Huawei SVN5800 Secure Access Gateways SVN5860-AC integrates 16GE(RJ45) ports, 8GE(SFP)ports, 4*10GE(SFP+) ports,16GB Memory and 2 AC Power supplies. Huawei SVN5860-AC provides comprehensive security protection with excellent access performance for medium and large enterprise networks. The secure solution enables remote access, mobile office, branch interconnection, cloud and multimedia tunnel access.
Secure, agile access anywhere protected by Secure Sockets Layer (SSL) and Internet Protocol Security (IPSec) Virtual Private Networks (VPNs) and encrypted transmission capabilities.
Safeguard your enterprise, government, or carrier’s cloud and networking access, support diverse terminals and branch interconnectivity with Huawei SVN5800 series end-to-end solutions.
Quick Specs
Figure 1 shows the appearance of SVN5860-AC.
Table 1 shows the Quick Specs.
|
Product Code |
SVN5860-AC |
|
Part Number |
02359831 |
|
Description |
SVN5860 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP),16GB Memory,2 AC Power) |
|
Maximum number of concurrent SSL VPN users |
40,000 |
|
Maximum number of concurrent SSL VPN connections |
150,000 |
|
IPSec VPN throughput |
18Gbit/s |
|
Concurrent IPSec VPN connections |
15,000 |
|
Maximum number of virtual gateways |
512 |
|
Fixed ports |
4*10GE+16GE+8SFP |
|
Expansion slots |
5WSIC |
|
Form Factor |
3U |
|
Redundant power supply |
Standard |
|
Maximum power |
350W |
|
Pack Weight(kg) |
27 |
|
Pack Volume(m^3) |
0.116 |
|
Pack Dimension(D*W*H mm) |
750*595*260 |
|
Net Dimension(D*W*H mm) |
449*442*130 |
Product Details
Figure 2 shows the front panel of SVN5860-AC.
Note:
|
① |
Mandatory 2XG8GE interface card |
|
② |
Mandatory 8GEF interface card |
|
③ |
Expansion alots |
The Modules, Cards, Licenses
Table 2 shows the recommended elements for the SVN5860-AC.
|
Category |
Model |
Description |
|
Gigabit optical transceiver
|
|
eSFP, GE, Single-mode Module(1550nm,100km,LC) |
|
|
Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.5km,LC) |
|
|
|
Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC) |
|
|
|
1000BASE-T (RJ45) SFP Electrical Module, Auto Negotiate,100m |
|
|
10-Gigabit optical transceiver
|
|
10GBase-ZR Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,80km,LC) |
|
|
10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC) |
|
|
|
Optical Transceiver,SFP+,10G,Multi-mode Module(1310nm,0.22km,LC,LRM) |
|
|
Hard disk
|
|
Huawei 300GB 10K RPM SAS Hard Disk Unit SM-HDD-SAS300G-A |
Compare to Similar Items
Table 3 shows the comparison of SVN5830-AC, SVN5850-AC, SVN5860-AC and SVN5880-AC.
|
Product Code |
SVN5860-AC |
|||
|
Description |
SVN5830 AC Host(8GE(RJ45)+4GE(SFP),4GB Memory,1 AC Power) |
SVN5850 AC Host(8GE(RJ45)+4GE(SFP),4GB Memory,1 AC Power) |
SVN5860 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP),16GB Memory,2 AC Power) |
SVN5880 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP+),16G Memory,2 AC Power) |
|
Maximum number of concurrent SSL VPN users |
6000 |
12,000 |
40,000 |
100,000 |
|
Maximum number of concurrent SSL VPN connections |
15,000 |
30,000 |
150,000 |
150,000 |
|
IPSec VPN throughput |
3Gbit/s |
3Gbit/s |
18Gbit/s |
18Gbit/s |
|
Concurrent IPSec VPN connections |
4000 |
4,000 |
15,000 |
15,000 |
|
Maximum number of virtual gateways |
256 |
256 |
512 |
512 |
|
Fixed ports |
8GE+4SFP |
8GE+4SFP |
4*10GE+16GE+8SFP |
4*10GE+16GE+8SFP |
|
Expansion slots |
2WSIC |
2WSIC |
5WSIC |
5WSIC |
|
Form Factor |
1U |
1U |
3U |
3U |
|
Redundant power supply |
Optional |
Optional |
Standard |
Standard |
|
Maximum power |
170W |
170W |
350W |
700W |
Get more information
Do you have any question about the SVN5860-AC?
Contact us now via Live Chat or [email protected].
SVN5860-AC Specification
SVN5860 Specifications |
|
|
Maximum number of concurrent SSL VPN users |
40,000 |
|
Maximum number of concurrent SSL VPN connections |
150,000 |
|
IPSec VPN throughput |
18Gbit/s |
|
Concurrent IPSec VPN connections |
15,000 |
|
Maximum number of virtual gateways |
512 |
|
I/O |
|
|
Fixed ports |
8GE+4SFP |
|
Expansion slots |
2WSIC |
|
Expansion card types |
WSIC: 2×10GE（SFP+）+8×GE（RJ45)，8×GE（RJ45），8×GE（SFP），4×GE（RJ45）BYPASS |
|
Device Specifications |
|
|
Form Factor |
3U |
|
Dimensions (H x W x D) mm |
130.5 x 442 × 415 |
|
Weight (fully configured) |
22KG |
|
HDD |
Optional, 300 GB hot-swappable dual hard disks (RAID1) |
|
Redundant power supply |
Standard |
|
AC power supply |
100 V to 240 V |
|
Maximum power |
350W |
|
Operating environment |
Temperature: 0°C to 45°C (without hard disk)/5°C to 40°C (with hard disk), humidity: 10% to 90% |
|
Non-operating environment (storage environment) |
Temperature: –40ºC to 70ºC, humidity: 5% to 95% (non-condensing) |
|
Functions |
|
|
SSL VPN |
Supports Web proxy, file sharing, port forwarding, network extension, and multimedia tunnel. Supports access to resources, such as Web, Client/Server application program, and multimedia resources, in IPv4 or IPv6 |
|
VPN types |
SSL VPN, IPSec VPN, GRE VPN, L2TP VPN, MPLS VPN |
|
User authentication |
Supports authentication methods, such as local password (VPNDB), AD, RADIUS, LDAP, SecurID, X.509 digital certificate, USB key, SMS, device ID, and CAPTCHA authentication. Supports hierarchical authentication, single sign-on (SSO), and software keyboard. |
|
Authentication control |
Supports role-based, external group mapping, and dynamic authorization based on the security level of the terminals Provides fine-grained access control based on application, IP address, port, and URL and is able to identify over 6000 application protocols |
|
Supported operating systems |
Supports Android, Windows, Mac OS, iOS, Linux, Symbian, and BlackBerry OS. |
|
Terminal security |
Supports terminal/host security check, cache cleaning, terminal ID binding, and DDoS attack defense at application and network layers. |
|
Virtual gateway |
Supports multiple virtual gateways on one physical gateway to allow for service and network virtualization and independent authentication, authorization, services, and resources management |
|
Agile feature |
Bandwidth management, intelligent ISP link selection |
|
Network security |
Supports access control, NAT, and attack defense. |
|
Network protocols |
Supports IPv4 and IPv6 |
|
Deployment and availability |
Supports transparent, routing, and hybrid deployment modes and active/active and active/standby high availability (HA) |
