Cisco ASA 5500 Series IPS Solution provides intrusion prevention, firewall, and VPN in a single, easy-to-deploy platform. Intrusion prevention services enhance firewall protection by looking deeper into the flows to provide protection against threats, including worms, Trojans, distributed denial of service, reconnaissance, and exploits against application and OS vulnerabilities. The intrusion prevention capabilities of the ASA 5500 Series IPS Solution are delivered using a hardware-accelerated intrusion prevention module, the Cisco ASA Advanced Inspection and Prevention Security Services Module (AIP-SSM).
ASA5510-AIP20SP-K9 (USED) Specification
| ASA5510-AIP20SP-K9 data sheet | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | ASA5510-AIP20SP-K9 |
| Product Type | Security appliance |
| Height (Rack Units) | 1U |
| Approximate Width | 17.5 in |
| Depth | 13.2 in |
| Height | 1.7 in |
| Weight | 20.1 lbs |
| Bundled with | Cisco Advanced Inspection and Prevention Security Services Module 20 (AIP-SSM-20) |
| Processor / Memory / Storage | |
| RAM Installed ( Max ) | 1 GB |
| Flash Memory Installed (Max) | 256 MB |
| Networking | |
| Form Factor | Rack-mountable |
| Ports Qty | 5 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet |
| Network / Transport Protocol | IPSec |
| Performance | Firewall throughput : 300 Mbps Firewall throughput + anti-x services : 150 Mbps VPN throughput : 170 Mbps |
| Capacity | IPSec VPN peers : 250 SSL VPN peers : 2 Concurrent sessions : 50000 |
| Features | Firewall protection, VPN support, VLAN support |
| Encryption Algorithm | Triple DES, AES |
| Connectivity Slots | |
| Expansion Slot(s) | 1 (total) / 0 (free) x expansion slot |
| Interfaces | 5 x network - Ethernet 10Base-T/100Base-TX - RJ-45 1 x management - Ethernet 10Base-T/100Base-TX - RJ-45 1 x management - console - RJ-45 1 x serial - auxiliary - RJ-45 2 x Hi-Speed USB - 4 pin USB Type A |
| Miscellaneous | |
| Compliant Standards | CE, CISPR 22 Class A, EN 60950, EN 61000-3-2, UL 1950, VCCI Class A ITE, IEC 60950, EN 61000-3-3, CSA 22.2 No. 950, EN55022 Class A, AS/NZS 3260, AS/NZ 3548 Class A, FCC Part 15 |
| Power Supply | |
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V ( 47 - 63 Hz ) |
| System software | |
| Software Included | Cisco IOS Security Plus |
