The Cisco Catalyst 3650 Series Switch, with Cisco StackWise-160 Technology, can stack 9 switches and support up to 160 Gpbs stack bandwidth. The WS-C3650-24TS-L integrates with 24 Ethernet ports and 4 x 1G SFP uplink ports in LAN base feature set.

Quick Specs

Figure 1 shows the appearance of the Cisco C3650-24TS-L switch.

Table 1 shows the Quick Specs.

Product Details

Figure 2 shows the front panel of the Cisco C3650-24TS-L switch.

Note：

①Mode button                                                   ④SB Type A storage port

②Status LEDs                                                    ⑤24 x 10/100/1000 Ports

③USB mini-Type B (console) port                 ⑥Uplink ports

Figure 3 shows the back panel of the Cisco C3650-24TS-L switch.

Note：

①Ground connector                              ②CONSOLE (RJ-45 console port)                ③MGMT (RJ-45 10/100/1000 management port)

④Fan module                                         ⑤Power supply modules

Figure 4 shows the StackWise-160 Kit.

The Cisco Catalyst 3650 supports an optional stacking module that is based on the Cisco StackWise-160 technology which allows stacking up to 9 switches.

Figure 5 shows the uboxing view of WS-C3650-24TS-L.

The Modules, Licenses and Accessories

Table 2 shows some modules,licenses and accessories of this switch.
