Introducing the Fortinet FAP-433F, a cutting-edge Indoor Wireless AP designed to provide unparalleled wireless connectivity. This tri-radio device supports 2x 802.11 a/b/g/n/ac/ax with 4x4 MIMO and a separate 1x 802.11 a/b/g/n/ac Wave 2 radio with 1x1 MU-MIMO, ensuring high-density, high-efficiency performance. External antennas enhance its flexibility in deployment, while compatibility with 802.3at PoE injectors and AC adapters guarantees easy power management. Ideal for businesses seeking robust, scalable wireless solutions.
Quick Spec
| Radio Configuration | Tri-radio (2x 802.11 a/b/g/n/ac/ax, 1x 802.11 a/b/g/n/ac Wave 2) |
| MIMO Technology | 4x4 MIMO and 1x1 MU-MIMO |
| Antennas | External |
| Power Options | 802.3at PoE injector GPI-130, AC adapter SP-FAP400-PA |
| Brand | Fortinet |
Product Features
- Tri-radio design for enhanced spectrum flexibility and capacity
- Supports the latest Wi-Fi standards (802.11ax) for superior connectivity
- High-efficiency 4x4 MIMO technology
- Includes external antennas for expanded coverage possibilities
- Flexible power options with PoE injector and AC adapter support
Product Applications
- High-density environments demanding seamless wireless access
- Businesses requiring robust, reliable connectivity for multiple devices
- Scenarios needing flexible deployment options and external antenna support
Supported Options
| 802.3at PoE Injector | GPI-130 |
| AC Adapter | SP-FAP400-PA |
| Antenna Types | External, Various Models Supported |
Compare to Similar Items
| Fortinet FAP-231F | Dual-radio, 802.11ac Wave 2, No external antenna option |
| Fortinet FAP-431F | Tri-radio, 802.11 a/b/g/n/ac, 4x4 MIMO, no 802.11ax support, external antennas |
| Fortinet FAP-441E | Quad-radio, including one dedicated scanning radio, 802.11ax support, internal antennas |
Get more information
To explore how the Fortinet FAP-433F can elevate your network infrastructure, feel free to reach out through Live Chat or email us at [email protected]. We��re here to assist with any queries regarding the product and its application in your setup.
FAP-433F Specification
FAP-433F Specifications | |
| Brand | Fortinet |
| Product Name | FAP-433F |
| Type | Indoor Wireless AP |
| Wireless Specifications | Tri-radio (2x 802.11 a/b/g/n/ac/ax, 4x4 MIMO and 1x 802.11 a/b/g/n/ac Wave 2, 1x1 MU-MIMO) |
| Antennas | External antennas included |
| Power Options | 802.3at PoE injector GPI-130 or AC adapter SP-FAP400-PA |
| Frequency Bands Supported | Dual-band operation with auto-sensing 2.4GHz & 5GHz |
| Max Data Rate | 2.4GHz: up to 600 Mbps, 5GHz: up to 4.8 Gbps |
| MIMO | 4x4 MIMO for 802.11 a/b/g/n/ac/ax, 1x1 MU-MIMO for 802.11 a/b/g/n/ac Wave 2 |
| Security Features | WPA-3, WPA2, AES, TKIP, EAP-TLS, EAP-TTLS, PEAP, SIM, AKA, 802.1X |
| Management | Cloud, on-premises, and hybrid management options |
| Maximum Clients | Supports up to 512 clients |
| Number of Radios | 3 |
| Network Interface | 1x Gigabit Ethernet port |
| Mounting Options | Ceiling mount, Wall mount (kits included) |
| Operating Temperature | -10�� C to 50�� C (14�� F to 122�� F) |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (WxDxH) | Without mount: to be confirmed |
| Compliance | FCC, CE, IC, and others |
| Features | Advanced RF management, Spectrum analysis, Airtime fairness, Band steering |
| Warranty | Limited lifetime |
