804367-B21 is the HPE Smart Array P204i-b SR Gen10 (4 Internal Lanes/1GB Cache) 12G SAS Modular Controller. The HPE Smart Array Gen10 Controllers for the HPE ProLiant Gen10 Server Blades, supporting 12Gb/s SAS and PCIe 3.0, are ideal for maximizing performance while supporting advanced RAID levels with up to 2 GB flash-backed write cache (FBWC). These controllers operate in Mixed Mode which combines RAID and HBA operations simultaneously. The Smart Array Gen10 controller portfolio provides the ability to support internally attached drives with the HPE Smart Array P204i-b SR Gen10 Controller and externally attached drives with the HPE Smart Array P408e-m SR Gen10 Controller. The Smart Array SR Gen10 Controllers also offer encryption for data-at-rest on any drive with HPE Smart Array SR Secure Encryption. The HPE controllers provide enterprise-class storage performance, reliability, security and efficiency needed to address your evolving data storage needs.
Quick Spec
Table 1 shows the quick spec.
|
Model |
804367-B21 |
|
Transfer rate |
12Gb/s SAS per lane 6Gb/s SATA per lane PCI Express 3.0 x8 lane width |
|
Form factor |
Type-b modular controller |
|
Ports |
Internal: 4 SAS lanes across 1 x4 port |
|
Cache |
1 GB Flash-Backed Write Cache |
|
Raid levels |
0, 1, 5, 6, 10, 1 ADM |
|
Servers supported |
HPE ProLiant BL460c Gen10 Server Blade |
|
Additional features |
HPE Secure Encryption (optional license) |
Supported Platforms
Table 2 shows the recommended servers.
|
Model |
Description |
|
HPE BL460c Gen10 10Gb/20Gb FLB CTO Blade |
|
|
HPE BL460c Gen10 6148 2P SB Svr Server |
|
|
HPE BL460c Gen10 6132 2P SB Svr Server |
Get More Information
Do you have any question about the 804367-B21?
Contact us now via Live Chat or [email protected].
804367-B21 Specification
804367-B21 Specification |
|
|
General |
|
|
Product Type |
Storage controller (RAID) |
|
Bay Provided |
|
|
Type |
None |
|
Header |
|
|
Manufacturer |
HP CTO Server Avnet |
|
Packaged Quantity |
1 |
|
Product Line |
HPE Smart Array |
|
Model |
P204i-b SR Gen10 |
|
Brand |
HPE |
|
Interface Provided |
|
|
Qty |
1 |
|
Connector Location |
Internal |
|
Type |
SATA 6Gb/s / SAS 12Gb/s |
|
Miscellaneous |
|
|
Compliant Standards |
FIPS 140-2 Level 1 |
|
Features |
Flash Backed Write-back Cache (FBWC) |
|
Color Category |
Green, Silver |
|
Power Device |
|
|
Type |
None |
|
Storage Controller |
|
|
Form Factor |
Plug-in card |
|
Supported Devices |
Disk array (RAID), Hard drive |
|
RAID Level |
RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 5, RAID 6 |
|
Data Transfer Rate |
1.2 GBps |
|
Channel Qty |
4 |
|
Buffer Size |
1 GB |
|
Maximum LUNs |
64 |
|
Host Bus |
PCIe 3.0 x8 |
|
Interface |
SATA 6Gb/s / SAS 12Gb/s |
|
System Requirements |
|
|
Min Operating System |
CentOS, Citrix XenServer, ClearOS, Microsoft Windows Hyper-V Server, Microsoft Windows Server, Oracle Linux, Oracle Solaris, Red Hat Enterprise Linux, VMware vSphere (ESXi) |
