C6800-48P-SFP is Catalyst 6800 48-Port 1GE Fiber Module with Integrated DFC4. This C6800-48P-SFP is similar with the C6800-48P-SFP=. The C6800-48P-SFP= is a spare one.
Quick Specs
Figure 1 shows the appearance of C6800-48P-SFP.
Table 1 shows the Quick Specs.
|
Product Code |
C6800-48P-SFP |
|
Product Type |
6800 Series 1 Gigabit Modules |
|
Port connector type |
LC (optical) or RJ-45 (copper) depending on the SFP transceiver installed |
|
Ports/Interface/ |
48 port; 1000BASE-SX, LX/LH, -ZX, -T; 1000BASE-CWDM; LC connecter |
|
Port Density/ |
·240 ports/ C6807-XL ·528 ports/ 6513E ·384 ports/ 6509E |
|
Maximum Frame Size |
Up to 9216 bytes/frame |
|
Queues per Port (Tx = Transmit, Rx = Receive) |
·Tx-1p3q8T ·Rx-2q8T |
|
Scheduler |
Deficit Weighted Round Robin (DWRR) |
|
Buffer Size per Port |
·Rx-166KB ·Tx-1.17MB |
|
Onboard Memory |
1GB Default |
|
Power Requirements |
334.44 and 339.44 Watts respectively |
|
Backplane connection |
Connects to the switch fabric using dual full-duplex 20-Gbps switch fabric channels (40 Gbps total). |
|
Chassis/slot support |
Can occupy slots 1-2 and 5-7 in C6807-XL chassis. Can occupy any slots in |
|
Supervisor engine |
Compatible with Supervisor Engine 2T and Supervisor Engine 2TXL. |
|
Distributed forwarding and performance |
Comes equipped with DFC4 or DFC4XL daughter cards, delivering optimal performance up to a sustained 60 Mpps for L2, IPv4 and MPLS forwarding and 30 Mpps for IPv6 forwarding. |
|
Dimensions (H x W x D) |
1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. |
|
Weight |
9.03 lb (4.1 kg) |
Product Details
Figure 2 shows the front panel of C6800-48P-SFP.
Note:
|
① |
Odd numbered ports |
|
② |
Even numbered ports |
The Accessories
Table 2 shows the recommended elements for the C6800-48P-SFP.
|
Category |
Model |
Description |
|
GLC Options
|
1000BASE-BX SFP, 1310NM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
||
|
1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
Compare to Similar Items
Table 3 shows the comparison of C6800-48P-SFP and C6800-48P-TX.
|
Product Code |
C6800-48P-SFP |
|
|
Description |
48-port SFP fiber Gigabit Ethernet Module with DFC4 |
48-port Copper Gigabit Ethernet Module with DFC4 |
|
Ports/Interface/ |
48 port; 1000BASE-SX, LX/LH, -ZX, -T; 1000BASE-CWDM; LC connecter |
48-port, RJ-45, 100m, Category 5 cable |
|
Maximum Frame Size |
Up to 9216 bytes/frame |
Up to 9216 bytes/frame |
|
Queues per Port (Tx = Transmit, Rx = Receive) |
·Tx-1p3q8T ·Rx-2q8T |
·Tx-1p3q8t; Rx‑2q8t |
|
Buffer Size per Port |
·Rx-166KB ·Tx-1.17MB |
·Rx-166KB ·Tx-1.17MB |
|
Power Requirements |
334.44 and 339.44 Watts respectively |
405 and 410 Watts respectively |
Get More Information
Do you have any question about the Cisco C6800-48P-SFP?
Contact us now via Live Chat or [email protected].
C6800-48P-SFP Specification
C6800-48P-SFP Specification |
|
|
Dimensions (H x W x D) |
1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. |
|
Weight |
9.03 lb (4.1 kg) |
|
Operating temperature |
Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) |
|
Humidity (RH) ambient (noncondensing) |
10 to 90 percent |
|
Operating altitude |
Certified for operation: 0 to 6500 ft (0 to 2000 m) Designed and tested for operation: -200 to 10,000 ft (-60 to 3000 m) |
