N9K-C9332C is the Nexus 9332C ACI Spine switch with 32p 40/100G QSFP28, 2p 1/10G SFP. The Cisco Nexus 9332C is the smallest form-factor 1-Rack-Unit (1RU) spine switch for Cisco ACI that supports 6.4 Tbps of bandwidth and 2.3 bpps across 32 fixed 40/100G QSFP28 ports and 2 fixed 1/10G SFP+ ports. Breakout is not supported on ports 1 to 32. The last 8 ports marked in green support wire-rate MACsec encryption.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
N9K-C9332C |
|
Physical |
● 32-port 40/100G QSFP28 ports & 2-port 1/10G SFP+ ports ● 1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2) ● Hot-swappable, 5 fans with redundancy ● System memory: 16 GB ● SSD: 256GB ● USB: 1 port ● RS-232 serial console ports: 1 ● Management ports: 2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP+) ● Broadwell-DE CPU: 4 cores |
|
Physical (H x W x D) |
1.7 x 17.3 x 22.9 in. (4.4 x 43.9 x 58.1 cm) |
|
Weight (chassis) |
25.1lb (11.4kg) with power supplies and fans, 19 lb (8.6kg) without power supplies and fans |
The Accessories
Table 2 shows the supported accessories.
|
Model |
Description |
|
Nexus 9300 Fan 3, Port-side Intake |
|
|
Nexus 9300 Fan 3, Port-side Exhaust |
|
|
Nexus Fan, 160CFM, port side intake airflow |
|
|
Nexus Fan, 160CFM, port side exhaust airflow |
|
|
Nexus Fan, 35CFM, port side intake airflow |
|
|
Nexus Fan, 35CFM, port side exhaust airflow |
|
|
Nexus 9300 1200W AC PS, Port-side Intake |
|
|
Nexus 9300 1200W AC PS, Port-side Exhaust |
|
|
Nexus 1100W AC PS, Port-side Exhaust |
|
|
Nexus 1100W AC PS, Port-side Intake |
|
|
Nexus 1200W AC PS, Port-side Exhaust |
|
|
Nexus 1200W AC PS, Port-side Intake |
|
|
Nexus 1200W, 200-277AC,240-380DC, Dual airflow PSU |
|
|
930W -48V DC PS, Port-side Exhaust |
|
|
930W -48V DC PS, Port-side Intake |
|
|
Nexus 930W -48V DC PS, Port-side Exhaust |
|
|
Nexus 930W -48V DC PS, Port-side Intake |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Code |
N9K-C9332C |
|
|
Physical |
● 36-port 40G QSFP ports ● 1200 watt (W) AC power supplies or 930W DC power supplies (up to 2) ● 80 Plus Platinum-rated power supplies that provide at least 90% efficiency with 20% utilization ● Hot-swappable, dual fan trays with redundant fans ● Port-side intake or Port side exhaust airflow direction ● System memory: 16GB ● SSD: 64GB ● USB: 2 ports ● RS-232 serial console ports: 1 ● Management ports: 1 x 10/100/1000BASE-T |
● 32-port 40/100G QSFP28 ports & 2-port 1/10G SFP+ ports ● 1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2) ● Hot-swappable, 5 fans with redundancy ● System memory: 16 GB ● SSD: 256GB ● USB: 1 port ● RS-232 serial console ports: 1 ● Management ports: 2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP+) ● Broadwell-DE CPU: 4 cores |
|
Physical (H x W x D) |
3.5 x 17.5 x 22.5 in. (8.9 x 44.5 x 57.1 cm) |
1.7 x 17.3 x 22.9 in. (4.4 x 43.9 x 58.1 cm) |
|
Weight (chassis) |
34.4 lb |
25.1lb (11.4kg) with power supplies and fans, 19 lb (8.6kg) without power supplies and fans |
Get More Information
Do you have any question about the Cisco N9K-C9332C?
Contact us now via Live Chat or [email protected].
N9K-C9332C Specification
N9K-C9332C Specification |
|
|
Physical |
● 32-port 40/100G QSFP28 ports & 2-port 1/10G SFP+ ports ● 1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2) ● Hot-swappable, 5 fans with redundancy ● System memory: 16 GB ● SSD: 256GB ● USB: 1 port ● RS-232 serial console ports: 1 ● Management ports: ● Broadwell-DE CPU: 4 cores |
|
Power and Cooling |
● Power: 1100W AC, 1100 DC or 1100W HVAC/HVDC ● Input voltage: 100 to 240V* AC or -40V to -72V DC (min‑max), -48V to -60V DC (nominal) *Supports input voltage of 100-120V for a max output of 800W; 200-240V for a max output of 1200W ● Frequency: 50 to 60 Hz (AC) ● Efficiency: 90% or greater ● RoHS compliance: Yes ● Hot swappable: Yes ● Port-side intake or port-side exhale options ● Typical power: 296W (AC) ● Maximum power: 700W (AC) |
|
Environmental |
● Physical (H x W x D): 1.7 x 17.3 x 22.9 in. (4.4 x 43.9 x 58.1 cm) ● Weight: 25.1lb (11.4kg) with power supplies and fans, 19 lb (8.6kg) without power supplies and fans ● Operating temperature: 32 to 104°F (0 to 40°C) ● Nonoperating (storage) temperature: -40 to 158°F (-40 to 70°C) ● Humidity: 5 to 85% (noncondensing) ● Altitude: 0 to 13,123 ft (0 to 4000m) |
|
Acoustics |
● Fan speed at 50%: 76.4 dBA ● Fan speed at 70%: 83.3 dBA ● Fan speed at 100%: 92.1 dBA |
|
MTBF |
● 363,500 hours |
