The ASA 5525-SSD120-K9 delivers superior performance with up to 2 Gbps stateful inspection throughput, 750 IPsec VPN peers, 500,000 concurrent connections and 1 expansion slot makes it ideally suited for the small, mid-size enterprises, branch offices or internet edge deployments while delivering enterprise-strength security. It is also integrated with 120G SSD which can deploy the Firepower system and register to the FireSight Management Center to analysis, monitoring, incident prioritization and reporting so that the enterprise can better protect the business.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
ASA5525-SSD-K9 |
|
Bundle |
Integrated with 120G SSD |
|
Interfaces |
8 copper GE ports, 1 copper GE management port, 1 expansion slot |
|
Stateful inspection throughput (maximum) |
2 Gbps |
|
3DES/AES VPN throughput |
300 Mbps |
|
IPsec VPN peers |
750 |
|
Virtual interfaces (VLANs) |
200 |
|
Memory |
8 GB |
|
Flash |
8 GB |
|
Height (rack units) |
1 RU |
|
Dimensions (D x H x W) |
4.45 x 20.04 x 36.2 cm |
Product Details
Figure 1 shows the front panel of ASA5525-SSD-K9.
Figure 2 shows the back panel of ASA5525-SSD-K9.
Note：
|
① |
LEDs |
④ |
Eight Gigabit Ethernet data interfaces |
|
② |
One Console port |
⑤ |
AC Socket |
|
③ |
Two USB Ports |
⑥ |
One Management 0/0 interface |
· There are six LEDs on the back panel: POWER, ALARM, BOOT, ACTIVE, VPN, and HD.
Compare to Similar Items
Table 3 shows the comparison of ASA5525-SSD-K9 and ASA5525-K9.
|
Models |
ASA5525-SSD120-K9 |
|
|
Bundle |
Integrated With 120G SSD |
None |
|
Stateful Inspection Throughput (maximum) |
2 Gbps |
2 Gbps |
|
Next-generation firewall throughput (multiprotocol) |
650 Mbps |
650 Mbps |
|
Height (rack units) |
1 RU |
1 RU |
Get more information
Do you have any question of ASA5525-SSD120-K9?
Contact us now via Live Chat or [email protected].
ASA5525-SSD120-K9 Specification
ASA5525-SSD120-K9 Specification |
|
|
Stateful inspection throughput (maximum) |
2 Gbps |
|
Stateful inspection throughput (multiprotocol]) |
1 Gbps |
|
ASA IPS throughput |
600 Mbps |
|
Next-generation firewall throughput(multiprotocol) |
650 Mbps |
|
Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput |
300 Mbps |
|
IPsec VPN peers |
750 |
|
Cisco AnyConnect Premium VPN peers (included; maximum) |
2;750 |
|
Concurrent connections |
500,000 |
|
New connections per second |
20,000 |
|
Virtual interfaces (VLANs) |
200 |
|
Security contexts[7](included; maximum) |
2; 20 |
|
High availability |
Active/active and active/standby |
|
Expansion slot |
1 interface card |
|
User-accessible Flash slot |
0 |
|
USB 2.0 ports |
2 |
|
Integrated I/O |
8 GE copper |
|
Expansion I/O |
6 GE copper or 6 GE SFP |
|
Memory |
8 GB |
|
Dimensions (H x W x D) |
1.75 x 17.5 x 14.25 in. (4.45 x 20.04 x 36.20 cm) |
|
Weight (with AC power supply) |
22.0 lb (10 kg) |
