Dell R750 8SFF Server

Brands: Dell

(0 reviews)

﷼ 24913.02 27681.13 10% Off

Model: Dell R750 8SFF Server Bundle - Dell PowerEdge R750 Server

Detail: Dell R750 8SFF Server Bundle

Categories: Servers / Dell Rack Server
Tags:

Dell EMC PowerEdge R750, powered by the 3rd Generation Intel Xeon Scalable processors is a rack server to address application performance and acceleration. The PowerEdge R750, is a dual-socket/2U rack server that delivers outstanding performance for the most demanding workloads. It supports 8 channels of memory per CPU, and up to 32 DDR4 DIMMs @ 3200 MT/s speeds - R750 Dell.

Table 1 shows the 3 configuration of Dell R750 8SFF Server.

Configuration	Processor	Memory	Hard Drive	Power Supply
Dell 2U R750 2*4310 8SFF Server	2 * Intel Xeon 4310	2 * 32G	2*1.2T SAS 10K	2*800W
Dell 2U R750 2*5317 8SFF Server	2 * Intel Xeon 5317	2 * 32G	2*1.2T SAS 10K	2*800W
Dell 2U R750 2*6330 8SFF Server	2 * Intel Xeon 6330	2 * 32G	2*1.2T SAS 10K	2*800W

Quick Spec

Table 2 shows the quick spec of Dell R750 server.

Series	Dell EMC PowerEdge R750
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor
Memory	• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s • Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max • Supports registered ECC DDR4 DIMMs only
Storage controllers	• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N • Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB • Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E
Drive Bays	Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
Power Supplies	• 800 W Platinum AC/240 mixed mode • 1100 W Titanium AC/240 mixed mode • 1400 W Platinum AC/240 mixed mode • 2400 W Platinum AC/240 mixed mode

Product Details

The Dell EMC PowerEdge R750 offers compelling performance, highspeed memory and capacity, I/O bandwidth and storage to address data requirements – Ideal for:

• Traditional corporate IT

• Database and Analytics

• Virtual Desktop Infrastructure

• AI/ML and HPC

Figure 1. Front view of the Dell PowerEdge R750 system

Front view of the dell r750 system

Figure 2. Rear view of the R750 system

Rear view of the dell r750 system

Compare to Similar Items

Table 3 shows the R750 vs R740.

Series	Dell EMC PowerEdge R750	Dell EMC PowerEdge R740
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor	Up to two 2nd Generation Intel Xeon Scalable processors, up to 28 cores per processor
Memory	• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s • Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max • Supports registered ECC DDR4 DIMMs only	• 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB max • Up to 12 NVDIMM, 192 GB Max • Up to 12 Intel® Optane™ DC persistent memory PMem, 6.14TB max (7.68TB max with PMem + LRDIMM) • Supports registered ECC DDR4 DIMMs only
Storage controllers	• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N • Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB • Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E	• Internal Controllers: PERC H330, H730P, H740P, HBA330 • External Controllers: H840, 12 Gbps SAS HBA
Drive Bays	Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB	• Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5” SAS/SATA HDD max 128TB • Optional DVD-ROM, DVD+RW
Power Supplies	• 800 W Platinum AC/240 mixed mode • 1100 W Titanium AC/240 mixed mode • 1400 W Platinum AC/240 mixed mode • 2400 W Platinum AC/240 mixed mode	• Titanium 750W, Platinum 495W • 750W • 750W 240VDC, 1100W, 1100W 380VDC • 1600W, 2000W and 2400W, Gold 1100W -48VDC
Recommended Server	Dell R750 8SFF Server	Dell 2U R740 4210R/8G1/600G SAS 10K1/H330/DVD/750W1/3.5-8 Dell 2U R740 5218R/8G1/600G SAS 10K1/H330/DVD/750W1/3.5-8

Dell R750 8SFF Server Specification

Dell EMC PowerEdge R750 Specification
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor
Memory	• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s • Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max • Supports registered ECC DDR4 DIMMs only
Storage controllers	• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N • Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB • Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E
Drive Bays	Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
Power Supplies	• 800 W Platinum AC/240 mixed mode • 1100 W Titanium AC/240 mixed mode • 1400 W Platinum AC/240 mixed mode • 2400 W Platinum AC/240 mixed mode
Cooling Options	Air cooling, optional processor liquid cooling
Fans	• Standard fan/High performance SLVR fan/High performance GOLD fan • Up to six hot plug fans
Dimensions	• Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 758.3 mm (29.85 inches) - without bezel 772.14 mm (30.39 inches) - with bezel
Form Factor	2U rack server
Embedded Management	• iDRAC9 • iDRAC Service Module • iDRAC Direct • Quick Sync 2 wireless module
Bezel	Optional LCD bezel or security bezel
OpenManage Software	• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin
Mobility	OpenManage Mobile
Integrations and Connections	OpenManage Integrations • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules • VMware vCenter and vRealize Operations Manager OpenManage Connections • IBM Tivoli Netcool/OMNIbus • IBM Tivoli Network Manager IP Edition • Micro Focus Operations Manager • Nagios Core • Nagios XI
Security	• Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC	2 x 1 GbE LOM
Network Options	1 x OCP 3.0 (x8 PCIe lanes)
GPU Options	Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators
Ports	Front Ports • 1 x Dedicated iDRAC Direct micro-USB • 1 x USB 2.0 • 1 x VGA Rear Ports • 1 x USB 2.0 • 1 x Serial (optional) • 1 x USB 3.0 • 2 x RJ-45 • 1 x VGA (optional for liquid cooling configuration) Internal Ports • 1 x USB 3.0
PCIe	Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules
Operating System and Hypervisors	• Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi
