AC6800V-HOST Specification

Dimensions (height x width x depth)

86.1 mm x 447 mm x 708 mm

NOTE

The AC6800V should be installed in a standard IEC cabinet (19-inch).

Power Supplies

AC

Forwarding Capability

60 Gbit/s

Maximum Number of Managed APs

10K

Maximum Number of Access Users

100K

AP-AC Networking

Layer 2 or Layer 3 networking

Forwarding Mode

Direct forwarding (distributed forwarding or local forwarding) or tunnel forwarding (centralized forwarding)

AC Active/Standby Mode

1+1 HSB or N+1 backup

Radio Protocols

802.11 a/b/g/n/ac/ac wave 2/ax

Interface type

6 x 10GE(SFP+) + 6 x GE

Maximum power consumption

350 W

Weight

Net weight: 21 kg

Operating temperature and altitude

-60 m to +1800 m: 0°C to 45°C

1800 m to 5000 m: Temperature decreases by

1°C every time the altitude increases 300 m.

Relative humidity

5% RH to 95% RH, noncondensing

Power modules

550W Dual Power Supply, 1+1 Redundant Backup

AC input voltage

Rated voltage range:

100V AC～240V AC, 50/60Hz

Maximum voltage range:

90 V AC to 264 V AC, 47 Hz to 63 Hz

Number of managed APs

Central APs：1280

Common APs and RUs：10240

NOTE

The RUs managed by the WLAN AC do not occupy the AC's license resources. However, the total number of managed common APs and RUs cannot exceed the upper limit allowed by the AC.

Number of access users

Entire device: 100K

NOTE

The maximum number of access users varies depending on the authentication mode.

Number of MAC address entries

160K

Forwarding capability

60Gbit/s

NOTE

Packet length: 512 bytes

Number of VLANs

4K

Number of routing entries

IPv4: 16K

IPv6: 4K

Number of ARP entries

160K

Number of multicast forwarding entries

2K

Number of DHCP IP address pools

256 IP address pools, each of which contains a maximum of 64K IP addresses

Number of local accounts

10K

Number of ACLs

32K

User group management

128 user groups

Each user group can reference a maximum of 8 ACLs.

A maximum number of ACL rules that can be associated with each user group: 512
