Cisco ASA 5500 Firewall Bundle ASA5515-K7 ASA 5515-X with SW, 6GE Data, 1GE Mgmt, AC, NPE for Cisco 5500 Firewall
ASA5515-K7 Specification
ASA5515-K7 Specification | |
| General | |
| Device Type | Security appliance |
| Height (Rack Units) | 1U |
| Width | 16.9 in |
| Depth | 15.6 in |
| Height | 1.7 in |
| Weight | 13.45 lbs |
| Processor / Memory / Storage | |
| RAM | 8 GB |
| Networking | |
| Form Factor | Rack-mountable |
| Ports Qty | 6 |
| Connectivity Technology | Wired |
| Data Link Protocol | Gigabit Ethernet |
| Performance | Firewall throughput: 1.2 Gbps ¦ VPN throughput (3DES/AES): 250 Mbps ¦ Connection rate: 15000 connections per second ¦ Firewall + intrusion prevention throughput: 400 Mbps |
| Capacity | IPSec VPN peers: 250 ¦ SSL VPN peers: 2 ¦ Concurrent sessions: 250000 ¦ Virtual interfaces (VLANs): 100 ¦ Security contexts: 2 |
| Status Indicators | Power, HDD activity, active, alarm |
| Features | Firewall protection, VPN support, VLAN support |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Interfaces | 6 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x management - RJ-45 ¦ 2 x USB 2.0 - Type A |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | VCCI, C-Tick, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class A, CISPR 22, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 B Class A, CAN/CSA C22.2 No. 60950-1-07, ANSI C63.4-2009 |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
