Cisco Catalyst 2960-S Series Switches WS-C2960S-48TS-L is a model, designed for enterprise, midmarket, and branch office networks equally. It has 48 RJ-45 10/100/1000Base-T Network LAN ports and provides LAN Base feature set.
Quick Specs
Figure 1 shows the appearance of the WS-C2960S-48TS-L.
Table 1 shows the Quick Spec of the WS-C2960S-48TS-L.
|
Product Code |
WS-C2960S-48TS-L |
|
Enclosure Type |
Rack-mountable - 1U |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
Four 1G Small Form-Factor Pluggable(SFP) |
|
Downlink Ports |
48 × Ethernet 10/100/1000 ports |
|
Expansion Slot(s) |
1 (total) / 1 (free) x Stacking Module |
|
Switching capacity |
176 Gbps |
|
Forwarding performance (64-byte packet size) |
41.7 Mpps |
|
DRAM |
128 MB |
|
Flash Memory |
64 MB |
|
Dimensions |
44.5 × 38.6 × 4.5 cm |
|
Package Weight |
9.19 Kg |
Product Details
Figure 2 shows the front panel of the WS-C2960S-48TS-L.
Note:
|
① |
Mode Button |
⑤ |
RJ45 Console Port |
|
② |
48 × Ethernet 10/100/1000 ports |
⑥ |
USB mini-Type B (console) Port |
|
③ |
SFP Module Slots |
⑦ |
USB Type A Port |
|
④ |
Ethernet Management Port |
Figure 3 shows the back panel of the WS-C2960S-48TS-L.
Note:
|
① |
1 (total) / 1 (free) x Stacking Module |
③ |
RPS Connector |
|
② |
Fan Exhaust |
④ |
AC power connector |
The Accessories
Table 2 shows some accessories of the WS-C2960S-48TS-L.
|
Models |
Description |
|
Catalyst 2960S FlexStack Stack Module optional for LAN Base |
|
|
GE SFP, LC connector LX/LH transceiver |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
WS-C2960S-48TS-L |
|
|
Ports |
24 × Ethernet 10/100/1000 ports FP) |
48 × Ethernet 10/100/1000 ports FP) |
|
Switching Capacity |
176 Gbps |
176 Gbps |
|
Uplinks |
4 x 1G SFP |
4 x 1G SFP |
|
Feature Set |
LAN Base |
LAN Base |
|
Stackable |
Yes |
Yes |
Get more information
Do you have any question about the WS-C2960S-48TS-L?
Contact us now via Live Chat or [email protected].
WS-C2960S-48TS-S (USED) Specification
WS-C2960S-48TS-S Specification |
|
|
Flash memory |
64 MB |
|
DRAM |
128 MB |
|
Forwarding Performance |
74.4 mpps |
|
Dimensions (H x W x D) |
Inches：1.75 x 17.7 x 11.8 Centimeters：4.5 x 45 x 30 |
|
Weight |
Pounds：10.5 Kilograms：4.8 |
|
Acoustic Noise |
Measured per ISO 7779 and declared per ISO 9296. Bystander positions operating mode at 25°C ambient. |
|
Sound Pressure |
LpA (Typical)：44 dB LpAD (Maximum)：47 dB |
|
Sound Power |
LwA (Typical)：5.4 B LwAD (Maximum)：5.7 B |
|
MTBF in hours |
357,740 |
|
Voltage (Autoranging) |
100 to 240 VAC |
|
Power Rating |
0.13 kVA |
|
Measured Power Consumption* |
100 Percent Throughput：53 5 Percent Throughput：50 |
|
Safety certifications |
UL 60950-1, Second Edition CAN/CSA 22.2 No. 60950-1, Second Edition TUV/GS to EN 60950-1, Second Edition CB to IEC 60950-1 Second Edition with all country deviations CE Marking NOM (through partners and distributors) |
|
Electromagnetic emissions (EMC) |
FCC Part 15 Class A EN 55022 Class A (CISPR22) EN 55024 (CISPR24) AS/NZS CISPR22 Class A CE CNS13438 Class A MIC GOST China EMC Certifications |
|
Environmental |
Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU |
|
Telco |
Common Language Equipment Identifier (CLEI) code |
|
US Government Certifications |
USGv6 and IPv6 Ready Logo |
