eSpace 8850 is a full-featured phone that features video call, user-friendly LCD touchscreen, high definition (HD) video camera, and directory functions. By supporting the voice over IP (VoIP) service, eSpace 8850 is the best choice for senior management personnel and enterprise users. Huawei IP1T8850AU01 eSpace 8850 Video Phone features: ·7-inch color touch screen, ·800 * 480 pixels, 16.7M colors ·Fashion design of appearance, and creative multi-media application·Provides USB interface and SD card slot·Supports cordless handset.
Quick Specs
Figure 1 shows the appearance of IP1T8850AU01.
Table 1 shows the Quick Specs.
|
Product Code |
IP1T8850AU01 |
|
Part Number |
50081720 |
|
Description |
eSpace 8850,7 inch LCD Touch Screen,Simple Chinese&English,With USB,Wired Handset,Australia Mode Power,100-240V,50/60Hz,1.8G DECT,for Australia |
|
Display |
·7-inch color touch screen ·800 * 480 pixels , 16.7M colors ·Supports the stylus and handwriting mode ·Support five positions from angle 0° to 35° |
|
External interface |
·1 LAN port, 1 PC port, and 10/100 Mb adaptive ·Audio output: one 3.5 mm headset port for listening only, and no speaking ·2 USB 2.0 ports ·1 SD card slot |
|
Power consumption |
15 W |
|
Flash memory |
512 MB |
|
Pack Weight(kg) |
1.64 |
|
Pack Volume(m^3) |
0.007348 |
|
Pack Dimension(D*W*H mm) |
324*270*84 |
|
Net Dimension(D*W*H mm) |
269.2*135.2*72.4 |
Product Details
Figure 2 shows the front panel of IP1T8850AU01.
Note:
|
① |
Camera used for local video preview and video calls |
|
② |
Home button used to display the home screen |
|
③ |
Back button used to return to the previous screen |
|
④ |
Navigation buttons Includes four arrow buttons (up, down, left, and right) and one OK button ·Arrow buttons used to highlight an item on the screen ·OK button used to confirm selected operation or option |
|
⑤ |
Sleep button used to enter the sleep mode |
|
⑥ |
·Message Waiting Indicator (MWI), which blinks blue when there is a new voice message. ·Sleep indicator, which is steady blue when the phone enters sleep state. |
Figure 3 shows the home screen of IP1T8850AU01.
Note:
|
① |
Voicemail |
|
② |
Call History |
|
③ |
Corporate Directory |
|
④ |
Contacts |
|
⑤ |
Dialer |
|
⑥ |
Home |
|
⑦ |
Status bar |
|
⑧ |
Favorites |
|
⑨ |
Call Forwarding |
|
⑩ |
DND |
|
⑪ |
Settings |
|
⑫ |
Applications |
|
⑬ |
Date |
|
⑭ |
Clock |
|
⑮ |
Help |
|
⑯ |
Line button |
|
⑰ |
Line button LED |
|
⑱ |
Deleting the Favorites |
|
⑲ |
Adding the Favorites |
Compare to Similar Items
Table 2 shows the comparison of IP1T8801US01 and IP1T8850AU01.
|
Product Code |
IP1T8850AU01 |
|
|
Description |
eSpace 8801D,1.8G DECT Handset Charging cradle,Simple Chinese&English, Mode Power/US Mode Power,100-240V,50/60Hz,for PBI,black case |
eSpace 8850,7 inch LCD Touch Screen,Simple Chinese&English,With USB,Wired Handset,Australia Mode Power,100-240V,50/60Hz,1.8G DECT,for Australia |
|
Display |
1.45-inch TFT LCD screen |
·7-inch color touch screen ·800 * 480 pixels , 16.7M colors ·Supports the stylus and handwriting mode ·Support five positions from angle 0° to 35° |
|
Power consumption |
0.008–0.2 W |
15 W |
Get more information
Do you have any question about the IP1T8850AU01?
Contact us now via Live Chat or [email protected].
IP1T8850AU01 Specification
eSpace 8850 Specifications |
|
|
Display |
7-inch color touch screen |
|
800 * 480 pixels , 16.7M colors |
|
|
Supports the stylus and handwriting mode |
|
|
Support five positions from angle 0° to 35° |
|
|
External interface |
1 LAN port, 1 PC port, and 10/100 Mb adaptive |
|
Audio output: one 3.5 mm headset port for listening only, and no speaking |
|
|
2 USB 2.0 ports |
|
|
1 SD card slot |
|
|
Protocol |
TCP/IP, SIP, SDP, UDP, RTP, RTCP, DHCP, Telnet, DNS, PPPoE, TFTP, HTTP, HTTPS, SNTP |
|
Digital cordless handset |
Supports a digital cordless handset (8801D) that complies to the following standards: DECT Mode: 1.8G/ 2.4G |
|
Power supply adapter |
Input: 100V~240 V AC Output: 12 V DC, 2 A Support for the standard of China, Europe, UK, USA and Australia |
|
Power consumption |
15 W |
|
Flash memory |
512 MB |
|
RAM |
256 MB |
|
Dimensions (H x W x D) |
269.2mm*135.2mm*72.4mm |
|
Weight |
1.00 kg |
|
Working temperature |
0°C to 40°C |
|
Working humidity |
10% to 80% |
|
Authentication |
3C, RoHS, CE Accord with Europe EMC Class B |
