Introducing the Aruba JL310A, a high-performance 100G QSFP28 LC LR4 SMF XCVR that offers reliable connectivity and advanced features. This transceiver module is designed to provide seamless communication and networking solutions for various applications.
Quick Spec
Table 1: The quick spec of JL310A
| Product Name | Aruba JL310A |
| Brand | Aruba |
| Data Rate | 100 Gbps |
| Connector Type | QSFP28 LC |
| Transmission Type | LR4 SMF |
Product Features
- High-speed data transmission at 100 Gbps.
- Compatible with QSFP28 LC connectors for easy integration.
- Long-range transmission using LR4 SMF technology.
- Reliable and durable construction for uninterrupted performance.
- Advanced features for enhanced networking capabilities.
Product Applications
- Data centers requiring high-speed connectivity.
- Enterprise networks for efficient and secure communication.
- Telecommunication infrastructure for reliable transmission.
Supported Options
Table 2: The supported options of JL310A
| Accessory | Model |
| Fiber Optic Patch Cable | LC-LC SMF |
| Rack Mount Kit | RMK-1U |
| Power Supply | PSU-1A |
Compare to Similar Items
Table 3: The comparison to similar items of JL310A
| Model | Differences |
| JL305A | Lower data rate (40 Gbps) |
| JL315A | Short range transmission |
| JL325A | Different connector type (QSFP28 SR4) |
Get more information
Do you have any questions about the JL310A price?
Contact us now via Live Chat or [email protected].
JL310A Specification
Aruba JL310A Specifications |
|
| Specification | Description |
| Product Model | JL310A |
| Brand | Aruba |
| Connectivity | 100G QSFP28 |
| Connector Type | LC |
| Transmission | LR4 |
| Fiber Type | Single Mode Fiber (SMF) |
| Wavelength | 4 Lambda (1271 nm, 1291 nm, 1311 nm, 1331 nm) |
| Data Rate | 100 Gbps |
| Transmission Distance | Up to 10 kilometers |
| Operating Temperature | -5°C to 70°C |
| Domestic/Import | Import |
| Form Factor | Hot-Pluggable |
| Power Supply Voltage | 3.3V |
| Power Consumption | 5W |
| Max Reach Supported | Up to 10 kilometers |
| Compatibility | Aruba switches and network devices |
| Supported Protocols | 100 Gigabit Ethernet, 4x 25 Gigabit Ethernet |
| Optical Components | DFB Laser |
| Dimensions | 70 mm x 13.5 mm x 18 mm |
