The Dell EMC PowerEdge R450, with 3rd generation Intel® Xeon® Scalable processors, offers improved performance and exceptional value in a 1U rack server - R450 Dell Server
Table 1 shows the 3 configuration of Dell R450 4LFF Server.
|
Configuration |
Processor |
Memory |
Hard Drive |
Power Supply |
|
Dell 1U R450 1*4310 4LFF Server |
1 * Intel Xeon 4310 |
1 * 32G |
1*2T SAS 10K |
1*600W |
|
Dell 1U R450 1*5317 4LFF Server |
1 * Intel Xeon 5317 |
1 * 32G |
1*2T SAS 10K |
1*800W |
|
Dell 1U R450 1*5320 4LFF Server |
1 * Intel Xeon 5320 |
1 * 32G |
1*2T SAS 10K |
1*800W |
Quick Spec
Table 2 shows the quick spec of Dell R450 server.
|
Product Code |
Dell R450 4LFF Server |
|
Processor |
Up to two 3rd Generation Intel® Xeon® Scalable processors, with up to 24 cores per processor |
|
Operating System |
(Dell Technologies recommends Windows 11 Pro for business) Canonical® Ubuntu® Server LTS Citrix® Hypervisor® Microsoft® Windows Server® with Hyper-V RedHat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
|
Chipset |
Intel® C620A chipset |
|
Memory |
DIMM Speed Up to 2933 MT/s Memory Type RDIMM Memory Module Slots 16 DDR4 DIMM slots Maximum RAM RDIMM 1 TB |
|
Storage |
Front Bays Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 16 TB Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 7.68 TB |
Product Details
The Dell EMC PowerEdge R450 is a two-socket entry-level 1U server offering updated technologies and added value with faster processing speeds and flexible storage options.
Density-optimized general-purpose server
The Dell EMC PowerEdge R450 with 3rd Generation Intel® Xeon® Scalable processors delivers the perfect combination of performance, density and affordability for general-purpose scale and web-tech deployments.
* Supports up to 24 cores per CPU, and up to 16x DDR4 RDIMMs at up to 2933 MT/s
* Built with a minimum footprint and enterprise compute to fit into a variety of environments
* Manage with iDRAC9 Enterprise, OpenManage Enterprise and Plugins, iDRAC Direct, and Quick Sync 2.0
* Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible and many other tools for on-premises, edge and cloud environments
Figure 1. Front view of the R450 system
Figure 2. Rear view of the R450 system
Figure 3. In the R450 system
Table 3 shows the R450 vs R440.
|
Series |
||
|
Processor |
Up to two 3rd Generation Intel Xeon Scalable processors, with up to 24 cores per processor |
Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 24 cores per processor |
|
Memory |
Memory 16 DDR4 DIMM slots, supports RDIMM max 1 TB, speeds up to 2933 MT/s |
16 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 1TB max |
|
Storage controllers |
• Internal controllers (RAID): PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150 |
Internal Controllers: PERC H330, H730P, H740P, HBA330 |
|
Drive Bays |
Front bays: |
Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 4 NVMe SSD max 76.8TB or |
|
Power Supplies |
• 600W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant |
Bronze 450W (Cabled PSU), Platinum 550W (Hot plug PSU with full redundancy option) |
|
Recommended Server |
Dell R450 4LFF Server Specification
Dell R450 4LFF Server Specification |
|
|
Processor |
Up to two 3rd Generation Intel® Xeon® Scalable processors, with up to 24 cores per processor |
|
Operating System |
(Dell Technologies recommends Windows 11 Pro for business) Canonical® Ubuntu® Server LTS Citrix® Hypervisor® Microsoft® Windows Server® with Hyper-V RedHat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
|
Chipset |
Intel® C620A chipset |
|
Memory |
DIMM Speed Up to 2933 MT/s
Memory Type RDIMM
Memory Module Slots 16 DDR4 DIMM slots
Maximum RAM RDIMM 1 TB |
|
Storage |
Front Bays Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 16 TB Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 7.68 TB |
|
Storage Controllers |
Internal Controllers PERC H345, PERC H355, PERC H745, PERC H755, HBA355i
External Controllers PERC H840, HBA355e
Software RAID S150
Internal Boot Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Internal Dual SD Module or USB |
|
Security |
Cryptographically signed firmware Secure Boot Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
|
Management |
Embedded / At-the-Server iDRAC9 iDRAC Service Module iDRAC Direct Quick Sync 2 wireless module
Consoles OpenManage Enterprise OpenManage Power Manager plugin OpenManage SupportAssist plugin OpenManage Update Manager plugin
Mobility OpenManage Mobile
Tools iDRAC RESTful API with Redfish IPMI RACADM CLI System Update Utility Update Catalogs
OpenManage Integrations BMC® Truesight Microsoft® System Center RedHat® Ansible® Modules VMware® vCenter and vRealize Operations Manager
OpenManage connections IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager Nagios® Core Nagios® XI |
|
Power Supplies
|
1100 W DC -48–(-60) V 800 W Platinum AC/240 V HVDC 600 W Platinum AC/240 V HVDC Hot plug power supplies with full redundancy option Up to 7 cold swap fans |
|
Ports |
Network Options 2 x 1 GbE LOM and 1 x OCP 3.0
Front Ports 1 x dedicated iDRAC Direct micro-USB 1 x USB 3.0 1 x VGA
Rear Ports 1 x USB 2.0 1 x Serial (optional) 1 x USB 3.0 2 x Ethernet 1 x VGA
Internal Ports 1 x USB 3.0 |
|
Slots |
2 x PCIe Gen4 slots |
|
Bezel |
Optional LCD bezel or security bezel |
|
Form Factor |
1U rack server |
|
Dimensions & Weight |
Height 42.8 mm (1.68 inches)
Width 482 mm (18.97 inches)
Depth For 4 x 3.5-inch configuration 748.79 mm (29.48 inches) with bezel 734.95 mm (28.93 inches) without bezel
For 8 x 2.5-inch configuration 698.03 mm (27.48 inches) with bezel 684.19 mm (26.93 inches) without bezel
Weight For 4 x 3.5-inch system - 18.62 kg (41.05 lbs.) For 8 x 2.5-inch system - 16.58 kg (36.55 lbs.) |
|
Rack Support |
ReadyRails™ II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks. Combo (Drop-in/Slide-in) rails with optional CMA and SRB for 4-post racks. ReadyRails™ static rails for 4-post and 2-post racks. |
|
Recommended Support |
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. |
