Cisco introduces the Cisco Catalyst 6509 Enhanced Vertical Chassis as part of the Cisco Catalyst 6500 Series of enhanced (E-Series) switches, delivering chassis with up to 1440 Gbps of system bandwidth capacity (80 Gbps/slot), enhanced cable management, and front-to-back airflow optimized for hot aisle/cold aisle designs in data center and service provider colocation (NEBS-L3 compliant) deployments.
Quick Specs
Figure 1 shows the appearance of WS-C6509-V-E.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C6509-V-E |
|
Bandwidth Capacity per Slot |
80 Gbps |
|
System Bandwidth Capacity |
1440 Gbps |
|
Cable Management |
Category 5e, Category 6, Category 6a and fiber |
|
Supported Maximum System Power |
14500W |
|
Standby Fabric Hot Sync (Supervisor Engine Switchover) |
50 ms |
|
Number of EoBC Channels |
2 |
The Modules, Cards, Licenses
Table 2 shows the recommended elements for the WS-C6509-V-E.
|
Category |
Model |
Description |
|
Cards and Modules |
Cisco 6500 Supervisor 2T VS-S2T-10G Catalyst 6500 Supervisor 2T - 2 ports 10GbE X2 - 2 ports SFP - MSFC5 PFC4 |
|
|
Cisco 6500 Supervisor 2T VS-S2T-10G-XL Catalyst 6500 Supervisor 2T 80G System XL |
||
|
Power |
Cisco WS-CAC-3000W Catalyst 6500 3000W AC power supply |
|
|
Cisco WS-CAC-4000W-INT Catalyst 6500 4000W AC PowerSupply, International (cable included) |
||
|
Fan Tray |
Catalyst 6509-V-E Fan Tray |
Compare to Similar Items
Table 3 shows the comparison of WS-C6509-V-E and WS-C6513-E.
|
Product Code |
WS-C6509-V-E |
|
|
Product Description |
Cisco Catalyst switch Enh C6513 Chassis, 13slot, 19RU, No Pow Supply, No Fan Tray |
Catalyst 6500 Enhanced 9-slot Chassis (Vertical), No PS, Fan |
Get More Information
Do you have any question about the Cisco WS-C6509-V-E?
Contact us now via Live Chat or [email protected].
WS-C6509-V-E (USED) Specification
WS-C6509-V-E Specification |
|
|
Number of Slots |
9 |
|
Supervisor Compatibility |
Cisco Catalyst 6500 Series Supervisor Engine 32 Cisco Catalyst 6500 Series Supervisor Engine 720-3B Cisco Catalyst 6500 Series Supervisor Engine 720-3BXL Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3C Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3CXL Cisco Catalyst 6500 Series Supervisor Engine 2T |
|
Power Supply Compatibility * Indicates EoS Power Supply |
AC: 2500W*, 3000W, 4000W, 6000W, 8700W DC: 2500W, 4000W, 6000W |
|
Module Compatibility |
All modules based on the software release in the system |
|
Software Compatibility (Minimum Software Version) |
|
|
With Supervisor Engine 32 |
● 12.2(18)SXF10 |
|
With Supervisor Engine 720 |
● 12.2(18)SXF10 |
|
With Supervisor Engine 720-10 GE |
● 12.2(33)SXH |
|
With Supervisor Engine 2T-10 GE |
● 15.0(1)SY |
|
Reliability and Availability Calculated Mean Time Between Failure (MTBF) |
330,888 |
|
MIBS |
Check the corresponding supervisor engine data sheet |
|
Network Management |
Check the corresponding supervisor engine data sheet |
|
Physical Dimensions |
|
|
Inches |
36.65 x 17.2 x 20.7 |
|
Centimeters |
93.3 x 43.1 x 53.3 |
|
Rack Units (RU) |
21 |
|
Weight |
|
|
Chassis Only (lbs) |
121 |
|
Fully Configured (lbs) |
270 |
|
Input Voltage |
100 to 240 VAC -48 to -60 VDC |
|
Safety |
UL 60950 Second Edition CAN/CSA-C22.2 No. 60950 Second Edition EN 60950 Second Edition IEC 60950 Second Edition AS/NZS 60950 |
|
EMC |
FCC Part 15 (CFR 47) Class A VCCI Class A EN55022 Class A CISPR 22 Class A CE marking AS/NZS 3548 Class A ETS300 386 EN55024 EN61000-6-1 EN50082-1 |
|
NEBS/ETSI |
GR-1089-Core NEBS Level 3 ETS 300 019 Storage Class 1.1 ETS 300 019 Transportation Class 2.3 ETS 300 019 Stationary Use Class 3.1 |
|
ATIS Pb free and Energy Efficiency |
ATIS-0600020.2010 Pb Free circuit packs ATIS-0600015-2009 General Energy Efficiency Requirements (TEER) ATIS-0600015.03-2009 Switch and Router Energy Efficiency ATIS-0600015.01-2009 Server Energy Efficiency VZ.TPR.9205 Verizon Energy Efficiency Requirements for Telecommunication Equipment (TEEER) |
|
Operating Environment |
|
|
Operating Temperature |
32°F to 104°F (0 to 40°C) |
|
Storage Temperature |
-4 to 149°F (-20 to 65°C) |
|
Thermal Transition |
0.5°C per minute (hot to cold) 0. 33°C per minute (cold to hot) |
|
Relative Humidity |
Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
|
Operating Altitude |
Certified for operation: 0 to 6500 ft (0 to 2000 m) Designed and tested for operation: -200 to 10,000 ft (-60 to 3000 m) |
