Cisco Catalyst 6500/7600 Series ASA Service module WS-SVC-ASA-SM1-K9 provides the seamless integration of Cisco Catalyst 6500 Series switch and Cisco 7600 Series router to offer unmatched security, reliability and performance in a single blade. The ASA Services Module makes it easy to add full firewall capabilities to an existing infrastructure by sliding a blade into an empty slot in an existing Catalyst 6500 Series switch or Cisco 7600 Series router - no additional rack space, cabling, power, or physical interface is required. WS-SVC-ASA-SM1-K9 helps data centers increase effectiveness and efficiency in protecting their networks and applications, it also works in tandem with other modules in the chassis to deliver robust security throughout the entire chassis, effectively making every port a security port.
WS-SVC-ASA-SM1-K9 (USED) Specification
| Model info: | WS-SVC-ASA-SM1-K9 | |
| Product Description | Cisco Catalyst 6500 / 7600 Series ASA Services Module WS-SVC-ASA-SM1-K9 | |
| Devide Tyde | Cisco Catalyst 6500/7600 ASA Service moulde | |
| Maximum firewall throughput | 20 Gbps | |
| Multiprotocol firewall throughput | 16 Gbps | |
| Concurrent connections | 10,000,000 | |
| Connections per second | 300,000 | |
| Maximum 3DES/AES VPN throughput | 2 Gbps | |
| Maximum site-to-site and IPsec IKEv1 client VPN user sessions | 10,000 | |
| Maximum AnyConnect or clientless VPN user sessions | 10,000 | |
| Cisco Cloud Web Security users | 7500 | |
| Capacities | ||
| Security contexts | 5, 10, 20, 50, 100, 250 licenses (2 included) | |
| Cards per switch | 4 ASA Services Modules per Catalyst 6500 or Cisco 7600 Series chassis | |
| VLANs | 1,000 | |
| High availability | Active/Active, Active/Standby | |
| NAT translations | 10 million | |
| Transparent mode VLANs | 16 pairs | |
| Access control entries | 2 million | |
| Supervisor engines supported | ● 6500 Series Supervisor Engine 2T and Supervisor Engine 720 Systems | ● 7600 Series Supervisor Engine 2T, Supervisor Engine 720 and Route Switch Processor 720 Systems |
| System requirement | ||
| Catalyst 6500-E Switch | ||
| ASA release version 8.5(1) and later IOS version 12.2(33)SXJ2 and later |
● VS-S720-10G-3C ● VS-S720-10G-3CXL |
● WS-SUP720-3B ● WS-SUP720-3BXL |
| ASA release version 8.5(1.7) and later IOS version 15.0(1)SY1 and later |
● VS-S2T-10G ● VS-S2T-10G-XL |
|
| Catalyst 7600 Series Router | ||
| Cisco 7606-S, 7609-S ASA release version 9.0(1) and later IOS version 15.2(4)S2 and later |
● RSP720-3C-10GE ● RSP720-3CXL-10GE ● RSP720-3C-GE |
● RSP720-3CXL-GE ● WS-SUP720-3B ● WS-SUP720-3BXL |
| Cisco 7604, 7609-S, 7613-S ASA release version 9.0(1) and later IOS version 15.1(1)SY and later |
● VS-S2T-10G ● VS-S2T-10G-XL |
|
| Module licenses | ● ASA 5500 5 Security Contexts License: ASA5500-SC-5 ● ASA 5500 10 Security Contexts License: ASA5500-SC-10 ● ASA 5500 20 Security Contexts License: ASA5500-SC-20 ● ASA 5500 50 Security Contexts License: ASA5500-SC-50 |
● ASA 5500 100 Security Contexts License: ASA5500-SC-100 ● ASA 5500 250 Security Contexts License: ASA5500-SC-250 ● ASA 5500 GTP/GPRS Inspection License: ASA5500-GTP |
