WS-C2960G-8TC-L is one of the Cisco Catalyst 2960G Series switches. It provides 7 Ethernet 10/100/1000 ports and 1 dual-purpose uplink (dual-purpose uplink port has 1 10/100/1000 Ethernet port and 1 SFP-based Gigabit Ethernet port, 1 port active)
Quick Specs
Figure 1 shows the appearance of the WS-C2960G-8TC-L.
Table 1 shows the Quick Spec of the WS-C2960G-8TC-L.
|
Product Code |
WS-C2960G-8TC-L |
|
Enclosure Type |
Rack-mountable - 1U |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
1 dual-purpose (10/100/1000 or SFP) ports |
|
Ports |
7 x 10/100/1000 ports |
|
Throughput |
11.9 Mpps |
|
Backplane Capacity |
32 Gbps |
|
DRAM |
64 MB |
|
Dimensions |
1.73 x 17.5 x 13 in. |
|
Package Weight |
5.17 Kg |
Product Details
Figure 2 shows the front panel of the WS-C2960G-8TC-L.
Note:
|
① |
System LEDs |
|
② |
Mode Button |
|
③ |
Console port |
|
④ |
7 × 10/100/1000 ports |
|
⑤ |
Dual-purpose port |
Figure 3 shows the back panel of the WS-C2960G-8TC-L.
Note: There are a AC power connector on the back panel. WS-C2960G-8TC-L has no fan.
The Accessories
Table 2 shows some accessories of the WS-C2960G-8TC-L.
|
Models |
Description |
|
GE SFP, LC connector LX/LH transceiver |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
WS-C2960G-8TC-L |
|
|
Ports |
7 x 10/100/1000 ports |
8 x 10/100/1000 Gigabit Ethernet ports |
|
Uplinks |
1 dual-purpose (10/100/1000 or SFP) ports |
2 x 1G copper plus 2 x 1G SFP |
|
Feature Set |
LAN Base |
LAN Base |
Get more information
Do you have any question about the WS-C2960G-8TC-L?
Contact us now via Live Chat or [email protected].
WS-C2960G-48TC-L (USED) Specification
| Specifications | |
| Type | Fixed |
| Topology | Ethernet (10/100/1000BaseT) Gigabit Ethernet (SFP) |
| Maximum Port density | 44 10/100/1000 ports |
| Uplinks | 4 dual-purpose (10/100/1000 or SFP) ports |
| Modular/Expansion Slots | n/a |
| Architecture | Layer 2 Switching (basic connectivity), Layer 2 Switching (intelligent services), Voice Enabled |
| Form Factor | Fixed, Rack Mountable, Standalone/Clustering |
| Dimensions | 1.73 x 17.5 x 12.9 in. |
| DRAM | 64 MB |
| Features | |
| Specialized Service Modules | n/a |
| Security | |
| DHCP Snooping |  |
| Dynamic ARP Inspection | |
| IP Source Guard | |
| RP Rate Limiters | |
| TCP Intercept | |
| 802.1x | |
| Port Security | |
| Dynamic VLANs | |
| Private VLANs | |
| Private VLAN Edge | |
| Secure Shell | |
| SNMPv3 | |
| Unicast RPF | |
| ACLs (L2-L4) | |
| Kerberos | |
| TACACS+ | |
| RADIUS | |
| High Availability/Resilliency | |
| Hardware Redundancy | External Redundant Power Supply |
| High Availability/Resilliency | PVST, Broadcast Suppression, Unicast Suppression, Mulitcast Suppression, Spanning Tree, Portfast, Uplink Fast, Backbone Fast, 802.1s, 802.1w |
| Management | |
| Management features | SPAN, RSPAN, CiscoView, Cisco Discover Protocol (CDP), Virtual Trunking Protocol (VTP), Telnet Client, BOOTP, TFTP, CiscoWorks, CWSI, RMON, SNMP, Clustering, Web-Based Management |
| Scalability | |
| WAN Interface Support | n/a |
| Throughput | 39 Mpps |
| Backplane Capacity | 32 Gbps |
| Number of VLANs | 255 |
