Cisco Catalyst Switch C6880-X Chassis with fixed configuration. The Cisco Catalyst 6880-X Series offers primary features and benefits, including:
● Platform Scalability: The platform supports up to 220Gbps slot capacity per port-card. It supports up to 2Tbps of switching capacity, which doubles up to 4Tbps with VSS technology.
● Security: Support for Cisco TrustSec (CTS), to provide IEEE 802.1AE MACsec encryption and role-based ACL, CoPP to prevent DoS attacks and Cisco ISE to safeguard and manage end-to-end security for the enterprise.
● Virtualization: Comprehensive suite of Virtualization features including L2/L3 VPN, full MPLS, EVN, VRF aware applications for NAT Netflow, GRE for v4/v6, L2 extensions with VPLS etc. to segment different user groups and serve unique security/QoS policy requirements of each of these diverse user groups.
● Application Visibility and Control (AVC): Supports enhanced application monitoring such as Flexible and Sampled NetFlow for intelligent and scalable application monitoring.
● Smart Operations: The Cisco Catalyst 6880-X supports Catalyst Instant Access*, which allows an Instant Access Client to act as a remote line card of the Cisco Catalyst 6880-X, as well as Smart Install Director, which provides zero-touch deployment of access switches.
● High Availability: Two Cisco Catalyst 6880-X Series Switches can be combined into a VSS. In addition to high-availability VSS, provides ease of operation by providing a single point of management, eliminating the need for First Hop Routing Protocol (FHRP) and removing the reliance on Spanning Tree Protocol (STP) for link failure restoration.
* Support of Catalyst Instant Access is available on 15.1(2) SY2 and later releases.
Quick Specs
Figure 1 shows the appearance of C6880-X.
Table 1 shows the Quick Specs.
|
Product Code |
C6880-X |
|
Number of port card slots |
4 |
|
Switching Capacity |
Up to 2Tbps |
|
Inches |
8.75x 17.35 x 23 |
|
Centimeters |
22.23 X 44.07 X 58.42 |
|
Rack units (RU) |
4.85 |
The Modules, Cards, Licenses
Table 2 shows the recommended elements for the C6880-X.
|
Category |
Model |
Description |
|
SFP 10G Options
|
10GBASE-SR SFP Module, Enterprise-Class |
|
|
Cisco 10GBASE-ZR SFP10G Module for SMF |
||
|
10GBASE-LR SFP+ Module for SMF 10 Gbps |
||
|
GLC Options |
1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM |
|
|
1000BASE-BX SFP, 1490NM |
||
|
Line Cards
|
Cisco Catalyst 6880-X Multi Rate Port Card (XL Tables) More |
|
|
Accessories
|
Console Cable 6ft with RJ45 and DB9F |
Compare to Similar Items
Table 3 shows the comparison of C6880-X and C6880-X-LE.
|
Attribute |
C6880-X |
|
|
MAC entries |
128K |
128K |
|
Routes |
256K (IPv4) 128K (IPv6) |
2048K (IPv4) 1024K (IPv6) |
|
ACL entries |
64K shared for QoS/Security |
256K shared for QoS/Security |
|
NetFlow entries |
512K (per module slot) Up to 2.5M per system |
1024K (per module slot) Up to 5M per system |
|
Multicast routes |
128K (IPv4) 128K (IPv6) |
128K (IPv4) 128K (IPv6) |
|
IPv4 routing |
In hardware Up to 300 Mpps** |
In hardware Up to 300 Mpps** |
|
IPv6 routing |
In hardware Up to 150 Mpps** |
In hardware Up to 150 Mpps** |
|
L2 bridging |
In hardware Up to 300 Mpps** |
In hardware Up to 300 Mpps** |
|
Jumbo frame support |
Up to 9216 bytes (For bridged and routed pkts.) |
Up to 9216 bytes (For bridged and routed pkts.) |
|
VLAN |
4K |
4K |
|
Bridge domains |
16K |
16K |
|
MPLS |
In hardware (up to 8192 VRFs at 300 Mpps**) |
In hardware (up to 8192 VRFs at 300 Mpps**) |
|
Logical interfaces |
128K |
128K |
|
EtherChannel hash |
8 bits |
8 bits |
|
VPLS |
In hardware (up to 150 Mpps**) |
In hardware (up to 150 Mpps**) |
|
GRE |
In hardware (up to 150 Mpps**) |
In hardware (up to 150 Mpps**) |
|
NAT |
Hardware assisted |
Hardware assisted |
|
Onboard memory |
2GB*** |
4GB |
|
Ingress buffers |
1.25MB per 10G port in 2:1 mode 2.5MB per 10G port in 1:1 mode (10MB per Port ASIC) |
1.25MB per 10G port in 2:1 mode 2.5MB per 10G port in 1:1 mode (10MB per Port ASIC) |
|
Egress buffers |
24MB per 10G port in 2:1 mode 48MB per 10G port in 1:1 mode (192MB per MUX FPGA) |
24MB per 10G port in 2:1 mode 48MB per 10G port in 1:1 mode (192MB per MUX FPGA) |
|
Oversubsription |
16P 10G at 2:1 in oversubscription mode (default) for base module and port cards 8P 10G at 1:1 in performance mode (configurable) for base module and port cards |
|
Get more information
Do you have any question about the C6880-X?
Contact us now via Live Chat or [email protected].
C6880-X Specification
C6880-X Specification |
|
|
QoS Features and Scalability |
|
|
Feature |
C6880-X |
|
Layer-3 classification and marking access control entries (ACEs) |
256K shared for QoS/Security |
|
Aggregate traffic rate-limiting policers |
16,348 |
|
Flow-based rate-limiting method; number of rates |
Per source address, destination address, or full flow; 64 rates |
|
Layer 2 rate limiters |
20 ingress/6 egress |
|
MAC ACLs featuring per-port/per VLAN granularity |
Yes |
|
Distributed policers |
Yes |
|
Shared uFlow policers |
Yes |
|
Egress uFlow policers |
Yes |
|
Packet or byte policers |
Yes |
|
Per port per VLAN |
Yes |
|
COS and DSCP based Queue mapping |
Yes |
|
Deficit Weighted Round Robin Scheduler (DWRR) and Weighted Random Early Detection Scheduler (WRED) |
Yes |
|
Receive and Transmit Queues |
Default: 1p7q4t Configurable: 2p6q4t |
|
Security Features and Scalability |
|
|
Port security |
Yes |
|
IEEE 802.1x and 802.1x extensions |
Yes |
|
VLAN and router ACLs and port ACLs |
Yes |
|
1:1 mask ratio to ACE values |
Yes |
|
Security ACL entries |
256K shared for QoS/Security |
|
CPU rate limiters (DoS protection) |
57 |
|
uRPF check (IPv4/IPv6) |
Up to 16 |
|
Number of interfaces with unique ACL |
16k |
|
RPF interfaces |
16 |
|
Private VLANs |
Yes |
|
MAC ACLs on IP |
Yes |
|
Layer 2 and Layer 3 Cisco TrustSec (Security Group Tagging & Security Group Access Control List) |
Yes |
|
IEEE 802.1ae (MACsec) Layer 2 encryption in hardware |
Yes |
|
CPU HW rate limiters by PPS or BPS |
Yes |
|
CoPP for multicast |
L2 and L3 support |
|
CoPP for exceptions (MTU, TTL) |
Yes |
|
CoPP exceptions NetFlow support |
Yes |
|
ACL labels |
16K |
|
Port ACL |
8K |
|
ACL dry run |
Yes |
|
Hitless ACL changes |
Yes |
|
MPLS and Virtualization Features |
|
|
VSS* |
Yes |
|
Label imposition/disposition (MPLS-PE), swapping (MPLS‑P) |
Yes |
|
Label Distribution Protocol (LDP) |
Yes |
|
MPLS VPN |
Yes |
|
VRF Lite |
Yes |
|
EVN |
Yes |
|
QoS mechanisms using experimental (EXP) bits |
Yes |
|
MPLS-RSVP-TE |
Yes |
|
MPLS differentiated services (diffserv)-aware traffic engineering (MPLS-DS-TE) |
Yes |
|
MPLS traceroute |
Yes |
|
EoMPLS |
Yes |
|
EoMPLS tunnels |
16k |
|
IPv4 and IPv6 in IPv6 tunneling |
Yes |
|
IPv6 in IPv4 tunnelling (Intra-Site Automatic Tunnel Addressing Protocol [ISATAP], 6to4, GRE |
Yes |
|
QoS support for uniform, short pipe and pipe mode tunnel |
Yes |
|
Native VPLS in HW |
Yes |
|
Native L2 over multipoint GRE |
Yes |
|
VRF-aware operational contexts |
Yes |
|
VPN NetFlow support |
Yes |
|
VPN aware NAT |
Yes |
|
VRF-lite scalability |
VLAN reuse per subinterface |
|
Per VPN interface statistics |
Yes |
|
Netflow and Multicast Features |
|
|
Netflow support in hardware |
Yes |
|
Flexible Netflow |
Yes |
|
Sampled Netflow |
Yes |
|
Ingress/Egress Netflow |
Yes |
|
Ingress and Egress replication in hardware |
Yes |
|
IGMPv3 snooping in hardware |
Yes |
|
IPv6 MLDv2 snooping in hardware |
Yes |
|
PIM registers in hardware |
Yes |
|
Label Switched Multicast (LSM) |
Yes |
|
Base System Scalability |
|
|
MAC entries |
128K |
|
Routes |
2048K (IPv4) 1024K (IPv6) |
|
ACL entries |
256K shared for QoS/Security |
|
NetFlow entries |
1024K (per module slot) Up to 5M per system |
|
Multicast routes |
128K (IPv4) 128K (IPv6) |
|
IPv4 routing |
In hardware Up to 300 Mpps** |
|
IPv6 routing |
In hardware Up to 150 Mpps** |
|
L2 bridging |
In hardware Up to 300 Mpps** |
|
Jumbo frame support |
Up to 9216 bytes (For bridged and routed pkts.) |
|
VLAN |
4K |
|
Bridge domains |
16K |
|
MPLS |
In hardware (up to 8192 VRFs at 300 Mpps**) |
|
Logical interfaces |
128K |
|
EtherChannel hash |
8 bits |
|
VPLS |
In hardware (up to 150 Mpps**) |
|
GRE |
In hardware (up to 150 Mpps**) |
|
NAT |
Hardware assisted |
|
Onboard memory |
4GB |
|
Ingress buffers |
1.25MB per 10G port in 2:1 mode 2.5MB per 10G port in 1:1 mode (10MB per Port ASIC) |
|
Egress buffers |
24MB per 10G port in 2:1 mode 48MB per 10G port in 1:1 mode (192MB per MUX FPGA) |
|
Software Packaging |
|
|
Software License |
● IP Services ● Advanced Enterprise Services |
|
Software compatibility |
15.1(2)SY1 and later releases* |
