The Cisco Catalyst 3560-CG Compact Switches are small form-factor Fast Ethernet and Gigabit Ethernet switches designed for deployments outside the wiring closet. This WS-C3560CG-8PC-S offers eight Gigabit Ethernet PoE(+) ports and two dual uplinks.
Quick Specs
Figure 1 shows the Appearance of WS-C3560CG-8PC-S.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C3560CG-8PC-S |
|
Feature Set |
IP Base |
|
Uplink Interfaces |
2 x 1G copper or 2 x 1G SFP |
|
Ports |
8 x 10/100/1000 Gigabit Ethernet PoE(+) ports |
|
Available PoE Power |
124W |
|
Forwarding Bandwidth |
10 Gbps |
|
RAM |
128 MB |
|
Flash Memory |
64 MB |
|
Dimensions |
4.44 x 26.9 x 23.8 cm |
|
Package Weight |
4.65 Kg |
Product Details
Figure 2 shows the front panel of WS-C3560CG-8PC-S.
Note:
|
① |
Mode Button |
⑤ |
System LEDs |
|
② |
USB Type A port |
⑥ |
8 x 10/100/1000 Gigabit Ethernet PoE(+) ports |
|
③ |
USB mini-Type B (console) port |
⑦ |
2 x 1G copper or 2 x 1G SFP |
|
④ |
RJ-45 console port |
Figure 3 shows the back panel of WS-C3560CG-8PC-S.
The Accessories
Table 2 shows some recommended cables and SFP modules.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
Compare to similar item
Table 3 shows the comparison between WS-C3560CG-8PC-S and WS-C3560CG-8TC-S.
|
Models |
WS-C3560CG-8PC-S |
|
|
Uplinks |
2 x 1G copper or 2 x 1G SFP |
2 x 1G copper or 2 x 1G SFP |
|
Ports |
8 x 10/100/1000 Gigabit Ethernet |
8 x 10/100/1000 Gigabit Ethernet |
|
Feature set |
IP Base |
IP Base |
|
Available PoE Power |
124W |
None |
Get more information
Do you have any question about the WS-C3560CG-8PC-S?
Contact us now via Live Chat or [email protected].
WS-C3560CG-8PC-S Specification
WS-C3560CG-8PC-S Specifications |
|
| Product Model | WS-C3560CG-8PC-S |
| Product Brand | Cisco |
| Product Type | Catalyst 3560C Switch |
| Number of Ports | 8 GE PoE(+) |
| Uplink Ports | 2 x Dual Uplink |
| Supported Features | IP Base |
| Power over Ethernet (PoE) | Yes |
| Port Speed | 10/100/1000 |
| Flash | 64 MB |
| Available PoE Power | 124W |
| Power Specifications | 100-240VAC, 1.7-0.8A |
| DRAM | 128 MB |
| QoS (Quality of Service) Support | Yes |
| Uplink Interfaces | 2 x 1G copper or 2 x 1G SFP |
| Port Security | Yes |
| Spanning Tree Protocol (STP) Support | Yes |
| Enhanced Security | Yes |
| Dimensions (W x D x H) | 10.6 x 9.4 x 1.75 inch |
