Cisco ASA 5508-X FirePower services Firewall is the entry-level next-generation firewall system.It is designed for small or mid-size enterprise or branch offices. It provides 8 Gigabit Ethernet interfaces,80GB SSD, supports up to 100 IPsec VPN peers, 50,000 concurrent connections and 1 Gbps thoughtput.
Quick Specs
Figure 1 shows the appearance of ASA5508-K9.
Table 1 shows the Quick Specs.
|
Product Code |
ASA5508-K9 |
|
Interfaces |
8 x 1 Gigabit Ethernet interface,1 management port |
|
Stateful inspection throughput (multiprotocol) |
500 Mbps |
|
Maximum 3DES/AES VPN throughput |
175 Mbps |
|
IPsec site-to-site VPN peers |
100 |
|
Virtual interfaces (VLANs) |
50 |
|
Memory |
8GB |
|
Flash |
8GB |
|
Power (AC or DC) |
AC Only |
|
Height (rack units) |
1RU |
|
Dimensions (D x H x W) |
11.288 in x 1.72 in x 17.2 in |
|
Package Weight |
8.77 Kg |
Product Details
Figure 2 shows the front panel of ASA5508-K9.
Table 2 shows the description of Status LED on the front panel.
|
Number |
LED |
Color |
Description |
|
① |
Power |
Unlit |
Power supply off |
|
Solid Green |
Power supply on |
||
|
② |
Status |
Green |
Normal system function. |
|
Amber |
Critical alarm indicating one or more of the following: ·Major failure of a hardware or software component. ·Over-temperature condition. ·Power voltage outside the tolerance range. |
||
|
③ |
Active |
Solid Green |
Failover pair operating normally. |
|
Unlit |
Failover is not operational. |
||
|
④ |
SSD |
Unlit |
No SSD present. |
|
Green |
Activity on the drive. |
Figure 3 shows the back panel of ASA5508-K9.
Note：
|
① |
Power switch |
⑥ |
SSD LED |
|
② |
Power cord socket |
⑦ |
SSD bay |
|
③ |
Status LEDs |
⑧ |
USB port |
|
④ |
Console ports |
⑨ |
Management port |
|
⑤ |
Reset button |
⑩ |
Network data ports |
· Console ports are two serial ports, a mini USB Type B, and a standard RJ-45 (8P8C).
· Management port connects with an RJ-45 cable.
· Network data ports include eight Gigabit Ethernet RJ-45 (8P8C) network I/O interfaces.
Figure 4 shows the unboxing view of ASA5508-K9.
Figure 5 shows the accessories with ASA5508-K9.
Compare to Similar Items
Table 4 shows the comparison of ASA5506-K9, ASA5508-K9 and ASA5515-K9.
|
Models |
ASA5508-K9 |
||
|
Interfaces |
8 x 1 GE |
8 x 1 GE |
6 GE Copper |
|
Stateful Inspection Throughput (multiprotocol) |
300 Mbps |
500 Mbps |
1.2 Gbps |
|
Maximum 3DES/AES VPN Throughput |
100 Mbps |
175 Mbps |
250 Mbps |
|
Memory |
4GB |
8GB |
8GB |
|
Flash |
8GB |
8GB |
8GB |
|
Height (rack units) |
Desk Top |
1 RU |
1 RU |
Datasheet Download
Cisco ASA 5500 with FirePOWER Services Datasheet.pdf
Get more information
Do you have any question of ASA5508-K9?
Contact us now via Live Chat or [email protected].
ASA5508-K9 Specification
ASA5508-K9 Specifications |
|
|
Type |
Cisco ASA 5508-X w/ FirePOWER Services |
|
Throughput: Application Control (AVC) |
450 Mbps |
|
Throughput: Application Control (AVC) and IPS |
250 Mbps |
|
Maximum concurrent sessions |
100,000 |
|
Maximum New Connections per second |
10,000 |
|
Supported applications |
More than 3,000 |
|
URL categories |
80+ |
|
Number of URLs categorized |
More than 280 million |
|
Centralized configuration, logging, monitoring, and reporting |
Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
|
On-Device Management |
ASDM (version 7.3 or higher required) |
|
Feature |
Cisco ASA 5508-X w/ FirePOWER Services |
|
Stateful inspection throughput (maximum) |
1 Gbps |
|
Stateful inspection throughput (multiprotocol) |
500 Mbps |
|
Triple Data Encryption Standard/ |
175 Mbps |
|
Users/nodes |
Unlimited |
|
IPsec site-to-site VPN peers |
100 |
|
Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections5 |
100 |
|
Virtual interfaces (VLANs) |
50 |
|
Security contexts5(included; maximum) |
2; 5 |
|
High availability |
Active/ |
|
Integrated Wireless Access Point (See Cisco AP 702 datasheet for WiFi technical details) |
N/A |
|
Expansion slot |
N/A |
|
User-accessible Flash slot |
No |
|
USB 2.0 ports |
USB port type ‘A’, High Speed 2.0 |
|
Integrated I/O |
8 x 1GE |
|
Expansion I/O |
N/A |
|
Dedicated management port |
Yes (To be shared with FirePOWER Services), 10/100/1000 |
|
Serial ports |
1 RJ-45 and Mini USB console |
|
Solid-state drive |
80 GB mSata |
|
Memory |
8 GB |
|
System flash |
8 GB |
|
System bus |
Multibus architecture |
|
Temperature |
32 to 104°F (0 to 40 °C) |
|
Relative humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 10,000 ft (3048 m) |
|
Acoustic |
41.6 A-weighted decibels (dBA) type |
|
67.2 dBA max |
|
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4572 m) |
|
AC range line voltage |
External, 90 to 240 volts alternating current (VAC) |
|
AC normal line voltage |
91 to 240 VAC |
|
AC current |
0.25AC amps |
|
AC frequency |
50/60 Hz |
|
Dual-power supplies |
None |
|
DC domestic line voltage |
N/A |
|
DC international line voltage |
N/A |
|
DC current |
N/A |
|
Steady state |
12V @3.0A |
|
Maximum |
12V @ 5A |
|
Maximum |
123 Btu/hr |
|
Form factor |
1 rack unit (RU), 19-in. rack-mountable |
|
Dimensions (H x W x D) |
1.72 x 17.2 x 11.288 in. |
|
(4.369 x 43.688 x 28.672 cm) |
|
|
Weight (with AC power supply) |
8 lb (3 kg) |
