Cisco ISR4431-SEC/K9 is the Cisco ISR4431/k9 router with Security Bundle. Its other specifications are the same as ISR4431/k9.
Quick Specs
Figure 1 shows the appearance of Cisco ISR4431-SEC/K9.
Table 1 shows the Quick Specs.
|
Product Code |
Cisco ISR4431-SEC/K9 |
|
Bundle |
Security Bundle |
|
Aggregate Throughput |
500 Mbps to 1 Gbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
4 |
|
RJ-45-based ports |
4 |
|
SFP-based ports |
4 |
|
Enhanced service-module (SM-X) slot |
0 |
|
NIM (Network Interface Modules) slots |
3 |
|
Onboard ISC slot |
1 |
|
DDRM (data plane) |
2 GB (default) / 2 GB (maximum) |
|
DDRM (control/services plane) |
4 GB (default) / 16 GB (maximum) |
|
Flash Memory |
8 GB (default) / 32 GB (maximum) |
|
Power-supply options |
Internal: AC, DC, and PoE |
|
Rack height |
1 RU |
|
Dimensions (H x W x D) |
43.9 x 438.15 x 507.2 mm |
|
Package Weight |
20.88 Kg |
Product Details
Figure 2 shows the front panel of Cisco ISR4431-SEC/K9.
Note:
|
① |
Power supply unit |
③ |
Router power On/Off switch |
|
② |
LEDs |
④ |
Optional power supply unit |
· LEDs include 12 indicators: PSU0, PSU1, GE/POE, FLASH, TEMP, PWR, POE0, POE1, BOOST, ISC, FAN, and STAT.
Figure 3 shows the back panel of Cisco ISR4431-SEC/K9.
Note:
|
① |
GE management port |
⑤ |
Console port |
|
② |
Auxiliary port |
⑥ |
GE Ports |
|
③ |
USB Type A port |
⑦ |
NIM Slots |
|
④ |
USB Type B mini port |
· The NIMs support 2 single-wide or 1 double-wide.
· The GE Ports include 4 RJ45 ports and 4 SFP ports.
Figure 4 shows the Security Bundle Functions.
The Modules, Cards and Accessories
Table 2 shows some recommended modules, cards and accessories of Cisco ISR4431-SEC/K9.
|
Items |
Models |
Descriptions |
|
Console and Auxillary Cables |
Cisco CAB-AUX-RJ45 Auxiliary Cable 8ft with RJ45 and DB25M |
|
|
Cisco Router Cable CAB-ETH-S-RJ45 |
||
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
||
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
||
|
Network Interface Modules |
Cisco Fourth-Generation Multiflex Trunk Voice and WAN network interface module |
|
|
Cisco Multiflex Trunk Voice and WAN network interface module |
||
|
Analog voice network interface card (ear and mouth) |
||
|
Cisco Analog voice network interface card NIM-2FXS |
||
|
Cisco Analog voice network interface card NIM-2FXS/4FXO |
||
|
Cisco Fourth-Generation Multiflex Trunk Voice and WAN network interface module |
||
|
SFPs for On-Board GE Ports |
Cisco GLC-SX-MMD 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
||
|
Cisco GLC-ZX-SMD 1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM |
Compare to Similar Items
Table 3 shows the comparison between tow similar items.
|
Models |
ISR4431-SEC/K9 |
|
|
Bundle |
None |
Security Bundle |
|
Aggregate Throughput |
500 Mbps to 1 Gbps |
500 Mbps to 1 Gbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
4 |
4 |
|
RJ-45-based ports |
4 |
4 |
|
SFP-based ports |
4 |
4 |
|
Enhanced service-module slots |
0 |
0 |
|
NIM slots |
3 |
3 |
|
Onboard ISC slot |
1 |
1 |
|
Rack height |
1 |
1 |
Get more information
ISR4431-SEC/K9 Specification
Cisco ISR4431-SEC/K9 Specification |
|
|
Type |
Cisco ISR4431/K9 with Security Bundle |
|
Aggregate Throughput |
500Mbps to 1Gbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
4 |
|
RJ-45-based ports |
4 |
|
SFP-based ports |
4 |
|
Enhanced service-module slots |
0 |
|
Doublewide service-module slots |
0 |
|
NIM slots |
3 |
|
OIR (all I/O modules) |
Yes |
|
Onboard ISC slot |
1 |
|
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes) |
NA |
|
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes) |
NA |
|
Default memory DDR3 ECC DRAM (data plane) |
2 GB |
|
Maximum memory DDR3 ECC DRAM (data plane) |
2 GB |
|
Default memory DDR3 ECC DRAM (control/services plane) |
4 GB |
|
Maximum memory DDR3 ECC DRAM (control/services plane) |
16 GB |
|
Default flash memory |
8 GB |
|
Maximum flash memory |
32 GB |
|
External USB 2.0 slots (type A) |
2 |
|
USB console port -type B mini (up to 115.2 kbps) |
1 |
|
Serial console port - RJ45 (up to 115.2 kbps) |
1 |
|
Serial auxiliary port - RJ45 (up to 115.2 kbps) |
1 |
|
Power-supply options |
Internal: AC, DC, and PoE |
|
Redundant power supply |
Internal: AC, DC, and PoE |
|
AC input voltage |
100 to 240 VAC autoranging |
|
AC input frequency |
47 to 63 Hz |
|
AC input current range, AC power supply (maximum) |
3 to 1.3A |
|
AC input surge current |
60 A peak and less than 5 Arms per half cycle |
|
Typical power (no modules) (watts) |
65 |
|
Maximum power with AC power supply (watts) |
250 (no PoE) |
|
Maximum power with PoE power supply (platform only) (watts) |
500 with PoE redundant |
|
Maximum endpoint PoE power available from PoE power supply (watts) |
250 W with optional redundancy |
