HPE MSA 2050 SAN DC-power LFF Storage.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
Q1J79A |
|
Description |
MSA 2050 San DC Power LFF Storage |
|
Product Model |
2050 |
|
Product Type |
SAN Storage System |
|
Number of Controllers |
2 |
|
Controller Type |
Serial Attached SCSI (SAS) |
|
Number of Total Expansion Bays |
12 |
|
Number of Hard Drives Supported |
12 |
|
Total Hard Drive Capacity Supported |
120 TB |
|
Number of Solid State Drive Supported |
12 |
|
Form Factor |
Rack-mountable |
|
Rack Height |
2U |
Get more information
Do you have any question about the Q1J79A?
Contact us now via Live Chat or [email protected].
Q1J79A Specification
Q1J79A Specification | |
| General | |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 2U |
| Chassis | |
| Installed Devices / Modules Qty | 0 |
| Supported Devices / Modules Qty | 12 |
| Supported Drives | SAS-2 |
| Storage | |
| Max Supported Capacity | 120 TB |
| Maximum LUNs | 512 |
| Storage Controller | |
| Type | 2 x RAID (iSCSI) |
| Interface Type | SAS 6Gb/s |
| Data Transfer Rate | 600 MBps |
| Cache / Buffer Size (Max) | 8 GB |
| RAID Level | RAID 1, RAID 5, RAID 6, RAID 10 |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) - 2.5 SFF |
| Interfaces | 4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel ¦ 2 x mini-USB 2.0 (management) ¦ 2 x Ethernet 1000Base-T (management) - RJ-45 ¦ 2 x SAS |
| System Requirements | |
| OS Required | HP-UX, SuSe Linux, Apple MacOS X, Microsoft Windows, Red Hat Enterprise Linux, HP OpenVMS, Microsoft Windows Server 2012, VMware ESXi 5.x, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, VMware ESXi 6.x |
| Miscellaneous | |
| Features | Systems Insight Manager (SIM) |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55022, GS, EN55024, CCC, FCC Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, EN61000-3-2, EN61000-3-3, CNS 13438 Class A, ICES-003:2004 Class A |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
| Power | |
| Power Device | 2 x internal power supply - hot-plug |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | DC -40 -75 V |
| Power Consumption Operational | 432 Watt |
| Dimensions & Weight | |
| Width | 29 in |
| Depth | 26 in |
| Height | 11 in |
| Weight | 57.98 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Sound Emission | 55 dBA |
