The Lenovo Think System SR550 dual-socket 2U rack server is ideal for small to large organizations that need industry-leading reliability, management, and security, as well as cost-optimized performance, storage capacity, and flexible I/O. Designed to handle a wide range of workloads, the SR550 server cost-effectively performs complex analytics on structured and unstructured data, speeds transactional systems, and powers through collaboration workloads with ever-growing data sets and large files shared within an organization.
Quick Specs
Table 1 shows the Quick Specs.
|
Product name |
LENOVO SR550 INTEL 4208/16G/NO DISK/SUPPORT 8X3.5" DISK/ RAID530I/0GB CACHE/2X1G/550W |
|
Form Factor/Height |
2U rack server |
|
Number of Processors |
1(Up to 2) |
|
Processor |
1x4208 Intel 8C 2.1GHz |
|
Memory |
16G DIMMs |
|
Expansion Slots |
Up to six slots. |
|
Hard Disk |
8X3.5/530i |
|
Power |
550W |
|
Optical drive bays |
None. Support for an external USB DVD RW Optical Disk Drive |
Product Details
The Lenovo SR550 servers provides these features:
① Cost-efficient performance
② Flexible storage
③ Empowering IT management
Compare to Similar Items
Table 2 shows the comparison.
|
Product |
LENOVO SR550 INTEL 4208/16G/NO DISK/SUPPORT 8X3.5" DISK/ RAID530I/0GB CACHE/2X1G/550W |
LENOVO SR550 INTEL 4210/16G/NO DISK/SUPPORT 8X3.5" DISK/RAID530I/0GB CACHE/2X1G NIC/550W |
|
Processor |
1x Intel 4208 8C 2.1GHz |
1x Intel 4210 10C 2.2GHz |
|
Hard Disk |
8x3.5, 530i |
8x3.5, 530i |
|
Number of Processors |
1 (Up to two Intel Xeon Bronze, Silver, Gold, or Platinum processors) |
1 (Up to two Intel Xeon Bronze, Silver, Gold, or Platinum processors) |
|
Memory |
16GB (Up to 768GB) |
16GB (Up to 768GB) |
|
Expansion Slot(s) |
Up to six |
Up to six |
Get More Information
Do you have any question about the LENOVO SR550 INTEL 4208/16G/NO DISK/SUPPORT 8X3.5" DISK/ RAID530I/0GB CACHE/2X1G/550W?
Contact us now via Live Chat or [email protected].
Lenovo SR550 Intel 4208/16G/No disk/Support 8x3.5" Disk/ RAID530i/0GB cache/2x1G/550W Specification
Lenovo SR550 Servers Specification |
|
|
Form Factor/Height |
2U rack/server |
|
Processors |
Up to 2 second-generation Intel® Xeon® Platinum processor, up to 125W |
|
Memory |
Up to 768GB in 12x slots, using 64GB DIMMs; 2666MHz / 2933MHz TruDDR4 |
|
Expansion Slots |
Up to 6x PCIe 3.0 (with 2x processors) via multiple riser options (PCIe-only or PCIe + ML2) |
|
Drive Bays |
Up to 16x hot-swap 2.5" or 12x hot-swap 3.5” or 8x simple-swap 3.5"; plus up to 2x mirrored M.2 boot (optional RAID 1) |
|
HBA/RAID Support |
Software RAID standard (up to 8 ports); up to 16-port HBAs/or HW RAID with flash cache |
|
Security and Availability Features |
Lenovo ThinkShield, TPM 1.2/2.0; PFA; Hot-swap/redundant drives and PSUs; front-access diagnostics via dedicated USB port; optional redundant cooling |
|
Network Interface |
2x 1GbE ports + 1x dedicated 1GbE management port (standard); 1x optional 10GbE LOM |
|
Power |
2x hot-swap/redundant (Energy Star 2.1): 550W/750W 80 PLUS Platinum; or 750W 80 PLUS Titanium |
|
Systems Management |
XClarity Controller, XClarity Administrator, XClarity Integrator plugins, and XClarity Energy Manager |
|
OSes Supported |
Microsoft, SUSE, Red Hat, VMware |
|
Limited Warranty |
1-year and 3-year customer replaceable unit and onsite service, next business day 9x5 |
