HPE MSA 2050 SAS DC Power LFF Storage.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
Q2P39A |
|
Description |
MSA 2050 SAS DC Power LFF Storage |
|
Product Series |
2000 |
|
Product Model |
2050 |
|
Product Type |
DAS Storage System |
|
Host Interface |
12Gb/s SAS |
|
Number of Controllers |
2 |
|
Controller Type |
12Gb/s SAS |
|
RAID Supported |
Yes |
|
RAID Levels |
1, 5, 6, 10 |
|
Number of Total Expansion Bays |
12 |
|
Number of 3.5" Bays |
12 |
|
Number of Hard Drives Supported |
12 |
|
Number of Solid State Drive Supported |
12 |
|
Height |
3.5" |
|
Width |
22.5" |
|
Depth |
17.6" |
|
Form Factor |
Rack-mountable |
|
Rack Height |
2U |
Get more information
Do you have any question about the Q2P39A?
Contact us now via Live Chat or [email protected].
Q2P39A Specification
Q2P39A Specification | |
| General | |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 2U |
| Chassis | |
| Installed Devices / Modules Qty | 0 |
| Supported Devices / Modules Qty | 12 |
| Supported Drives | SAS-3 |
| Storage | |
| Max Supported Capacity | 120 TB |
| HDD Array External Interface | SAS 12Gb/s |
| Maximum LUNs | 512 |
| Storage Controller | |
| Type | 2 x RAID |
| Interface Type | SAS 12Gb/s |
| Data Transfer Rate | 1.2 GBps |
| RAID Level | RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 50 |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) - 3.5 LFF |
| Interfaces | 8 x SAS 12Gb/s ¦ 1 x USB (management) ¦ 1 x Ethernet 1000 (management) |
| System Requirements | |
| OS Required | HP-UX, Red Hat Linux, Apple MacOS X, SUSE Linux Enterprise Server, HP OpenVMS, Microsoft Windows Server 2008 R2, Oracle Solaris, Microsoft Windows Server 2012 |
| Miscellaneous | |
| Features | Systems Insight Manager (SIM) |
| Compliant Standards | CISPR 22 Class A, CISPR 24, GS, EN55022 Class A, CCC, ICES-003 Class A, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, K60950-1, KN22 Class A, China RoHS, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3, EN 55024 Class A, CNS 13438 Class A |
| Power | |
| Power Device | 2 x internal power supply - hot-plug |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | DC 48 - 60 V |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Sound Emission | 55 dBA |
