CISCO1941W-N/K9 is a wireless router, supporting 802.11 a/b/g/n and Australia, New Zealand & Singapore Compliant. The platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings.
Quick Specs
Figure 1 shows the appearance of CISCO1941W Router.
Table 1 shows the Quick Specs of the CISCO1941W-N/K9.
|
Product Code |
CISCO1941W-N/K9 |
|
Product Type |
Wireless router |
|
Compliant WLAN ISM |
Australia, New Zealand & Singapore Compliant WLAN ISM |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n (draft 2.0) |
|
Rack Units |
2 RU |
|
Interfaces |
2 integrated 10/100/1000 Ethernet ports: GE0/0&GE0/1 |
|
Expansion Slot(s) |
2 enhanced High-Speed WAN Interface Card slots 1 Internal Services Module slot |
|
RAM |
512 MB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
34.3 cm x 29.2 cm x 8.9 cm |
|
Weight |
5.8 Kg |
Product Details
Figure 2 shows front panel of CISCO1941W Router.
Note: ① antennas
Figure 3 shows the back panel of CISCO1941W Router.
Note:
|
① |
On/Off switch |
⑦ |
Compact flash 2 |
|
② |
HWIC slot 1 |
⑧ |
HWIC slot 2 |
|
③ |
Input power connector |
⑨ |
USB serial port |
|
④ |
AUX port |
⑩ |
GE 0/1 |
|
⑤ |
GE 0/0 |
⑪ |
USB ports |
|
⑥ |
Compact flash 1 |
Modularity Features
Table 2 shows recommended modules for this router.
|
Models |
Description |
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
HWIC two routed port Cisco Router High-Speed WAN Interface card |
|
|
1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco Voice/WAN Card VWIC3-1MFT-T1/E1 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-T1/E1 |
|
|
Cisco Voice&WAN T1/E1 interface moudle VWIC3-1MFT-G703 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
Compare to Similar Routers
Table 3 shows the comparison between CISCO1941/K9 and CISCO1941W-N/K9.
|
Model |
CISCO1941W-N/K9 |
|
|
Product Type |
Wired Router |
Wireless Router |
|
Compliant WLAN ISM |
N/A |
Australia, New Zealand & Singapore Compliant WLAN ISM |
|
Interface |
2 GE |
2 GE |
|
EHWIC slot |
2 |
2 |
|
ISM Slot |
1 |
1 |
|
Memory |
512 MB (installed) / 2 GB (max) |
512 MB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
256 MB (installed) / 8 GB (max) |
|
Rack Unit |
2U |
2U |
Get more information
Do you have any question about the CISCO1941W-N/K9 router?
CISCO1941W-N/K9 Specification
CISCO1941W-N/K9 Specifications |
|
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
CISCO1941W-N/K9 |
|
Compliant WLAN ISM |
Australia, New Zealand & Singapore Compliant WLAN ISM |
|
Product Type |
Wireless router |
|
Form Factor |
Desktop - modular - 2U |
|
Connectivity Technology |
Wireless, wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n (draft 2.0) |
|
Network / Transport Protocol |
IPSec, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
|
Remote Management Protocol |
SNMP, RMON, TR-069 |
|
Encryption Algorithm |
LEAP, MD5, TLS, PEAP, TKIP, WPA, WPA2 |
|
Authentication Method |
RADIUS, Extensible Authentication Protocol (EAP), EAP-FAST |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Web Services Management Agent (WSMA), NetFlow |
|
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, IEEE 802.11n (draft 2.0), ANSI T1.101, ITU-T G.823, ITU-T G.824 |
|
DRAM Memory |
512 MB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
LED Status Lights Indicators |
Link activity, power |
|
Connectivity Slots |
|
|
Router Interfaces |
1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
|
Expansion Slot(s) |
2 (total) / 2 (free) x HWIC |
|
Aerial |
|
|
Aerial |
External detachable |
|
Antenna Qty |
3 |
|
Directivity |
Omni-directional |
|
Gain Level |
2 dBi |
|
Power Supply |
|
|
Power Device |
Power supply - internal |
|
Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
|
Dimensions / Weight / Miscellaneous |
|
|
Width |
34.3 cm |
|
Depth |
29.2 cm |
|
Height |
8.9 cm |
|
Weight |
5.8 kg |
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, AS/NZS 3548 Class A, CAN/CSA C22.2 No. 60950-1, VCCI V-3, EN 61000, TIA/EIA/IS-968 |
|
System Software |
|
|
IOS Software Included |
Cisco IOS IP Base |
