JL070A is the switch with 8-PoE+ Internal Power Supply. The Aruba 2530 Switch Series provides security, reliability, and ease of use for enterprise edge, branch office, and SMB deployments.

Quick Specs

Figure 1 shows the appearance of JL070A.

Table 1 shows the Quick Specs.

Product Details

Figure 2 shows the front panel of JL070A.

JL070A provides these features:

•  Cost-effective, reliable and secure Aruba Layer 2 switch series
•  Flexible Management via Aruba AirWave, Aruba Central, and Aruba ClearPass Policy Manager
•  Right size deployment with choice of 8, 24 and 48 port Gigabit and Fast Ethernet models
•  Up to 370W PoE+ to power IoT, APs and cameras
•  REST API support
•  Simple deployment with Zero Touch Provisioning

Quality of Service (QoS)

•  Traffic prioritization (IEEE 802.1p) for real-time traffic classification. Support for eight priority levels mapped to either two or four queues, and uses weighted deficit round robin (WDRR) or strict priority
•  Simplified quality of service (QoS) configuration

- Port-based traffic prioritization by specifying a port and priority level

- VLAN-based traffic prioritization by specifying a VLAN and priority level

•  Class of Service (CoS) sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number, source port, and DiffServ
•  Rate limiting establishes per-port ingress-enforced maximums for all traffic or for broadcast, multicast, or unknown destination traffic
•  Layer 4 prioritization enables priorities based on TCP/UDP port numbers
•  Flow control delivers reliable communication during full-duplex operation

Simplified Configuration and Management

•  Aruba Central cloud-based management platform offers a simple, secure and cost effective way to manage switches. Complies with RFC 7030 for encryption key enrollment
•  Zero-Touch-Provisioning (ZTP) simplifies installation of the switch infrastructure using DHCP-based process with AirWave
•  Flexible management – Supports both cloud-based Central and on-premise AirWave without ripping and replacing switching infrastructure
•  Choice of management interfaces

- HTML-based easy-to-use Web GUI allows configuration of the switch from any Web browser

- Robust CLI provides advanced configuration and diagnostics

- Simple network management protocol (SNMPv1/v2c/v3) allows the switch to be managed with a variety of third-party network management applications

•  Provides single IP address management for up to 16 switches individually
•  sFlow® (RFC 3176) delivers wire-speed traffic accounting and monitoring, configured by SNMP and CLI with three terminal encrypted receivers
•  IEEE 802.1AB Link-Layer Discovery Protocol (LLDP) automates device discovery protocol for easy mapping by network management applications
•  Provides local and remote logging of events via SNMP (v2c and v3) and syslog; provides log throttling and log filtering to reduce the number of log events generated
•  Port mirroring allows traffic to be mirrored on any port or a network analyzer to assist with diagnostics or detecting network attacks
•  Remote monitoring (RMON) provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events
•  Friendly port names allows assignment of descriptive names to ports
•  Dual flash images provides independent primary and secondary operating system files for backup while upgrading
•  Multiple configuration files are easily stored with a flash image
•  Front-panel LEDs

- Locator LEDs allows users to set the locator LED on a specific switch to turn on, blink, or turn off; and simplifies troubleshooting by making it easy to locate a particular switch within a rack of similar switches

- Per-port LEDs provides an at-a-glance view of the status, activity, speed, and full-duplex operation

- Power and fault LEDs display issues, if any

 Product architecture

•  Energy-efficient design

- IEEE 802.3az reduces power consumption during periods of low data activity on Gigabit Ethernet switches

- Port low-power mode enables the port to automatically go into low-power mode to conserve energy when no link is detected

- Fan-less and variable-speed fans decrease power consumption in fan-less (all 8-port, 2530-24, and 2530-48 PoE+ switches) as well as variable-speed fan switches

- Port LEDs conserves energy by optionally turning off port link and activity LEDs

•  Switch on a chip provides a highly integrated, highperformance switch design with a nonblocking architecture

Flexibility

•  Power Savings with Energy Efficient Design

- Rack mountable allows the switch to be mounted on a standard 19-inch rack, with the hardware included

- Wall mountable allows the switch to be mounted on a wall, using the hardware included

- Surface mountable allows the switch to be mounted above or below a surface (such as a desk or table), using the hardware included

•  Quiet operation lowers noise, making it suitable for deployments in acoustically sensitive environments such as conference rooms and office spaces
•  Compact size reduces space requirements (refer to the product specifications for the exact dimensions)

Compare to Similar Items

Table 2 shows the comparison of JL070A.
