Huawei AR120 series router AR121-S targeted for small enterprise or remote office environment and comes with 1 fast Ethernet 10/100 WAN port, 4FE 10/100 LAN ports.
Quick Specs
Figure 1 shows the appearance of Huawei Router - AR121-S.
Table 1 shows the Quick Specs.
|
Product Code |
Huawei Router - AR121-S |
|
Memory |
256 MB |
|
Flash |
256 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 10/100M auto-sensing Ethernet electrical interface LAN interfaces: 4 10/100M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: FE0-FE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
Product Details
Figure 2 shows the back panel of Huawei Router - AR121-S.
Note:
|
CON/AUX interface |
|
WAN FE electrical interfaces |
|
4 FE electrical interfaces |
|
RST button |
|
Power interface |
Compare to Similar Items
Table 3 shows the comparison between AR121-S and AR2220E.
|
Model |
AR121-S |
|
|
SIC Slots |
0 |
4 |
|
Memory |
256 MB |
1 GB |
|
Flash |
256 MB |
512 MB |
|
Weight |
2.8 kg |
6 kg (13.2 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
442.0 mm x 420.0 mm x 44.5 mm |
AR121-S Specification
AR121-S Specification |
|
|
Memory |
256 MB |
|
Flash |
256 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 10/100M auto-sensing Ethernet electrical interface LAN interfaces: 4 10/100M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: FE0-FE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
