Cisco Catalyst 2960X-48TD-L LAN Base stackable Layer 2 switch provides enterprise-class access for campus and branch applications. It is comprised of 48 Ethernet 10/100/1000 ports and 2 x 10G SFP+ uplink interfaces.
Quick Specs
Figure 1 shows the front view of the Cisco 2960X-48TD-L switch.
Table 1 shows the Quick Spec of the Cisco 2960X-48TD-L switch.
|
Product Code |
WS-C2960X-48TD-L |
|
Enclosure Type |
Rack-mountable - 1U |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 10G SFP+ |
|
Ports |
48 x Ethernet 10/100/1000 Gigabit ports |
|
Maximum stacking number |
8 |
|
Stack bandwidth |
80G |
|
Forwarding Bandwidth |
108Gbps |
|
Switching Bandwidth |
216Gbps |
|
RAM |
512MB |
|
Flash Memory |
128MB |
|
Dimensions |
44.5 cm x 27.9 cm x 4.5 cm |
|
Package Weight |
9.19 Kg |
Product Details
Figure 2 shows the front panel of the Cisco Catalyst 2960X-48TD-L switch.
Note:
① Ethernet management port ⑥ SFP module ports
② Mode button ⑦ 48 x 10/100/1000 ports
③ Switch LEDs ⑧ CONSOLE LED
④ USB mini-Type B (console) port ⑨ MGMT LED
⑤ USB Type A ports ⑩ RJ-45 console port
·The Switch LEDs include SYST, STAT, SPEED, RPS, MAST, and STACK LEDs.
Figure 3 shows the back panel of the Cisco Catalyst 2960X-48TD-L switch.
Note:
① FlexStack-Plus module slot and cover ③ RPS Connector
② Fan Exhaust ④ AC power connector
Figure 4 shows the stackable capacity.
This C2960X switch delivers stackable capacity that supports up to 8 switches stacking with same 2960-X LAN base series. It also can stack up to 4 switches stacking when mixed with 2960-S LAN base series switches.
The Accessories
Table 2 shows some accessories of the WS-C2960X-48TD-L.
|
Models |
Description |
|
Catalyst 2960-X FlexStack Plus Stacking Module |
|
|
Cisco FlexStack Stacking Cables |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
|
|
Console Cable 6 ft with USB Type A and mini-B |
Get more information
Do you have any question about the Cisco Catalyst C2960X-48TD-L switch?
Contact us now via Live Chat or [email protected].
WS-C2960X-48TD-L Specification
WS-C2960X-48TD-L Specification |
|
|
General |
|
|
model info: |
WS-2960X-48TD-L |
|
enclosure type |
Rack-mountable - 1U |
|
Ports |
48 x 10/100/1000 + 2 x 10G SFP+ |
|
Network management Interface |
10/100 Mbps Ethernet (RJ-45) |
|
Available PoE Power |
None |
|
Forwarding bandwidth(Gbps) |
108Gbps |
|
Maximum stacking number |
8 |
|
Stack Bandwidth |
80G |
|
Forwarding Performance |
130.9Mpps |
|
Switching bandwidth |
216Gbps |
|
Maximum active VLANs |
1023 |
|
MAC Address Table Size |
16K (default) |
|
CPU |
APM86392 600MHz dual core |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Status Indicators |
Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, and link speed |
|
Expansion / Connectivity |
|
|
Console ports |
USB (Type-B), Ethernet (RJ-45) |
|
Stacking cable |
Optional |
|
Power Redundancy |
Option (PWR-RPS2300) |
|
Voltage range (Auto) |
110V-240V |
|
Power Consumption Operational |
0.049KVA |
|
Miscellaneous |
|
|
Width |
17.5 Inches (44.5 cm) |
|
Depth |
11 Inches (27.9 Cm) |
|
Height |
1.75 Inches (4.5 cm) |
|
Package Weight |
20.26 Pounds (9.19Kg) |
|
Weight |
9.6 Pounds (4.3Kg) |
|
Rack Mounting Kit |
optional |
|
MTBF in hours |
445,460 |
|
Compliant Standards |
|
|
System software / license |
|
|
System software |
IOS LAN BASE |
|
license |
NERGY-MGT-100-K9, EW-DO-100-DE |
|
features |
● IEEE 802.1D Spanning Tree Protocol ● IEEE 802.3u 100BASE-TX ● IEEE 802.3ab 1000BASE-T ● IEEE 802.3z 1000BASE-X ● RMON I and II standards ● SNMP v1, v2c, and v3 ● IEEE 802.3az ● IEEE 802.1ax |
|
Network security |
|
|
Management and Troubleshooting |
|
|
Environmental Ranges |
|
|
Operating temperature up to 5000 ft (1500 m) |
23ºF to 113ºF |
|
Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF |
|
Short-term exception at sea level* |
23ºF to 131ºF |
|
Short-term exception up to 5000 feet (1500 m)* |
23ºF to 122ºF |
|
Short-term exception up to 10,000 feet (3000 m)* |
23ºF to 113ºF |
|
Short-term exception up to 13,000 feet (4000 m)* |
23º to 104ºF |
|
Storage temperature up to 15,000 feet (4573 m) |
-13º to 158ºF |
|
Operating altitude |
Up to 10,000 feet |
|
Storage altitude |
Up to 13,000 feet |
|
Operating relative humidity |
10% to 95% noncondensing |
|
Storage relative humidity |
10% to 95% noncondensing |
