Cisco 870 Series of integrated services routers are fixed-configuration routers that support multiple types of DSL technologies, broadband cable, and Metro Ethernet connections in small offices. CISCO877W-G-E-M-K9 provides the performance needed to run concurrent services, including firewall, intrusion prevention, and encryption for VPNs; optional 802.11b/g for WLAN networking; and quality of service (QoS) features for optimizing voice and video applications. In addition, the Cisco Router and Security Device Manager (SDM) Web-based configuration tool simplifies setup and deployment , and centralized management capabilities give network managers visibility and control of the network configurations at the remote site.
Quick Spec
Figure 1 shows the appearance of CISCO877W-G-E-M-K9.
Table 1 shows the quick spec.
|
Product Code |
CISCO877W-G-E-M-K9 |
|
Product Description |
Cisco 877 Integrated Services Router - router |
|
Product Type |
Router + 4-port switch (integrated) |
|
Default DRAM |
128 MB |
|
Maximum DRAM |
256 MB |
|
Default Flash Memory |
24 MB (28 MB for Advanced IP Services Feature Set) |
|
Maximum Flash Memory |
52 MB |
|
Dimensions (H x W x D) |
2.00 x 10.25 x 8.50 in |
|
Weight |
2.10 lb |
Compare to Similar Items
Table 2 shows the comparison between CISCO877W-G-E-M-K9 and CISCO861-K9.
|
Product Code |
CISCO877W-G-E-M-K9 |
|
|
WAN Interface |
ADSL over POTS |
10/100 Mbps Fast Ethernet |
|
LAN Interfaces |
4-port 10/100 Mbps managed switch |
4-port 10/100 FE managed switch |
|
802.11b/g Option |
Yes (Cisco 877W) |
No |
|
Default DRAM |
128 MB |
256 MB |
|
Maximum DRAM |
256 MB |
256 MB |
|
Default Flash Memory |
24 MB (28 MB for Advanced IP Services Feature Set) |
128 MB |
|
Maximum Flash Memory |
52 MB |
128 MB |
CISCO877W-G-E-M-K9 (USED) Specification
CISCO877W-G-E-M-K9 specification |
|
|
Product Description |
Cisco 877 Integrated Services Router - router |
|
Manufacturer Part Number |
CISCO877W-G-E-M-K9 |
|
Product Type |
Router + 4-port switch (integrated) |
|
Default DRAM |
128 MB |
|
Maximum DRAM |
256 MB |
|
Default Flash Memory |
24 MB (28 MB for Advanced IP Services Feature Set) |
|
Maximum Flash Memory |
52 MB |
|
Data Transfer Rate |
54 Mbps |
|
Frequency Band |
2.4 GHz |
|
Dimensions (H x W x D) |
2.00 x 10.25 x 8.50 in |
|
Weight |
2.10 lb |
|
WAN Interface |
ADSL over POTS |
|
LAN Interfaces |
4-port 10/100 FE managed switch |
|
802.11g/n Option |
Yes (Cisco 877W) |
|
Console Port |
RJ-45 |
|
LEDs |
PPP, VPN, ADSL, G.SHDSL, WLAN, LAN |
|
External Power Supply |
Universal 100 to 240 VAC |
|
Inline PoE |
Optional external adapter for inline PoE for IP phones or external wireless access points |
