The Fortinet Enterprise Firewall Solution delivers end-to-end network security with one platform, one network security operating system and unified policy management with a single pane of glass - for the industry's best protection against the most advanced security threats and targeted attacks.
Quick Specs
Figure 1 shows the appearance of FG-60E-BDL-950-36.
Table 1 shows the Quick Specs.
Product Code |
FG-60E-BDL-950-36 |
Form Factor |
Desktop |
Height X Width X Length (inches) |
1.5 x 8.5 x 6.3 |
Power Consumption (Average / Maximum) |
11.7 / 14 W |
Power Required |
100-240V AC, 50-60 Hz |
Application Control Throughput |
550 Mbps |
CAPWAP Throughput |
1.5 Gbps |
Product Details
Figure 2 shows the front panel of FG-60E-BDL-950-36.
Figure 3 shows the back panel of FG-60E-BDL-950-36.
FG-60E-BDL-950-36 provides these features:
Security
- Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
- Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
- Prevent and detect against known and unknown attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services
Performance
- Delivers industry’s best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
- Provides industry-leading performance and protection for SSL encrypted traffic
Certification
- Independently tested and validated for best-in-class security effectiveness and performance
- Received unparalleled third-party certifications from NSS Labs
Networking
- Delivers advanced networking capabilities that seamlessly integrate with advanced layer 7 security and virtual domains (VDOMs) to offer extensive deployment flexibility, multi-tenancy and effective utilization of resources
- Delivers high-density, flexible combination of various high-speed interfaces to enable best TCO for customers for data center and WAN deployments
Management
- Includes a management console that is effective, simple to use, and provides comprehensive network automation and visibility
- Provides Zero Touch Integration with Fortinet’s Security Fabric’s Single Pane of Glass Management
- Predefined compliance checklist analyzes the deployment and highlights best practices to improve overall security posture
Security Fabric
- Enables Fortinet and Fabric-ready partners’ products to provide broader visibility, integrated end-to-end detection, threat intelligence sharing, and automated remediation
Table 2 shows the comparison of FG-60E-BDL-950-36.
Module |
FG-60E-BDL-950-36 |
|
Form Factor |
Desktop |
Desktop |
Height X Width X Length (inches) |
1.5 x 8.5 x 6.3 |
1.5 x 8.5 x 6.3 |
Power Consumption (Average / Maximum) |
11.7 / 14 W |
95 watt |
Power Required |
100-240V AC, 50-60 Hz |
50/60 hertz |
Get More Information
Do you have any question about the FG-60E-BDL-950-36?
Contact us now via Live Chat or [email protected].
FG-60E-BDL-950-36 Specification
FG-60E-BDL-950-36 Specification |
|
Dimensions |
|
Form Factor |
Desktop |
Height X Width X Length (inches) |
1.5 x 8.5 x 6.3 |
Height X Width X Length (mm) |
38 x 216 x 160 |
Environment |
|
Heat Dissipation |
40 BTU/h |
Humidity |
20-90% non-condensing |
Maximum Current |
110 V / 1.5 A, 220 V / 0.75 A |
Operating Altitude |
Up to 7,400 ft (2,250 m) |
Operating Temperature |
32-104°F (0-40°C) |
Power Consumption (Average / Maximum) |
11.7 / 14 W |
Power Required |
100-240V AC, 50-60 Hz |
Storage Temperature |
-31-158°F (-35-70°C) |
Hardware Specifications |
|
Console (RJ45) |
1 |
GE RJ45 DMZ Ports |
1 |
GE RJ45 Internal Ports |
7 |
GE RJ45 WAN Ports |
2 |
USB Ports |
1 |
System Performance |
|
Application Control Throughput |
550 Mbps |
CAPWAP Throughput |
1.5 Gbps |
Client-to-Gateway IPsec VPN Tunnels |
500 |
Concurrent Sessions (TCP) |
1.3 Million |
Concurrent SSL-VPN Users (Recommended Maximum) |
100 |
Firewall Policies |
5,000 |
Firewall Throughput (1518 / 512 / 64 Byte UDP Packets) |
3 / 3 / 3 Gbps |
Firewall Throughput (Packets Per Second) |
4.5 Mpps |
Gateway-to-Gateway IPsec VPN Tunnels |
200 |
High Availability Configurations |
Active / Active, Active / Passive, Clustering |
IPS Throughput (HTTP / Enterprise Mix) |
1,400 / 350 Mbps |
IPsec VPN Throughput (512 Byte Packets) |
2 Gbps |
Maximum Number Of FortiAPs (Total / Tunnel Mode) |
10 / 5 |
Maximum Number Of FortiTokens |
100 |
Maximum Number Of Registered FortiClients |
200 |
New Sessions/Second (TCP) |
30,000 |
NGFW Throughput |
250 Mbps |
SSL Inspection Throughput |
340 Mbps |
SSL-VPN Throughput |
150 Mbps |
Threat Protection Throughput |
180 Mbps |
