The 13-slot Cisco Catalyst 6513-E Switch provides high port densities that are ideal for many wiring closet, distribution, and core network as well as data center deployments with exceptional functionality and flexibility. Supervisor engine redundancy and power redundancy supporting deliver the low latency and high scalability network experience to ensure superior reliability for edging or core network. Any two Cisco Catalyst 6500E series Switches with Supervisor Engine 720-3C/720-3CXL/S2T-10G/S2T-10G-XL can be pooled together into a VSS, the Chassis delivers up to 180 Gbps per-slot bandwidth and will be capable of delivering up to 8 Tbps of system bandwidth.
● Support all Cisco Catalyst 6500 series Supervisor Engine
● 13 slots with slot 7 and 8 support supervisor engine
● Power redundancy and Supervisor Engine redundancy supporting
● Up to 720Gbps system bandwidth with Supervisor engine 720
● Up to 2 Terabit system bandwidth with supervisor engine 2T
● Up to 1.4Tbps system bandwidth in VSS with Supervisor engine 720
● Up to 4Tbps system bandwidth in VSS with supervisor engine 2T
Quick Specs
Figure 1 shows the appearance of WS-C6513-E.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C6513-E |
|
Release Date: |
11-AUG-2010 |
|
Operating Altitude: |
Certified for operation: 0 to 6500 ft (0 to 2000 m). Designed and tested for operation: -200 to 10,000 ft (-60 to 3000 m). |
|
Power Supply Compatibility: |
AC: 3000W, 4000W, 6000W, 8700W; DC: 2500W, 4000W, 6000W |
|
Operating Temperature : |
32 F to 104 F (0 to 40 C) |
|
Storage Temperature: |
-4 to 149 F (-20 to 65 C) |
|
MTBF: |
311,778 hours |
|
Maximum forwarding performance (IPv4): |
720 Mpps |
|
Slots: |
13 |
|
Max 1 GE ports: |
534 |
|
Relative Humidity: |
Ambient (noncondensing) - Operating: 5% to 90%; Nonoperating and storage: 5% to 95% |
|
Weight (fully configured): |
280 lbs (127 kg) |
|
Weight (chassis): |
102 lbs (46.3 kg) |
|
Max 10 GE ports: |
180 |
|
Max 10-100-1000 ports: |
529 |
|
Input Voltage: |
100 to 240 VAC; -48 to -60 VDC |
|
Max 40 GE ports: |
44 |
|
Rack Units: |
19 |
|
Thermal Transition: |
0.5 C per minute (hot to cold); 0.33 C per minute (cold to hot) |
|
Ports: |
8 |
Product Details
Figure 2 shows a front view of the Catalyst 6513-E switch chassis.
Note:
|
① |
Switching modules |
|
② |
Supervisor engines |
|
③ |
Redundant supervisor engines |
|
④ |
Switching modules |
The Modules, Cards, Licenses
Table 2 shows the recommended elements for the WS-C6513-E.
|
Category |
Model |
Description |
|
Cards and Modules |
Cisco 6500 Supervisor 2T VS-S2T-10G Catalyst 6500 Supervisor 2T - 2 ports 10GbE X2 - 2 ports SFP - MSFC5 PFC4 |
|
|
Cisco 6500 Supervisor 2T VS-S2T-10G-XL Catalyst 6500 Supervisor 2T 80G System XL |
||
|
Power |
Cisco WS-CAC-3000W Catalyst 6500 3000W AC power supply |
|
|
Cisco WS-CAC-4000W-INT Catalyst 6500 4000W AC PowerSupply, International (cable included) |
||
|
Fan Tray |
Catalyst 6513-E Fan Tray |
Compare to Similar Items
Table 3 shows the comparison of WS-C6509-V-E and WS-C6513-E.
|
Product Code |
WS-C6513-E |
|
|
Product Description |
Cisco Catalyst switch Enh C6513 Chassis, 13slot, 19RU, No Pow Supply, No Fan Tray |
Catalyst 6500 Enhanced 9-slot Chassis (Vertical), No PS, Fan |
Get More Information
Do you have any question about the Cisco WS-C6513-E?
Contact us now via Live Chat or [email protected].
WS-C6513-E (USED) Specification
WS-C6513-E Specification |
|
|
Number of Slots |
13 |
|
Supervisor Compatibility |
Cisco Catalyst 6500 Series Supervisor Engine 32 Cisco Catalyst 6500 Series Supervisor Engine 720-3B Cisco Catalyst 6500 Series Supervisor Engine 720-3BXL Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3C Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3CXL Cisco Catalyst 6500 Series Supervisor Engine 2T |
|
Power Supply Compatibility * Indicates EoS Power Supply |
AC: 3000W, 4000W, 6000W, 8700W DC: 2500W, 4000W, 6000W |
|
Module Compatibility |
All modules based on the software release in the system |
|
Software Compatibility (Minimum Software Version) |
|
|
With Supervisor Engine 32 |
● 12.2(33)SXI1 ● 12.2(33)SXH2 ● 12.2(18)SXF14 |
|
With Supervisor Engine 720 |
● 12.2(33)SXI1 ● 12.2(33)SXH2 ● 12.2(18)SXF14 |
|
With Supervisor Engine 720-10 GE |
● 12.2(33)SXI1 ● 12.2(33)SXH2 |
|
With Supervisor Engine 2T-10 GE |
● 15.0(1)SY |
|
Reliability and Availability Calculated Mean Time Between Failure (MTBF) |
311,778 |
|
MIBS |
Check the corresponding supervisor engine data sheet |
|
Network Management |
Check the corresponding supervisor engine data sheet |
|
Physical Dimensions |
|
|
Inches |
32.7 x 17.3 x 18.1 |
|
Centimeters |
83.0 x 43.9 x 46 |
|
Rack Units (RU) |
19 |
|
Weight |
|
|
Chassis Only (lbs) |
102 |
|
Fully Configured (lbs) |
280 |
|
Input Voltage |
100 to 240 VAC -48 to -60 VDC |
|
Safety |
UL 60950 Second Edition CAN/CSA-C22.2 No. 60950 Second Edition EN 60950 Second Edition IEC 60950 Second Edition AS/NZS 60950 |
|
EMC |
FCC Part 15 (CFR 47) Class A VCCI Class A EN55022 Class A CISPR 22 Class A CE marking AS/NZS 3548 Class A ETS300 386 EN55024 EN61000-6-1 EN50082-1 |
|
NEBS/ETSI |
GR-1089-Core NEBS Level 3 ETS 300 019 Storage Class 1.1 ETS 300 019 Transportation Class 2.3 ETS 300 019 Stationary Use Class 3.1 |
|
ATIS Pb free and Energy Efficiency |
ATIS-0600020.2010 Pb Free circuit packs ATIS-0600015-2009 General Energy Efficiency Requirements (TEER) ATIS-0600015.03-2009 Switch and Router Energy Efficiency ATIS-0600015.01-2009 Server Energy Efficiency VZ.TPR.9205 Verizon Energy Efficiency Requirements for Telecommunication Equipment (TEEER) |
|
Operating Environment |
|
|
Operating Temperature |
32°F to 104°F (0 to 40°C) |
|
Storage Temperature |
-4 to 149°F (-20 to 65°C) |
|
Thermal Transition |
0.5°C per minute (hot to cold) 0. 33°C per minute (cold to hot) |
|
Relative Humidity |
Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
|
Operating Altitude |
Certified for operation: 0 to 6500 ft (0 to 2000 m) Designed and tested for operation: -200 to 10,000 ft (-60 to 3000 m) |
