Cisco WS-C3850-24XU-S provides stackable 24 100M/1G/2.5G/5G/10G UPoE ports, 1 network module slot, and 1100 W AC power supply. Cisco Catalyst 3850 Series provides capabilities that ideally suited to support the convergence of wired and wireless access. The new Cisco Unified Access Data™ Plane (UADP) Application-Specific Integrated Circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise®-480 technology.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
WS-C3850-24XU-S |
|
Enclosure Type |
1 RU |
|
Feature Set |
IP Base |
|
Ports |
24 100M/1G/2.5G/5G/10G UPoE ports |
|
Performance |
92 Gbps |
|
RAM |
4GB |
|
Flash Memory |
2GB |
|
Dimension |
Width: 17.5 in Depth: 19.2 in Height: 1.8 in |
The Module
Table 2 shows some recommended modules of this switch.
|
Models |
Description |
|
Cisco 3850 Series 4 x 1GE Network Module |
|
|
Cisco 3850 Series 2 x 10GE Network Module |
|
|
Cisco 3850 Series 4 x 10GE Network Module |
|
|
Cisco 3850 Series 8 x 10GE Network Module |
|
|
Cisco 3850 Series 2 x 40GE Network Module |
Compare to Similar Item
Table 3 shows the comparison.
|
Product Code |
WS-C3850-24XU-S |
|
|
Enclosure Type |
1 RU |
1 RU |
|
Feature Set |
IP Base |
IP Base |
|
Ports |
12 100M/1G/2.5G/5G/10G and 36 1 G UPoE ports |
24 100M/1G/2.5G/5G/10G UPoE ports |
|
Switching capacity |
176 Gbps |
92 Gbps |
|
RAM |
4GB |
4GB |
|
Flash Memory |
2GB |
2GB |
Switch to Something New
Why Upgrade to Catalyst 9300? | See the Catalyst 9300 Series
Get more information
Do you have any question about the WS-C3850-24XU-S?
Contact us now via Live Chat or [email protected].
WS-C3850-24XU-S Specification
WS-C3850-24XU-S Specification |
|
|
Description |
Stackable 24 100M/1G/2.5G/5G/10G UPoE ports, 1 network module slot, 1100 W AC power supply 1RU |
|
Ports |
Stackable 24 100M/1G/2.5G/5G/10G UPoE ports |
|
Performance |
Switching capacity: 92 Gbps ¦ Stacking bandwidth: 480 Gbps |
|
Dimensions & Weight |
Width: 17.5 in Depth: 19.2 in Height: 1.8 in Weight: 17.64 lbs |
|
Environmental Parameters |
Min Operating Temperature: 23 °F Max Operating Temperature: 113 °F Humidity Range Operating: 10 - 95% (non-condensing) Min Storage Temperature: -40 °F Max Storage Temperature: 158 °F |
|
PoE Power |
60W |
|
RAM |
4 GB |
|
Flash Memory |
2 GB |
|
Miscellaneous |
MTBF: 203,150 hours Compliant Standards: AS/NZS 3548 Class A, AS/NZS CISPR 22, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CNS 13438, EN 300386, EN 55022 Class A, EN 60950-1, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15, FCC Part 15 A, ICES-003 Class A, IEC 60950-1, IEC 60950-1 Second Edition, KCC, KN22 Class A, KN24, NOM, RoHS 5/6, UL 60950-1, UL 60950-1 Second Edition, VCCI Class A |
|
Software |
Cisco IOS IP Base |
|
Power |
Power Device: Internal power supply Installed Qty: 1 (installed) / 2 (max) Power Redundancy: Optional Power Redundancy Scheme: 1+1 (with optional power supply) Power Provided: 1100 Watt Voltage Required: AC 120/230 V (50/60 Hz) Features: Rear-to-front airflow |
