Huawei AP8050TN-HD is an 802.11ac Wave 2 access point (AP) designed for high-density scenarios such as stadiums and outdoor courts. The 2.4 GHz radio supports 2x2 MIMO and two spatial streams; and the 5 GHz radios both support 2x2 MIMO and two spatial streams.
Quick Spec
Table 1 shows the Quick Specs.
|
Product Code |
AP8050TN-HD |
|
Dimensions (H x W x D) |
100mm x 320 mm x 320 mm |
|
Weight |
3.23 kg |
|
Interface type
|
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45 x 2) 1 x Management console port (RJ45) 1 x SFP optical port Note: The optical port supports single-fiber bidirectional optical modules. |
|
Bluetooth |
BLE4.1 |
|
LED indicator |
Indicates the power-on, startup, running, alarm, and fault states of the system. |
|
Power input |
PoE power supply: in compliance with IEEE 802.3at |
|
Maximum number of SSIDs for each radio |
≤ 16 |
|
Maximum number of users |
≤ 768 |
Product Details
Huawei AP8050TN-HD provides these features:
• 802.11ac Wave 2 compliance, MU-MIMO (2SU-2MU-2MU), delivering services simultaneously on one 2.4G radio and two 5G radios; 400 Mbit/s at 2.4 GHz; 867 Mbit/s+867 Mbit/s at 5 GHz; and 2.134 Gbit/s for the device.
• Built-in 5 kA surge protectors; no additional surge protection device required. This design simplifies installation and saves costs.
• Uses a metal shell and heat dissipation design, adapts to a wide temperature range from –40°C to +65°C, and provides 6 kA or 6 kV surge protection capability on an Ethernet interface, and IP68 protection level, meeting industry-level use requirements.
• Supports the Fat, Fit, and cloud modes and enables Huawei cloud-based management platform to manage and operate APs and services on the APs, reducing network O&M costs.
Compare to Similar Items
Table 2 shows the comparison.
|
Product Code |
AP8050TN-HD |
||
|
Dimensions (length x diameter) |
387 mm x φ165 mm |
387 mm x φ165 mm |
100mm x 320 mm x 320 mm |
|
Interface type
|
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45) 1 x 100/1000M/2.5G/5G self-adaptive Ethernet interface (RJ45) 1 x Management console port (RJ45) 1 x SFP fiber interface |
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45) 1 x 100/1000M/2.5G/5G self-adaptive Ethernet interface (RJ45) 1 x Management console port (RJ45) 1 x SFP fiber interface |
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45 x 2) 1 x Management console port (RJ45) 1 x SFP optical port
|
|
Bluetooth |
BLE4.1 |
BLE4.1 |
BLE4.1 |
|
Antenna type
|
Built-in directional antennas (horizontal 60°, vertical30°) |
External antennas (with eight type N connectors) |
Built-in dual-band directional antenna 2.4G: horizontal 40°, vertical 40° 5G-1: horizontal 27°, vertical 27° 5G-2: horizontal 27°, vertical 27° |
|
Antenna gain |
2.4G: 7dBi 5G: 7dBi |
\ |
2.4G : 7dBi 5G-1: 9dBi 5G-2: 9dBi |
|
Maximum transmit power
|
2.4G: 29 dBm (combined power) 5G: 28 dBm (combined power) |
2.4G: 28 dBm (combined power) 5G: 27 dBm (combined power) |
2.4G: 21 dBm (combined power) 5G-1: 20 dBm (combined power) 5G-2: 21 dBm (combined power) |
