HP SN6000B 16Gb 48/24 FC Switch
The HPE QK753B HP SN6000B is a high-performance Fibre Channel switch designed for enterprise-level storage networks. It offers advanced features such as high availability, high performance, and scalability. This switch is ideal for data centers and can handle heavy workloads with ease.
Quick Spec
Table 1 shows the quick spec.
| Brand | HPE |
| Model | QK753B |
| Ports | 48 x 16 Gbps Fibre Channel ports, 24 x 16 Gbps Fibre Channel ports |
| Switching Fabric | 2.88 Tbps |
| Max. Forwarding Rate | 4.28 billion frames/sec |
| Max. Latency | 700 ns |
| Power Consumption | 390 W |
| Dimensions | 1.7 x 17.4 x 27.0 inches |
| Weight | 28.22 lbs |
| Layer 2 Features | FC-SW-4, FC-FLA, FC-GS-2, FC-SW-3, FC-AL-2, FC-SW-2, FC-SW-1 |
| Layer 3 Features | FSPF, IP over FC |
| Management Features | SNMPv1, SNMPv2, SNMPv3, Telnet, SSH, HTTP, HTTPS, SMI-S, RMON |
| Operating Temp. | 0 to 40 °C (32 to 104 °F) |
Get More Information
Please feel free to check the QK753B datasheet below.
Do you have any question about the QK753B price?
Contact us now via Live Chat or [email protected].
QK753B Specification
QK753B Specification | |
| Performance | |
| Type | Bandwidth |
| Value | 768 Gbps |
| Ports | |
| Qty | 24 |
| Type | 16Gb Fibre Channel SFP+ |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Min Storage Temperature | -13 °F |
| Max Storage Temperature | 158 °F |
| Header | |
| Compatibility | PC |
| Manufacturer | HP CTO Server Avnet |
| Packaged Quantity | 1 |
| Product Line | HPE |
| Model | SN6000B 16Gb 48-port/24-port Active Fibre Channel Switch |
| Brand | HPE |
| Interface Provided | |
| Interface | Ethernet 10Base-T/100Base-TX |
| Qty | 24 |
| Connector Type | Type A |
| Comments | Management |
| Type | USB |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | APM, RoHS, VESA FDMI |
| Height (Rack Units) | 1 |
| Encryption Algorithm | 256-bit AES |
| Manufacturer Selling Program | HPE Complete |
| Networking | |
| Type | Switch |
| Remote Management Protocol | CLI, HTTP, SMI-S, SNMP 1, SNMP 3, SSH |
| Ports Qty | 24 |
| Features | EZ Switch, ISL support, Manageable, Syslog support |
| Subcategory | Fibre Channel and SAN |
| Manageable | Yes |
| Form Factor | Rack-mountable |
| Subtype | Fibre Channel |
| Power Device | |
| Frequency Required | 50/60 Hz |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Nominal Voltage | AC 120/230 V |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Type | Internal power supply |
| Hot-Plug | Hot-plug |
| Software | |
| Type | Brocade Advanced Web Tools, Brocade Advanced Zoning, Brocade EZ Switch, HP SAN Network Advisor Professional, HP Server Application Optimization |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 17.4 in |
| Height | 16.9 in |
| Weight | 20.19 lbs |
