The UDM Pro is an all-in-one networking console that runs every UniFi OS application, like Network and Protect.
Quick Specs
Figure 1 shows the appearance of UDM-Pro.
Table 1 shows the Quick Specs.
|
Product Code |
UDM-Pro |
|
Interfaces
|
(8) 10/100/1000 RJ45 LAN Ports (1) 10/100/1000 RJ45 WAN Port (1) 1/10G SFP+ LAN Port (1) 1/10G SFP+ WAN Port |
|
Management Interfaces |
Ethernet In-Band (1) Bluetooth BLE |
|
Max. Power Consumption: |
33W |
|
Voltage Range: |
100 to 240VAC |
|
Power Method: |
(1) Universal AC Input, 100-240VAC, 50/60 Hz |
|
Width x Height x Depth:
|
442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24") |
Product Details
Figure 2 shows the front panel of UDM-Pro.
Figure 3 shows the back panel of UDM-Pro.
UDM-Pro provides these features:
- Runs every UniFi OS application, including the pre-installed UniFi Network
- 8-port switch with 1GbE RJ45 and 10G SFP+ ports
- Integrated security gateway and UniFi Protect-ready network video recorder that supports compatible 3.5" HDDs
- Enterprise-class internet threat management, deep packet inspection, and WiFi AI functionality
- Powered by a fast, 1.7 GHz quad-core processor
- 1U-sized, rack-mountable console
- Allows you to easily scale your deployment by connecting additional UniFi devices
Compare to Similar Items
Table 2 shows the comparison of UDM-Pro.
|
Module |
UDM-Pro |
|
|
Power Supply: |
Internal 50W/12V |
Internal AC/DC Power Adapter, 60W (24V, 2.5A) |
|
Max. Power Consumption: |
33W |
40W |
|
Processor: |
Quad ARM Cortex-A57 Core at 1.7 GHz |
Dual-Core 1 GHz, MIPS64 with Hardware Acceleration for Packet Processing |
|
Operating Temperature: |
-10° to 40° C (14° to 104° F) |
‐10 to 45° C (14 to 113° F) |
|
Operating Humidity: |
5 to 95% Noncondensing |
10 to 90% Noncondensing |
UDM-Pro Specification
UDM-Pro Specification |
|
|
Dimensions |
|
|
Width x Height x Depth:
|
442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24") |
|
Technical specifications |
|
|
Interfaces
|
(8) 10/100/1000 RJ45 LAN Ports (1) 10/100/1000 RJ45 WAN Port (1) 1/10G SFP+ LAN Port (1) 1/10G SFP+ WAN Port |
|
Management Interfaces |
Ethernet In-Band (1) Bluetooth BLE |
|
Technical Information |
|
|
IDS/IPS Throughput: |
3.5 Gbps |
|
Processor: |
Quad ARM Cortex-A57 Core at 1.7 GHz |
|
System Memory: |
4 GB DDR4 |
|
On-Board Flash Storage: |
16 GB eMMC |
|
Power |
|
|
Max. Power Consumption: |
33W |
|
Voltage Range: |
100 to 240VAC |
|
Power Method: |
(1) Universal AC Input, 100-240VAC, 50/60 Hz |
|
Redundant Power: |
(1) RPS DC Input |
|
Power Supply: |
Internal 50W/12V |
|
ESD/EMP Protection: |
Air: ± 16 kV, Contact: ± 12 kV |
|
Environment |
|
|
Operating Temperature: |
-10° to 40° C (14° to 104° F) |
|
Operating Humidity: |
5 to 95% Noncondensing |
