Aruba 2530 Series Gigabit Ethernet devices are enterprise class, fully managed, Layer 2 edge switches delivering cost effective, reliable, and secure connectivity for business networks. Designed for entry level to midsize enterprise networks, these Gigabit Ethernet switches deliver full Layer 2 capabilities with enhanced access security, traffic prioritization, and IPv6 host support. This J9774A has 8 x 10/100/1000 PoE+ ports with a power budget of 67W. Additionally the switch has two Gigabit 10/100/1000 dual personality shared with two SFP ports.
Quick Spec
Table 1 shows the quick spec.
|
Product Code |
J9774A |
|
Type |
Aruba 2530-8G-PoE+ Switch |
|
Ports |
· 8 × RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only · 2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-Tx; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) · 1 dual-personality (RJ-45 or USB micro-B) serial console port. |
|
Switching capacity |
20 Gb/s |
|
PoE power |
67 W |
|
Minimum dimensions (W x D x H) |
25.4 x 15.95 x 4.45 cm (10 x 6.28 x 1.75 in) (1U height) |
|
Weight |
1 kg (2.2 lb) |
Product Details
Figure 1 shows the front panel of HPE Aruba J9774A.
Note:
|
① |
Console Port |
|
② |
8 × RJ-45 autosensing 10/100/1000 PoE+ ports |
|
③ |
2 × dual-personality ports |
Figure 2 shows the back panel of HPE Aruba J9774A.
Note:
|
① |
DC power connector |
Compare to Similar Items
Table 2 shows the comparison.
|
Product Code |
J9774A |
||
|
Type |
Aruba 2530-8G-PoE+ Switch |
Aruba 2530-8G Switch |
Aruba 2530-48-PoE+ Switch |
|
Ports |
· 8 × RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only · 2 × dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-Tx; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) · 1 dual-personality (RJ-45 or USB micro-B) serial console port. |
· 8 × RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;1000BASE-T: full only. · 2 × dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-Tx; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) ports. · 1 dual-personality (RJ-45 or USB micro-B) serial console port. |
· 48 × RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+); Media Type: Auto-MDIX; Duplex: half or full · 2 × autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only · 2 × fixed Gigabit Ethernet SFP ports · 1 dual-personality (RJ-45 or USB micro-B) serial console port. |
|
Switching capacity |
20 Gb/s |
20 Gb/s |
17.6 Gb/s |
|
PoE capability |
67W |
N/A |
382 W |
Get more information
Do you have any question about the J9774A?
Contact us now via Live Chat or [email protected].
J9774A Specification
J9774A Specifications |
|
| Model | J9774A |
| Port Type | 8 x 10/100/1000 PoE+ RJ-45 |
| Power Over Ethernet (PoE) | Yes (PoE+) |
| Switching Capacity | 20 Gbps |
| Power Consumption | 86 W (maximum) |
| Heat dissipation | 65 BTU/hr (68.58 kJ/hr) |
| PoE capability | 67 W |
| Throughput | up to 14.8 Mpps |
| Quality of Service (QoS) | Yes |
| Input voltage | 100 - 127 / 200 - 240 VAC, rated |
| Rack Mountable | Yes |
| Fanless | No |
| Minimum dimensions ( H x W x D) | 25.4 x 15.95 x 4.45 cm |
| Operating Temperature | 0°C to 45°C |
| Humidity | 15% to 95% non-condensing |
