Cisco Catalyst compact switches easily extend an intelligent, fully managed Cisco Catalyst wired switching infrastructure, including end-to-end IP and Borderless Network services, with a single Ethernet cable or fiber from the wiring closet. WS-C2960CPD-8PT-L is one of Cisco Catalyst 2960 compact series switches. It offers two 1G (PoE+ input) uplinks and eight 10/100 Fast Ethernet PoE ports.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960CPD-8PT-L |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 1G (PoE+ input) |
|
Ports |
8 x 10/100 Fast Ethernet |
|
PoE Output Ports |
8 PoE |
|
Available PoE Power |
Up to 30.8W |
|
Forwarding Bandwidth |
10 Gbps |
|
RAM |
128 MB |
|
Flash Memory |
64 MB |
|
Dimensions |
4.44 x 26.9 x 17.2 cm |
|
Package Weight |
3.37 Kg |
Product Details
Figure 1 shows the front panel of WS-C2960CPD-8PT-L.
Note:
|
① |
Mode Button |
⑤ |
System LEDs |
|
② |
USB Type A port |
⑥ |
8 x 10/100 Fast Ethernet PoE ports |
|
③ |
USB mini-Type B (console) port |
⑦ |
2 x 1G (PoE+ input) uplinks |
|
④ |
RJ-45 console port |
The Accessories
Table 2 shows some recommended cables and SFP modules.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
1000BASE-BX SFP, 1490NM |
|
|
1000BASE-BX SFP, 1310NM |
|
|
100BASE-FX SFP for FE port |
|
|
100BASE-LX SFP for FE port |
|
|
100BASE-BX10-D SFP |
|
|
100BASE-BX10-U SFP |
Compare to similar item
Table 3 shows the comparison between WS-C2960CPD-8TT-L and WS-C2960CPD-8PT-L.
|
Models |
WS-C2960CPD-8PT-L |
|
|
Uplinks |
2 x 1G (PoE+ input) |
2 x 1G (PoE+ input) |
|
Ports |
8 x 10/100 Fast Ethernet |
8 x 10/100 Fast Ethernet |
|
Available PoE Power |
N/A |
8 PoE Output Ports, Up to 30.8W |
|
Feature set |
LAN Base |
LAN Base |
Get more information
Do you have any question about the WS-C2960CPD-8PT-L?
Contact us now via Live Chat or [email protected].
WS-C2960CPD-8PT-L (USED) Specification
WS-C2960CPD-8PT-L Specification |
|
|
Manufacturer: |
Cisco |
|
Product ID: |
WS-C2960CPD-8PT-L |
|
Product Description: |
2960C PoE Switch 8 FE, 2 x 1G Uplink, LAN Base |
|
Product Type: |
Ethernet Switch |
| Marketing Information | |
|---|---|
|
The Cisco Catalyst 3560-C and 2960-C Series compact switches are small form-factor Gigabit Ethernet and Fast Ethernet switches designed for deployments outside the wiring closet. Enterprise and commercial customers can deliver advanced security services, unified communications, wireless, IP video cameras, and other applications for the office workspace, branch office, classroom, cruise ship, and other wiring-constrained environments. |
|
| Interfaces/Ports | |
|
Total Number of Network Ports: |
8 |
|
Token Ring Port: |
No |
|
LRE Port: |
No |
|
Uplink Port: |
2 |
|
USB: |
Yes |
|
Number of RJ-45 Ports: |
8 |
| Media & Performance | |
|
Ethernet Technology: |
Gigabit Ethernet |
|
Network Technology: |
10/100/1000Base-T |
| I/O Expansions | |
|
Number of Total Expansion Slots: |
2 |
|
Expansion Slot Type: |
RJ-45 |
|
Shared SFP Slot: |
No |
|
Number of SFP Slots: |
No |
| Network & Communication | |
|
Layer Supported: |
2 |
| Management & Protocols | |
|
Manageable: |
Yes |
|
Management: |
|
| Memory | |
|
Standard Memory: |
128 MB |
|
Memory Technology: |
DRAM |
|
Flash Memory: |
64 MB |
| Power Description | |
|
PoE (RJ-45) Port: |
Yes |
|
Input Voltage: |
110 V AC 220 V AC |
|
Power Source: |
Power Supply |
| Physical Characteristics | |
|
Form Factor: |
Rack-mountable Desktop Wall Mountable |
|
Height: |
4.44 cm |
|
Width: |
26.9 cm |
|
Depth: |
17.2 cm |
|
Package Weight |
3.37 Kg |
