The Cisco® 7201 Router is a compact, high-performance 1-rack-unit (1RU) router coupled with a broad set of interfaces and Cisco IOS® Software features, making it ideal for both service providers and enterprise applications.
Quick Spec
Figure 1 shows the appearance of CISCO7201.
Table 1 shows the quick spec.
|
Product Number |
CISCO7201 |
|
Description |
Cisco 7201 Chassis, 1GB Memory, Dual P/S, 256MB Flash |
|
Processor |
1.67-GHz Motorola Freescale 7448 processor |
|
Performance |
2,000,000 pps or more |
|
DRAM |
1 GB default (2 GB maximum) |
|
Compact Flash |
64 MB default (256 MB maximum) |
|
Dimensions (H x W x D) |
1.75 x 19 x 16.9 in. (4.44 x 48.26 x 42.93 cm) |
|
Weight |
Chassis fully configured with a port adapter ~16.5 lb (7.48 kg) |
Compare to Similar Items
Table 2 shows the comparison between CISCO7201 and CISCO7206VXR.
|
Product Number |
CISCO7201 |
|
|
Description |
Cisco 7201 Chassis, 1GB Memory, Dual P/S, 256MB Flash |
Cisco 7206 VXR, 6-slot chassis, 1 AC supply with IP software |
|
Dimensions (H x W x D) |
1.75 x 19 x 16.9 in. (4.44 x 48.26 x 42.93 cm) |
5.25 x 16.8 x 17 in.(13.34 x 42.67 x 43.18 cm) |
|
Weight |
Chassis fully configured with a port adapter ~16.5 lb (7.48 kg) |
Chassis is fully configured with a network processing engine, I/O controller, four port adapters, two power supplies, and a fan tray: ~50 lb (22.7 kg) |
Get more information
Do you have any question about the CISCO7201 router?
Contact us now via Live Chat or [email protected].
CISCO7201 (USED) Specification
CISCO7201 Specification |
|
|
Product Number |
CISCO7201 |
|
Description |
Cisco 7201 Chassis, 1GB Memory, Dual P/S, 256MB Flash |
|
Processor |
1.67-GHz Motorola Freescale 7448 processor |
|
Performance |
2,000,000 pps or more |
|
LAN ports |
4 Gigabit Ethernet ports |
|
Gigabit Ethernet Optics |
SFP • Short wave (SX) • Long wave/long haul (LX/LH) • Extended wavelength (ZX) • RJ-45 copper SFP |
|
DRAM |
1 GB default (2 GB maximum) |
|
Compact Flash |
64 MB default (256 MB maximum) |
|
Cisco IOS Software Release |
12.2(31)SB4, 12.4XD7, and 12.4PI6 |
|
Dimensions (H x W x D) |
1.75 x 19 x 16.9 in. (4.44 x 48.26 x 42.93 cm) |
|
Weight |
Chassis fully configured with a port adapter ~16.5 lb (7.48 kg) |
|
Heat Dissipation |
290 Btu/hr at 85W typical input power 512 Btu/hr at 150W maximum input power |
|
Operating Temperature |
32 to 104ºF (0 to 40ºC) |
|
Storage Temperature |
-4 to 149ºF (-20 to 65ºC) |
|
Operating Humidity |
10 to 90% non-condensing |
|
Storage Relative Humidity |
5 to 95% |
|
Operating Altitude |
60 to 2000m |
