Huawei's next-generation NetEngine AR6000 series enterprise routers use high-performance multi-core processors and a nonblocking switching structure, helping to deliver higher forwarding performance than the industry average. The NetEngine AR6000 also integrates functions such as SD-WAN, routing, switching, VPN, security, and MPLS, ensuring diversified and cloud-based services are fully supported.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
AR6140-16G4XG |
|
Processor |
16-core, 1.85 GHz |
|
Memory |
4 GB |
|
Flash |
1 GB |
|
Micro SD card (default sd1) |
Not supported |
|
Hard disk |
Not supported |
|
Dimensions (H x W x D)
|
• With no rack-mounting bracket installed: 44.4 mm x 442.0 mm x 424.0 mm (1.75 in. x 17.40 in. x 16.69 in.), 1U height • With rack-mounting brackets installed: 44.4 mm x 482.6 mm x 572.5 mm (1.75 in. x 19.00 in. x 22.54 in.), 1U height |
|
Processor |
16-core, 1.85 GHz |
|
Memory |
4 GB |
|
Maximum input current |
3 A |
|
Maximum output power |
150 W |
|
RPS power supply |
Not supported |
|
PoE power supply |
Not supported |
Product Details
Figure 1 shows the front panel of Huawei AR6140-16G4XG.
Note：
|
① |
RST button |
④ |
WAN interface: four 10GE optical interface |
|
② |
LAN interfaces: twelve GE electrical interfaces |
⑤ |
Console interface |
|
③ |
WAN interfaces: four GE electrical interfaces |
⑥ |
USB interface 2.0 (host) |
Figure 2 shows the back panel of Huawei AR6140-16G4XG.
1. RESET button NOTE:This button is used to reset the router.
If needed, you can run the factory-configuration prohibit command in the system view to disable the function of restoring the factory settings by holding down the RESET button. To enable this function again, run the undo factory-configuration prohibit command. | 2. LAN interfaces: twelve GE electrical interfaces | 3. WAN interfaces: four GE electrical interfaces |
4. WAN interface: four 10GE optical interface | 5. Console interface | 6. USB interface 2.0 (host) |
7. Ground point | 8. Product model silkscreen | 9. Four SIC slots |
10. Two power module slots Applicable power modules: 150W AC Power Module |
Compare to Similar Items
Table 2 shows the comparison.
|
Product Code |
AR6140-16G4XG |
|
|
Processor |
16-core |
4-Core |
|
Memory |
4 GB |
2 GB |
|
Flash |
1 GB |
1 GB |
|
Dimensions (H x W x D)
|
• With no rack-mounting bracket installed: 44.4 mm x 442.0 mm x 424.0 mm (1.75 in. x 17.40 in. x 16.69 in.), 1U height • With rack-mounting brackets installed: 44.4 mm x 482.6 mm x 572.5 mm (1.75 in. x 19.00 in. x 22.54 in.), 1U height |
• With no rack-mounting bracket installed: 44.5 mm x 442 mm x 420 mm • With rack-mounting brackets installed: 44.5 mm x 482.6 mm x 572.5 mm
|
|
Rated input voltage range (AC) |
100 V to 240 V, 50 Hz/60 Hz |
100 V to 240 V, 50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
90 V to 264 V, 47 Hz to 63 Hz
|
|
Maximum input current |
3 A |
3 A |
|
Maximum output power |
150 W |
150W |
|
Typical power consumption |
60 W |
18W |
|
Maximum power consumption |
96.8 W |
32W |
|
Fans |
Built-in, unpluggable fans |
Built-in, unpluggable fans |
|
Airflow (facing the front panel) |
Left to right |
Left to right |
AR6140-16G4XG Specification
AR6140-16G4XG Specification |
|
|
System Parameters |
|
|
Processor |
16-core, 1.85 GHz |
|
Memory |
4 GB |
|
Flash |
1 GB |
|
Micro SD card (default sd1) |
Not supported |
|
Hard disk |
Not supported |
|
Dimensions (H x W x D)
|
• With no rack-mounting bracket installed: 44.4 mm x 442.0 mm x 424.0 mm (1.75 in. x 17.40 in. x 16.69 in.), 1U height • With rack-mounting brackets installed: 44.4 mm x 482.6 mm x 572.5 mm (1.75 in. x 19.00 in. x 22.54 in.), 1U height |
|
Power specifications |
|
|
Rated input voltage range (AC) |
100 V to 240 V, 50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
|
Maximum input current |
3 A |
|
Maximum output power |
150 W |
|
RPS power supply |
Not supported |
|
PoE power supply |
Not supported |
|
Power consumption (empty chassis) |
|
|
Typical power consumption |
60 W |
|
Maximum power consumption |
96.8 W |
|
Heat dissipation |
|
|
Fans |
Built-in, unpluggable fans |
|
Airflow (facing the front panel) |
Left to right |
|
Interface density |
|
|
Management interface |
1 (RJ45) |
|
CON/AUX interfaces |
1 (RJ45) |
|
USB 3.0 interface |
1 |
|
Service interfaces (standard configuration)
|
LAN interfaces: twelve GE electrical interfaces WAN interfaces: four GE electrical interfaces and four 10GE optical interfaces |
|
Extended slots
|
4 x SIC 2 x WSIC |
|
Environment parameters |
|
|
Operating temperature |
0°C to 45°C (32°F to 113°F) |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Operating relative humidity |
5% to 95%, non-condensing |
|
Operating altitude |
< 5000 m (16404.2 ft.) |
|
Software Features and Protocols |
|
|
Basic function
|
DHCP server/client/relay, PPPoE server/client, NAT, and sub-interface management |
|
LAN |
IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, VLAN aggregation, MAC management, STP |
|
WLAN (AC)
|
AP management (AC discovery, AP access, and AP management), CAPWAP, WLAN user management, WLAN radio management (802.11a/b/g/n/ac), WLAN QoS (WMM), WLAN security (WEP, WPA, WPA2, key management) |
|
IPv4 unicast routing |
Routing policies, static routes, RIP, OSPF, IS-IS, BGP |
|
IPv6 unicast routing
|
Static routes, routing policies, RIPng, OSPFv3, IS-ISv6, BGP4+ |
|
Basic IPv6 function
|
IPv6 ND, IPv6 PMTU, IPv6 FIB, IPv6 ACL, ICMPv6, DNSv6, DHCPv6 |
|
IPv6 tunneling |
Manual tunnel, automatic tunnel, GRE tunnel, IPv6 over IPv4 tunnel, 6 to 4 tunnel, ISATAP |
|
Multicast
|
IGMP v1/v2/v3, PIM-SM, PIM-DM, MSDP, MBGP, IPv6 PIM, MLD |
|
MPLS |
LDP, MPLS L3 VPN, VLL, PWE3, static LSP, dynamic LSP, MPLS TE, IP FRR, LDP FRR, TE FRR |
|
VPN |
IPsec VPN, GRE VPN, DSVPN, A2A VPN, L2TP VPN, L2TPv3 VPN |
|
QoS
|
DiffServ mode, MPLS QoS, priority mapping, traffic policing (CAR), traffic shaping, congestion avoidance, congestion management, MQC (traffic classifier, traffic behavior, and traffic policy), hierarchical QoS, Smart Application Control (SAC) |
|
Security
|
ACL (v4/v6), domain-based stateful firewall, 802.1X authentication, MAC address authentication,portal authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, PKI,broadcast storm suppression, ARP security, ICMP attack defense, URPF, CPCAR, blacklist, attack source tracing, online behavior management, IPS, URL filtering |
|
Management and maintenance
|
Upgrade management, device management, web-based network management, GTL, SNMP (v1/v2c/v3), RMON, NTP, CWMP, Auto-Config, URL-based/USB-based/DHCP deployment, NETCONF/YANG, CLI, NetStream, IP FPM, TCP FPM, TWAMP, IP accounting, NQA |
|
Safety and Regulatory Standards |
|
|
EMC standards compliance |
CISPR32 Class A EN 55032 Class A CISPR24 EN 55024 ETSI EN 300 386 AS/NZS CISPR32 Class A FCC Part 15 Subpart B Class A ICES 003 Class A IEC 61000-3-2 EN 61000-3-2 IEC 61000-3-3 EN 61000-3-3 GB 9254 VCCI-CISPR32 Class A |
|
Environmental standards compliance |
RoHS REACH WEEE |
|
Safety standards compliance
|
IEC 60950-1 EN 60950-1 UL 60950-1 CSA C22.2 No 60950-1 GB 4943.1 |
