ITCS EX3400-24P

Sale Off

EX3400-24P

Brands: Juniper

(0 reviews)

﷼ 5624.44 6249.38 10% Off

Model: EX3400-24P - Juniper EX3400 Series Ethernet Switches

Detail: <p style="margin-bottom: 0px;">EX3400 24-port 10/100/1000BaseT PoE+, 4 x 1/10G SFP/SFP+, 2 x 40G QSFP+, redundant fans, front-to-back airflow, 1 AC PSU JPSU-600-AC-AFO included (optics sold separately)</p>

Categories: Switches / Juniper EX3400 Series Ethernet Switches
Tags:

EX3400-24P is a Juniper EX3400 switch with 24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included). EX3400 Ethernet Switches are a cost-effective solution for today’s most demanding converged data, voice, and video enterprise access networks. The compact, fixed-configuration 1U devices offer levels of performance and management previously available only with high-end access switches.

Quick Spec

Table 1 shows the quick spec.

SKU	EX3400-24P
Ports	24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Backplane speed	160 Gbps
Data rate	288 Gbps
Throughput	214 Mpps (wire speed)
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit

Product Details

Figure 1 shows the front panel of EX3400-24P.

Note:

①	RJ-45 PoE+ ports	④	Factory Reset/Mode button
②	Uplink ports	⑤	Port status mode LEDs
③	Mini-USB console port	⑥	Chassis status LEDs

Figure 2 shows the rear panel of EX3400 AC chassis.

Note:

①	Management Ethernet port	⑦	AC power supply
②	Protective earthing terminal	⑧	Serial Number ID Label
③	ESD point	⑨	QSFP+ uplink ports
④	Fan modules	⑩	RJ-45 console port
⑤	CLEI code label	⑪	USB port
⑥	Empty slot for power supply covered by a blank panel

Compare to Similar Items

Table 2 shows the comparison.

SKU	EX3400-24T	EX3400-24P	EX3400-48T	EX3400-48P
Ports	24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)	24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)	48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+	48-port 10/100/1000BASE-T (48 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Backplane speed	160 Gbps	160 Gbps	160 Gbps	160 Gbps
Data rate	288 Gbps	288 Gbps	336 Gbps	336 Gbps
Throughput	214 Mpps (wire speed)	214 Mpps (wire speed)	250 Mpps (wire speed)	250 Mpps (wire speed)
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit

Get More Information

Do you have any question about the EX3400-24P?

EX3400-24P Specification

EX3400-24P Specification
Description	EX3400 24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Form factor	Fixed platform Virtual Chassis configuration consisting of up to 10 switches Junos Fusion Enterprise Satellite device
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit
Backplane speed	160 Gbps
Data rate	288 Gbps
Throughput	214 Mpps (wire speed)
40GBASE quad small form-factor pluggable plus transceiver (QSFP+) port densities	2
100GBASE C form-factor pluggable transceiver (CFP) port densities	N/A
Resiliency	Redundant, field-replaceable power supplies Redundant trunk groups that provide port redundancy and simplify switch configuration
Operating system	Junos OS
Traffic monitoring	sFlow
Quality-of-service (QoS) queues/port	8 unicast/4 multicast
MAC addresses	32,000
Jumbo frames	9216 bytes
IPv4 unicast/multicast routes	36,000/4,000
IPv6 unicast/multicast routes	18,000/2,000
Number of VLANs	4,096
ARP entries	16,000
