Quick Specs
Figure 1 shows the appearance of UCK-G2.
Table 1 shows the Quick Specs.
|
Product Code |
UCK-G2 |
|
Dimensions |
27.10 x 46.80 x 119.75 mm (1.07 x 1.84 x 4.71") |
|
Enclosure material |
Anodized aluminum |
|
eMMC memory |
32 GB |
|
Power method |
802.3af PoE, 5VDC, 1A |
|
Max. power consumption |
5W |
Product Details
Figure 2 shows the front panel of UCK-G2.
Figure 3 shows the back panel of UCK-G2.
UCK-G2 provides these features:
- 4x more powerful than the original Cloud Key
- Simple, Bluetooth-powered console setup via UniFi's mobile apps
- Powered by 802.3af PoE or USB-C
- Built-in battery for automatic safe shutdown
- Front panel display that helps you to review UniFi system details at a glance
- Allows you to easily scale your deployment by connecting additional UniFi devices
Compare to Similar Items
Table 2 shows the comparison of UCK-G2.
|
Module |
UCK-G2 |
|
|
Dimensions |
27.10 x 46.80 x 119.75 mm (1.07 x 1.84 x 4.71") |
131.16 x 27.10 x 134.20 mm (5.16 x 1.07 x 5.28") |
|
Enclosure material |
Anodized aluminum |
Anodized aluminum |
|
eMMC memory |
32 GB |
2 GB |
|
Power method |
802.3af PoE, 5VDC, 1A |
802.3af PoE Quick charge 2.0/3.0 power adapter, 9VDC, 2A |
|
Max. power consumption |
5W |
12.95W |
Get More Information
Do you have any question about the UCK-G2?
Contact us now via Live Chat or [email protected].
UCK-G2 Specification
UCK-G2 Specification |
|
|
Mechanical |
|
|
Dimensions |
27.10 x 46.80 x 119.75 mm (1.07 x 1.84 x 4.71") |
|
Enclosure material |
Anodized aluminum |
|
Hardware |
|
|
Processor |
Quad core Arm® Cortex®-A53 based chip |
|
eMMC memory |
32 GB |
|
Power method |
802.3af PoE, 5VDC, 1A |
|
Max. power consumption |
5W |
|
Networking interface |
GbE RJ45 port |
|
Management interface |
UniFi Protect |
|
Buttons |
(1) Power |
|
LEDs |
(1) Power: white/blue |
|
Operating temperature |
0 to 35° C (32 to 104° F) |
|
Operating humidity |
20 to 80% noncondensing |
|
Certifications |
FCC, CE, IC |
