
EHWIC slots |
4 |
4 |
|
SM slots |
2 |
4 |
|
ISM slots |
1 |
1 |
|
DSP |
4 |
4 |
|
SFP |
2 |
2 |
|
Rack Unit |
3U |
3U |
Get more information
Do you have any question about the CISCO3945-SEC/K9?
Contact us now via Live Chat or [email protected].
CISCO3945-SEC/K9 Specification
CISCO3945-SEC/K9 Specifications |
|
|
Device Type |
Router |
|
Form Factor |
Desktop - modular - 3U |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Capacity |
Cisco Unified Communications Manager Express sessions : 350 |
|
Network / Transport Protocol |
IPSec, PPPoE, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR) |
|
Remote Management Protocol |
SNMP, RMON |
|
Encryption Algorithm |
SSL |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
|
DRAM Memory |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
LED Status Lights Indicators |
Link activity, power |
|
Connectivity Slots |
|
|
Router Interfaces |
3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
|
Expansion Slots Total (Free) |
4 ( 4 ) x EHWIC |
|
Power Supply |
|
|
Power Device |
Power supply - internal |
|
Voltage Required |
AC 120/230 V ( 47/63 Hz ) |
|
Dimensions / Weight / Miscellaneous |
|
|
Width |
47.6 cm |
|
Depth |
43.8 cm |
|
Height |
13.3 cm |
|
Weight |
17.7 kg |
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438 |
|
System Software |
|
|
IOS Software Included |
Cisco IOS Security |
