Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server

Brands: Dell

(0 reviews)

﷼ 11183.82 12426.47 10% Off

Model: pe_t630_1023

Detail: Fully Customizable: Intel® Xeon® E5-2603 v4, Optional Operating System, 4GB Memory, 1TB Hard Drive, SAS, H330 and a 3 Year Warranty

Categories: Servers / Dell Tower Server
Tags:

Dell PowerEdge T630 Server drives a wide range of demanding workloads with a flexible server offering peak 2-socket performance and huge internal storage capacity. This model is the Dell PowerEdge T630 server with Intel® Xeon® E5-2603 v4 processor, Optional Operating System, 4GB Memory, 1TB Hard Drive, SAS, H330 and a 3 Year Warranty.

Quick Specs

Table 1 shows the quick spec.

Product Model	Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server
Product Series	Dell PowerEdge T630 Server
Fully Customizable	Intel® Xeon® E5-2603 v4, Optional Operating System, 4GB Memory, 1TB Hard Drive, SAS, H330 and a 3 Year Warranty
Processor	Intel® Xeon® E5-2603 v4 1.7GHz,15M Cache,6.4GT/s QPI,6C/6T (85W) Max Mem 1866MHz
Operating System	No Operating System
Memory	4GB RDIMM, 2400MT/s, Single Rank, x8 Data Width
Hard Drive	1TB Hard Drive
RAID Controllers	Internal: PERC S130 PERC H330 PERC H730 PERC H730P External: PERC H830
Chassis	Form Factor: 5U Height 443.5 mm (17.5 inch) with feet 434.5 mm (17.1 inch) without feet Width:48.2cm (18.98”) Depth:75.09cm (29.56”) Max Weight: T630 full system with 2.5” HDD: Max 2.5"x16 (6 fans) 37.57Kg/82.75lb Max 2.5"x32 (6 fans) 40.55Kg/89.32lb T630 full system with 3.5” HDD: Max 3.5"x18 (6 fans) 49.65 Kg/109.36 lb

Product Details

Figure 1 shows the front and back panel description of Dell PowerEdge T630 Server.

Front Panel (2.5 inch hot-swap hard-drive chassis For References):

①	SD vFlash card slot	⑥	Information tag
②	power button	⑦	iDRAC Direct port
③	NMI button and System identification button	⑧	USB connector
④	LCD menu buttons	⑨	Optical drive or tapedrive bay
⑤	LCD panel	⑩	2.5 in Physical drives

Note：This supports 3.5 inch hot-swap hard-drive chassis, which provides 4 Flex Bays and 8 3.5-inch hard drives on the front panel.

Back Panel:

①	PCIe expansion card slots (3) (processor 1)	⑥	Serial connector
②	System identification connector and System identification button	⑦	Full-height PCIe expansion card slots (processor 2)
③	iDRAC Enterprise port	⑧	Ethernet connectors
④	USB port(6)	⑨	Power supply
⑤	Video connector	⑩	Power supply

Compare to Similar Item

Table 2 shows the comparison.

Product Model	Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server	Dell PowerEdge T630 Xeon E5-2620 v4 8GB 1TB SAS H330 Tower Server
Product Series	Dell PowerEdge T630 Server	Dell PowerEdge T630 Server
Processor	Intel® Xeon® E5-2603 v4 1.7GHz,15M Cache,6.4GT/s QPI,6C/6T (85W) Max Mem 1866MHz	Intel® Xeon® E5-2620 v4 2.1GHz,20M Cache,8.0GT/s QPI,Turbo,HT,8C/16T (85W) Max Mem 2133MHz
Operating System	No Operating System	No Operating System
Memory	4GB RDIMM, 2400MT/s, Single Rank, x8 Data Width	8GB RDIMM, 2400MT/s, Single Rank, x8 Data Width

Dell Server Configuration

Table 3 shows the Dell T630 Server Configuration. You can contact us to order a T630 server according to this guide.

Model	PowerEdge T630
Description	Drive a wide range of demanding workloads with a flexible server offering peak 2-socket performance and huge internal storage capacity
Processor	Intel® Xeon® processor E5 2600 v4 product family
Memory	Up to 1.5TB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s
PCI Slots	Slot 1: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector) Slot 2: Full Length, Full Height, PCH - PCIe Gen2 x4 (x8 connector) Slot 3: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector) Slot 4: Half Length, Full Height, CPU2 - PCIe Gen3 x8 (x8 connector) Slot 5: Full Length, Full Height, CPU2 - PCIe Gen2 (DMI) x4 (x8 connector) Slot 6: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector) Slot 7: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector) Slot 8: Half Length, Full Height, CPU1 - PCIe Gen3 x8 (x8 connector)
Network Controller	2 X 1GbE
Storage	SAS, SATA, Near-line SAS, SSD, PCIe SSD Up to 4 optional Express Flash PCIe SSDs Up to 144TB via 18 x 8TB 3.5” HDDs

Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server Specification

Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server Specification
Product Series	Dell PowerEdge T630 Server
Model	Dell PowerEdge T630 Xeon E5-2603 v4 4GB 1TB SAS H330 Tower Server
Fully Customizable	Intel® Xeon® E5-2603 v4, Optional Operating System, 4GB Memory, 1TB Hard Drive, SAS, H330 and a 3 Year Warranty
Processor	Intel® Xeon® E5-2603 v4 1.7GHz,15M Cache,6.4GT/s QPI,6C/6T (85W) Max Mem 1866MHz
Operating System	No Operating System
Memory	4GB RDIMM, 2400MT/s, Single Rank, x8 Data Width
Hard Drive	1TB Hard Drive
Warranty	3 Year Basic Hardware Warranty Repair, 5X10 HW-Only, 5x10 NBD On-site
Chipset	Intel C610 series chipset
Embedded Hypervisor (Optional)	Microsoft® Windows Server® 2008, with Hyper-V® VMware® ESXi Citrix XenServer
Storage	SAS, SATA, Near-line SAS, SSD, PCIe SSD Up to 4 optional Express Flash PCIe SSDs Up to 144TB via 18 x 8TB 3.5” HDDs
Drive Bays	Internal hard drive bay and hot-plug backplane: Up to 8 x 3.5” SAS, SATA, Near-Line SAS,SSD, PCIe SSD drives with optional flex bay Up to 18 x 3.5” SAS, SATA, Near-Line SAS,SSD drives without optional flex bay Up to 16 x 2.5” SAS, SATA, Near-line SAS, SSD, PCIe SSD drives with optional flex bay Up to 32 x 2.5” SAS, SATA, Near-Line SAS,SSD drives with optional flex bay
Slots	Slot 1: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector) Slot 2: Full Length, Full Height, PCH - PCIe Gen2 x4 (x8 connector) Slot 3: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector) Slot 4: Half Length, Full Height, CPU2 - PCIe Gen3 x8 (x8 connector) Slot 5: Full Length, Full Height, CPU2 - PCIe Gen2 (DMI) x4 (x8 connector) Slot 6: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector) Slot 7: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector) Slot 8: Half Length, Full Height, CPU1 - PCIe Gen3 x8 (x8 connector)
RAID Controllers	Internal: PERC S130 PERC H330 PERC H730 PERC H730P External: PERC H830
Network Controller	2 x 1Gb
Communications	Broadcom® 5719 quad-port 1Gb NIC Broadcom 5720 dual-port 1Gb NIC Broadcom 57810 dual-port 10Gb DA/SFP+ CNA Broadcom 57810 dual-port 10Gb Base-T network adapter Intel® Ethernet I350 dual-port 1Gb server adapter Intel Ethernet I350 quad-port 1Gb server adapter Intel Ethernet X540 dual-port 10GBASE-T server adapter Mellanox® ConnectX®-3 dual-port 10Gb Direct Attach/SFP+ server network adapter Mellanox ConnectX-3 dual-port 40Gb Direct Attach/QSFP server network adapter Emulex® LPE 12000, single-port 8Gb Fibre Channel HBA Emulex LPE 12002, dual-port 8Gb Fibre Channel HBA Emulex LPe16000B, single-port 16Gb Fibre Channel HBA Emulex LPe16002B, dual-port 16Gb Fibre Channel HBA Emulex OneConnect OCe14102-U1-D 2-port PCIe 10GbE CNA QLogic® 2560, single-port 8Gb Optical Fibre Channel HBA QLogic 2562, dual-port 8Gb Optical Fibre Channel HBA Qlogic 2660, single-port 16GB, Fibre Channel HBA, full height Qlogic 2662, dual-port 16GB, Fibre Channel HBA, full height
Power	Titanium efficiency 750W AC power supply Gold efficiency 1100W DC power supply Platinum efficiency 495W, 750W, 1100W or 1600W AC power supply
Availability	ECC memory Hot-plug hard drives Hot-plug redundant cooling Hot-plug redundant power iDRAC8 Internal Dual SD Module Single Device Data Correction (SDDC) Spare Rank Tool-less chassis Support for high availability clustering and virtualization Proactive systems management alerts iDRAC8 with Lifecycle Controller
Graphics Card	Video Type :Integrated Integrated Matrox G200 with iDRAC8 Video Memory: 16 MB shared with iDRAC8 application memory GPUs – Support for up to four optional 300W internal GPU processing accelerators
Chassis	Form Factor: 5U Height 443.5 mm (17.5 inch) with feet 434.5 mm (17.1 inch) without feet Width:48.2cm (18.98”) Depth:75.09cm (29.56”) Max Weight: T630 full system with 2.5” HDD: Max 2.5"x16 (6 fans) 37.57Kg/82.75lb Max 2.5"x32 (6 fans) 40.55Kg/89.32lb T630 full system with 3.5” HDD: Max 3.5"x18 (6 fans) 49.65 Kg/109.36 lb
Management	Dell OpenManage portfolio of systems management solutions, including: OpenManage Essentials console iDRAC8 with Lifecycle Controller
