HPE OFFICECONNECT 1950 12XGT 4SFP+ SWITCH
JH295A Specification
html
JH295A Specifications | |
| Brand | Aruba |
| Product Name | HPE OfficeConnect 1950 12XGT 4SFP+ Switch |
| Product Model | JH295A |
| Product Type | Switch - 16 ports - L3 - Managed |
| Ports | 12 x 10GBase-T + 4 x 10 Gigabit SFP+ |
| Performance | Switching capacity: 320 Gbps Throughput: up to 238 Mpps |
| MAC Address Table Size | 32K entries |
| Jumbo Frame Support | Yes, up to 10KB |
| Routing Protocol | Static IPv4 routing, Static IPv6 routing |
| Management | Web-based management, CLI, SNMP, RMON |
| Features | Flow control, full duplex capability, Layer 3 switching, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, IPv6 support |
| RAM | 1 GB |
| Flash Memory | 128 MB |
| Power Device | Internal power supply |
| Power Consumption Operational | Max 110 W |
| Authentication Method | RADIUS, TACACS+ |
| Encryption Algorithm | SSL |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.3ae, IEEE 802.3an |
| Dimensions (WxDxH) | 17.32 in x 6.3 in x 1.73 in |
| Operating Temperature | 0��C to 45��C |
| Operating Humidity Range | 15% to 95% (non-condensing) |
| Status Indicators | Power, link/activity, fan, temperature |
