CISCO3945E-SEC/K9 is the Cisco 3945E router with Security Bundle w/SEC license PAK. The Cisco router 3945E, supporting Modular Services Performance Engine (SPE) 250, delivers highly secure data, voice, video, and application services to large branch offices.
Quick Specs
Figure 1 shows the appearance of the CISCO 3945E router for reference.
Table 1 shows the Quick Specs.
|
Product Code |
CISCO3945E-SEC/K9 |
|
Bundle |
Cisco 3945E Security Bundle w/SEC license PAK |
|
Services Performance Engine module |
w/SPE 250 |
|
Rack Units |
3U |
|
Interfaces |
4 integrated 10/100/1000 Ethernet ports with 2 SFP ports |
|
Expansion Slot(s) |
4 service module slots 3 Enhanced High-Speed WAN Interface Card slots 3 onboard digital signal processor (DSP) slots |
|
RAM |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
13.3 x 43.8 x 47.6 cm |
Product Details
Figure 2 shows the front panel of the CISCO 3945E router for reference..
Note:
|
① |
② |
③ |
|
On/Off switch |
Power connector |
LEDs area |
Figure 3 shows the back panel of the Cisco 3945E router with slots and ports.
Note:
|
① |
EHWIC 0,1, and 2 (0, far right) |
⑦ |
SFP 1 and SFP 2 (1, Top) |
|
② |
USB serial port |
⑧ |
USB 0 and USB 1 (1, Left) |
|
③ |
AUX port |
⑨ |
Ground |
|
④ |
RJ-45 serial console port |
⑩ |
Service module slots |
|
⑤ |
10/100/1000 Ethernet ports (GE 0/3, Top; GE 0/2, Bottom) |
⑪ |
Compact flash 0 and 1 (0, right) |
|
⑥ |
10/100/1000 Ethernet ports (GE 0/1, Top; GE 0/0, Bottom) |
Figure 4 shows the security bundle features.
Modularity Features
Table 2 shows modules for this router.
|
Models |
Description |
|
Cisco Services Performance Engine 250 for Cisco 3945E router. (It's a configured item in the CISCO3945E/K9.) |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
16-channel high-density voice DSP module |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
1GB USB Flash Token |
|
|
Licenses |
Description |
|
Cisco 3900 Router License - FL-39-SNA= SNA E-Delivery License for Cisco 3925/3945 for Cisco 3900 Series |
|
|
Cisco Application Experience License ISR 3900 series - includes licenses for: AppX, DATA and WAASX. |
|
|
Cisco 3900 License L-SL-39-UC-K9 Unified Communication E-Delivery PAK for Cisco 3900 Series |
Compare to Similar Routers
Table 3 shows the comparison.
|
Model |
CISCO3945E-SEC/k9 |
|
|
Bundle |
No |
Cisco 3945E Security Bundle w/SEC license PAK |
|
SPE |
w/SPE 250 |
w/SPE 250 |
|
Interface |
4GE |
4GE |
|
EHWIC slots |
3 |
3 |
|
SM slots |
4 |
4 |
|
ISM slots |
0 |
0 |
|
DSP |
3 |
3 |
|
SFP |
2 |
2 |
|
Rack Unit |
3U |
3U |
Get more information
Do you have any question about the CISCO3945E-SEC/k9?
CISCO3945E-SEC/K9 Specification
CISCO3945E-SEC/K9 Specification |
|
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
CISCO3945E-SEC/K9 |
|
Bundle |
Cisco 3945E Security Bundle w/SEC license PAK |
|
Form Factor |
Desktop - modular - 3U |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Capacity |
Cisco Unified Communications Manager Express sessions : 450 Cisco Unified SRST sessions : 1500 |
|
Network / Transport Protocol |
IPSec, PPPoE, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR) |
|
Remote Management Protocol |
SNMP, RMON |
|
Encryption Algorithm |
SSL |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
|
DRAM Memory |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
LED Status Lights Indicators |
Link activity, power |
| Connectivity Slots | |
|---|---|
|
Router Interfaces |
WAN : 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 Management : 1 x console - RJ-45 Management : 1 x console - mini-USB Type B Serial : 1 x auxiliary - RJ-45 USB : 2 x 4 pin USB Type A 2 x SFP (mini-GBIC) |
|
Expansion Slots Total (Free) |
3 ( 3 ) x EHWIC 3 ( 3 ) x PVDM 2 ( 1 ) x CompactFlash Card 4 ( 4 ) x service module (SM) |
| Power Supply | |
|
Power Device |
Power supply - internal |
|
Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Dimensions / Weight / Miscellaneous | |
|
Approximate Width |
18.7 in |
|
Depth |
17.2 in |
|
Height |
5.2 in |
|
Weight |
39 lbs |
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438, NEBS |
| System software | |
|
IOS Software Included |
Cisco IOS Security |
